INSTALLATION - CHECKLIST
SEAWATER COOLING SYSTEM
Speed scoop located as far below the water line and as close to the keel as possible
Shut off valve (seacock) and speed scoop properly sealed and tight
Seawater pump is at least one foot below water line and securely mounted
Strainer mounted below pump with access to filter
Double/reversed stainless steel hose clamps on all hose connections
Teflon tape on all threaded connections
Hose runs uphill from speed scoop and seacock to strainer, pump and MABRU AC unit, then downhill (if possi-
ble) from MABRU AC unit to overboard discharge
Water flowing freely from overboard discharge while pump is running
Pump relay panel, if used, must have its own circuit breaker sized for the pump (20 Amp max)
All metal fittings should be bonded Mounting
MOUNTING
Not in engine room or bilge areas, must be sealed away from exhaust or fumes
Proper spacing allowed around unit
Attached to solid level platform with hold down clips provided
Condensate drain routed aft and downhill to a sealed sump (not bilge)
Blower rotated toward supply air grille Electrical
GRILLES AND DUCTING
Supply air grille mounted as high as possible
Return air grille mounted as low and as close to the ale unit as possible
Return air grille mounted away from bilge vapors or exhaust fumes
Ducting is pulled taut, straight, smooth and properly connected with no excess
+1 888 818 2814
support@mabrumarine.com
Page No.14
