- Page 1 YOUR CONNECTION TO SAFETY Asian Electron Co., Ltd. PST700W Series Pure Sine Wave Inverter Instruction Manual klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y...
-
Page 2: Table Of Contents
YOUR CONNECTION TO SAFETY List of Contents 1. Features Application Electrical performance Mechanical drawings 2. Introduction Front panel operations Rear panel operations Installation Quick hook – up and testing AC safety grounding Making DC wiring connections Inverter operation Cooling fan working code 3. -
Page 3: Features
YOUR CONNECTION TO SAFETY Features Pure Sine Wave output (THD < 3%) R Load Output frequency: 50/60Hz switch Bypass Function Wired remote control Loading controlled cooling fan Advanced microprocessor Protection: Input Undervoltage Input Overvoltage Overload Short circuit Low battery alarm Over temperature 1-1 Utilities Application 1-1-1 Power tools –... - Page 4 YOUR CONNECTION TO SAFETY 1-2 Electrical Performance Specification Model Item PST1270 PST2470 PST4870 PST1270E PST2470E PST4870E Continuous Output Power 700W Maximum Output Power 780W (3Min.) Surge Rating 1400W Input Voltage Input Voltage Range 10-16VDC 20-32VDC 42-62VDC 10-16VDC 20-32VDC 42-62VDC DC Input Over Voltage Alarm 15.5VDC 31.0VDC 61.0VDC 15.5VDC...
- Page 5 YOUR CONNECTION TO SAFETY Mechanical Drawings klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y Y O U R C O N N E C T I O N TO S A F E T Y...
-
Page 6: Introduction
YOUR CONNECTION TO SAFETY Introduction The power inverter series are the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installing and using this model. 2-1 Front Panel Operation 2-1-1 Front view 2-1-2 ON / OFF switch... - Page 7 YOUR CONNECTION TO SAFETY 2-2 Rear Panel Operation 2-2-1 Ventilation openings Do not obstruct. Allow at least 3 inch for airflow. 2-2-2 Battery terminals Connect to 12V / 24V / 48V battery or other 12V / 24V / 48V power source. is positive;...
-
Page 8: Installation
YOUR CONNECTION TO SAFETY 2-3 Installation Where to install The power inverter should be installed in a location that meets the following requirements. 2-3-1 Dry – Do not allow water to drip or splash on the inverter. 2-3-2 Cool – Ambient air temperature should be between -20°C and 50°C, the cooler the better. - Page 9 YOUR CONNECTION TO SAFETY WARNING! Make sure all the DC connections are tight (torque to 9-10 ft-lbs, 11.7-13Nm). Loose connections will overheat and could result in a potential hazard. 2-4-4 Before proceeding further, carefully check that cable you have just connected negative terminal of inverter to the negative output power source.
- Page 10 YOUR CONNECTION TO SAFETY 2-5-1 Neutral Grounding (GFCI’s): 2-5-1-1 120V models: The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation. According to National Electrical Code requirements that separately derived AC sources (such as inverter and generators) have their neutral conductors tied to ground in the same way that the neutral conductor from the utility is tied to ground at the GFCI breaker panel.
- Page 11 YOUR CONNECTION TO SAFETY WARNING! The installation of a fuse must be on positive cable. Failure to place a fuse on “+ “cables running between the inverter and battery may cause damage to the inverter and will void warranty. Increasing your DC cable size will help improve the situation. Our company recommends the following cables for optimum inverter performance (apply both 120V and 230V versions.
- Page 12 YOUR CONNECTION TO SAFETY 2-7 Inverter Operation To operate the power inverter, turn it on using the ON/OFF switch on the front panel. The power inverter is now ready to deliver AC power to your loads. If you are operating several loads from the power inverter, turn them on separately after the inverter has been turned on.
-
Page 13: Maintenance
YOUR CONNECTION TO SAFETY Cooling Fan Working Code Cooling fan of inverter is through detecting output power and over temperature situation to work. When start to turn on the inverter and output power under 300W, the cooling fan does not start running. -
Page 14: Warranty
YOUR CONNECTION TO SAFETY Warranty We warrant this product against defects in materials and workmanship during warranty period and will repair or replace any defective power inverter when directly returned (postage paid) to This warranty will be considered void if the unit has suffered any obvious damage by natural and man-made factors, or alteration either internal or external and does not cover damage arising from improper use such as plugging the unit into an unsuitable power sources attempts to operate products with excessive power consumption requirement, or use in unsuitable... -
Page 15: Appendices A
YOUR CONNECTION TO SAFETY 6-2-4 Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid battery. A lead-acid battery produces a short-circuit current high enough to weld a ring or the like to metal, causing a severe burn. 7.
