INSTALLATION - OVERVIEW
Mount unit with condenser/evaporator coil directly behind return air grill or with at least 3" (76mm) of air circula-
tion clearance if adjacent to a bulkhead or other obstruction. Compressor should be mounted away from return
air grill if possible, to minimize sound level in cabin.
Mounting Brackets -
The four mounting brackets provided should be placed around edge of drain pan as equally
spaced as possible. Secure ale unit to a flat level mounting surface. Customer is to supply screws or bolts.
Route condensates drain hose to a sealed condensate or shower sump pump (see note below).
Drain hose must be routed downward to allow water to flow via gravity downhill.
Very Important!
Do not terminate condensate drain line within 3' (.91M) of any outlet of engine or generator exhaust systems, nor
in a compartment housing an engine or generator, nor in a bilge, unless the drain is connected properly to a sealed
condensate or shower sump pump. If drain line is not properly installed, then dangerous fumes may travel up drain
line and contaminate living quarters.
Items included in the box.
Ethernet cable
Touch screen thermostat control
Insulated tape
Stainless steel clamps.
(Mabru 12V Raw water pump included in the
SC DC 12 Volts units Only)
+1 888 818 2814
support@mabrumarine.com
Page No.6
