- Page 1 YOUR CONNECTION TO SAFETY Asian Electron Co., Ltd. PSW1500W / PSW2000W Series Pure Sine Wave Inverter Instruction Manual klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y...
-
Page 2: Table Of Contents
YOUR CONNECTION TO SAFETY List of Contents 1. Features Application Electrical performance Mechanical drawings 2. Introduction Front panel operations Rear panel operations Installation Quick hook – up and testing AC safety grounding Making DC wiring connections Inverter operation Cooling fan working code 3. -
Page 3: Features
YOUR CONNECTION TO SAFETY Features Pure sine wave output (THD < 3%) R Load Output frequency : 50 / 60Hz switch Low power Power Saving Mode to conserve energy RS – 232C interface / remote control port / wire connection to PC Wired remote control Loading and Temperature controlled cooling fan Advanced microprocessor... - Page 4 YOUR CONNECTION TO SAFETY 1-2 Electrical Performance 1500W Specification Model Item PSW12150 PSW24150 PSW48150 PSW12150E PSW24150E PSW48150E Continuous Output Power 1500W Maximum Output Power 1650W(3mins) Surge Rating 3000W Input Voltage Input Voltage Range 10-16VDC 20-32VDC 42-62VDC 10-16VDC 20-32VDC 42-62VDC 15.5VDC 31VDC 61VDC 15.5VDC...
- Page 5 YOUR CONNECTION TO SAFETY Electrical Performance 2000W Specification Model YK- PSW YK- PSW YK- PSW YK-PSW YK-PSW YK-PSW YK-PSW YK-PSW YK-PSW YK-PSW Item 12200 24200 48200 110200 220200 12200E 24200E 48200E 110200E 220200E Continuous Output Power 2000W Maximum Output Power 2300W (3mins) Surge Rating 4000W...
- Page 6 YOUR CONNECTION TO SAFETY 1-3 Mechanical Drawings 1500W & 2000W klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y...
-
Page 7: Introduction
YOUR CONNECTION TO SAFETY Introduction The power inverter series are the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installing and using this model. 2-1 Front Panel Operation 2-1-1 Front view: 2-1-2 ON / OFF switch:... - Page 8 YOUR CONNECTION TO SAFETY 2-1-4 AC outlet (Outlet sockets available): 2-2 Rear Panel Operation: 2-2-1 Ventilation openings: Do not obstruct. Allow at least 3 inch for airflow. 2-2-2 Battery terminals: Connect to 12Vdc / 24Vdc / 48Vdc/110Vdc /220Vdc battery or other 12Vdc / 24Vdc / 48Vdc/ 110Vdc / 220Vdc power source.
- Page 9 YOUR CONNECTION TO SAFETY WARNING! Do not connect the 12V model to a 24V or 48V battery. The unit will be destroyed immediately. 2-2-3 RS-232 Connect to remote control unit (option accessory) or connect to computer to remote control working status. klick to klick to klick to...
-
Page 10: 2-3 Installation
YOUR CONNECTION TO SAFETY WARNING! Any damages caused by using incorrect RS232 cable will be outside of our warranty scope. If you are not sure which one is correct RS232 cable, please purchase the correct RS232 cable from us directly. 2-2-4 Connect chassis ground terminal to earth or to vehicle chassis using # 8 AWG wire. - Page 11 YOUR CONNECTION TO SAFETY 2-4 Quick Hook – Up and Testing: 2-4-1 Unpack and inspect the power inverter, check to see that the power switch in the OFF position. 2-4-2 Connect the cables to the power input terminals on the rear panel of power inverter. The red terminal is positive (+) and black terminal is negative (-).
- Page 12 YOUR CONNECTION TO SAFETY 2-4-5 Set the power switch to the ON position; you will hear the “bi-bi-bi” sound. At the same time, the display shows the word “ASIAN” for two times. After that, you will hear the continuous sound from internal alarm. Then, the AC voltage shows on the display. It means the device has done the operation.
- Page 13 YOUR CONNECTION TO SAFETY WARNING! Do not operate the power inverter without connecting it to Ground. Electrical shock hazard may result. 2-6 Making DC Wiring Connections: Follow this procedure to connect the battery cables to the DC input terminals on the inverter. Your cables should be as short as possible (ideally, less than 10 feet / 3 meters) and large enough to handle the required current in accordance with the electrical codes or regulations applicable to your installation.
- Page 14 YOUR CONNECTION TO SAFETY 2000W Model No Wire AWG Inline Fuse YK-PSW12200 #2/0 250A YK-PSW12200E YK-PSW24200 #1/0 125A YK-PSW24200E YK-PSW48200 YK-PSW48200E YK-PSW110200 YK-PSW110200E YK-PSW220200 YK-PSW220200E Also, use only high quality copper wiring and keep cable length short from 3-6 feet. 1500W &...
- Page 15 YOUR CONNECTION TO SAFETY 2-7-1 Controls and indicators: The ON / OFF switch turns the control circuit in the power inverter on and off. The inverter operates from an input voltage range: 10.0 to 16.0 VDC for 12V models 20.0 to 32.0 VDC for 24V models 42.0 to 62.0 VDC for 48V models 90.0 to 140 VDC for 110V models 180 to 275 VDC for 220V models...
- Page 16 YOUR CONNECTION TO SAFETY 2-7-7 Output Frequency AC indicator LED displays light on Hz as show as output frequency value Please have the accuracy of 6 functions of display, as below: Functions AMP WATT TEMP Frequency 100-120 200-240 10-16 20-32 42-62 90-140 180-275...
-
Page 17: Maintenance
YOUR CONNECTION TO SAFETY 2-8 Cooling Fan Working Code: Cooling fan of inverter is through detecting output power and over temperature situation to work. Regarding the Pure Sine Wave 1500W inverter: When start to turn on the inverter and output power under 300W, the cooling fan does not start running. -
Page 18: Warranty
YOUR CONNECTION TO SAFETY Warranty: We warrant this product against defects in materials and workmanship during warranty period and will repair or replace any defective power inverter when directly returned (postage paid) to This warranty will be considered void if the unit has suffered any obvious damage by natural and man-made factors or alteration either internal or external and does not cover damage arising from improper use such as plugging the unit into an unsuitable power sources attempts to operate products with excessive power consumption requirement, or use in unsuitable... -
Page 19: Appendices A
YOUR CONNECTION TO SAFETY Appendices A 7-1 Dip Switch (at the left side of inverter) FREQ. (Hz) BAUD RATE POWER SAVING ACV-ADJ H--------L 2400 DISABLE 240V 200V H--------L 4800 ENABLE 120V 100V ---- ---- 9600 ---- ----- ---- ---- ---- 19200 ---- -----...
