- Page 1 BMT-RTR User Manual | EN V 1.0 | Version 10/2021 Page 1 of 36 BMT-RTR BACnet Router User Manual METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com...
-
Page 2: Table Of Contents
Editing the Manual Slave Address Binding (MSAB) table ..............22 4.7.2 Editing the Broadcast Distribution Table (BDT) ................23 Security............................24 METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... - Page 3 4.11.2 Device Settings ..........................32 4.11.3 Firmware Update ..........................33 4.12 Configuration using the “MC-Search Utility” ................34 METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com...
-
Page 4: Preamble
1 Preamble 1.1 About this User Manual This document describes the operation of the BMT-RTR (BACnet Router), P/N 11088001 and P/N 1108800170 The description contains information on the use and installation of the device. If you have any questions that cannot be answered with the help of this manual, please contact the manufacturer for further information. -
Page 5: Qualified Specialists
(ISO 16484-5:2017) router with BACnet/IP, BACnet Ethernet (ISO 8802-3) and BACnet MS/TP protocols support. There are two 4-pin connectors on the front panel to connect to METZ CONNECT expansion modules. Third-party BACnet MS/TP fieldbus I/O-modules can be connected via the device terminal block. -
Page 6: Technical Data
Material – Terminal block Polyamide 6.6 V0 Material – Covers Polycarbonate REACH – substance (SVHC) Lead / 7439-92-1 METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 7: Installation
The BMT-RTR is suitable for decentralized mounting in electrical sub-distribution boards or in switch cabinets on TH35 mounting rails according to IEC 60715. The BMT-RTR can be snapped onto a TH35 mounting rail according to IEC 60715 for installation in an electrical distributor or small enclosure. The device has to be accessible for operating, testing, inspection and maintenance. -
Page 8: Connection
2 remove the device to the front After using, the BMT-RTR must be disposed of as electronic scrap in accordance with the WEEE Directive and the laws in force in the respective country. Further information is available from METZ CONNECT GmbH. -
Page 9: Power Supply
3.4.2 Power Supply The operating voltage of the BMT-RTR is 24 Volt DC +/- 10% (SELV) and is either provided via a jumper plug and the NG4 power supply unit from METZ CONNECT (Figure 5) or directly via the power supply terminals on the device. -
Page 10: Indicators
Flash on 50ms when receiving any correct BACnet MS/TP frame Busy RX MS/TP RX Green LED: Off BACnet Router is not receiving Data METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 11: Configuration
4 Configuration 4.1 Web interface The BMT-RTR has an integrated and intuitive web interface for parameter settings, management and monitoring of router in responsive design. The Ethernet connection is established via a standard patch cable and the RJ45 connector on the device. -
Page 12: Getting Started
If you have connected to a new device that does not yet have a password, you will see a message at the beginning: METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... - Page 13 If the device password has already been set, you may see the following login form: Figure 10 Enter password METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433...
-
Page 14: Reset To Factory Default
„OFF“ position. Replace the housing cover and start up the device. Figure 11 Default- jumper settings METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 15: Overview
After the login process has been successfully completed, you will be taken to the start page of the web interface. The menu item Overview displays the current settings of the BMT-RTR. Clicking on the METZ CONNECT logo takes you directly to the product page on www.metz-connect.com... -
Page 16: Dynamic Window Adaptation
To restore the navigation menu, click the "≡" button. Figure 13 Collapsed navigation menu example Figure 14 Expanded navigation menu example METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 17: Network
If you have specified a valid DNS server address, are using DHCP mode, and your DHCP server is configured to issue a DNS server address, then your BMT-RTR device will use two DNS servers. When you finish changing the settings, do not forget to click the "Save changes" button. - Page 18 In this case, to continue working, the new IP address must be specified in the address bar of the browser. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433...
-
Page 19: Bacnet
The parameters on the "BACnet" page are divided into four groups: Settings of the object "Device". Settings of the object "Network Port: MS/TP". METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... - Page 20 This parameter is an indication of whether (TRUE) or not (FALSE) Slave Proxy enabled the device will perform Slave-Proxy functions for this port. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com...
- Page 21 This parameter contains the address of the BBMD device. An IP address or network name can be used. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com...
-
Page 22: Editing The Manual Slave Address Binding (Msab) Table
To edit the MSAB table, you need set "Slave Proxy enabled" checkbox in the BACnet MS/TP group and click the "Edit MSAB table" button. Figure 18 Edit MSAB table METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 23: Editing The Broadcast Distribution Table (Bdt)
(clear one record) or the "Clear All" button (clear all records). When you finish editing the BDT table, do not forget to click the "Save changes" button. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 24: Security
V 1.0 | Version 10/2021 Page 24 of 36 4.8 Security The "Security" page contains parameters that relate to security and restricting access to the "BMT-RTR" device. Using this page, you can: Set or change the password for the device's WEB interface. -
Page 25: Monitoring
Page 25 of 36 4.9 Monitoring The menu item “Monitoring” is designed to display the current state of the BMT-RTR device. The monitoring page contains several additional tabs, the content of which depends on the selected mode of operation of the network port BACnet/IP. -
Page 26: Devices Tab
One address is scanned per second. The devices found are marked green in the table. The entire scan takes up to 256 seconds. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 27: Routing Tab
Network" broadcast BACnet message. Next, routing information is automatically filled in based on the received responses from other BACnet routers. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 28: Bbmd Tab
Figure 25 Monitoring – Foreign Device Table The foreign device can be forcibly disconnected by clicking the "X" button. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 29: Ms/Tp Capture
When recording, you can watch the number of captured MS/TP frames. To stop recording and write the results to a file, click the "Stop and save results" button. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 30: Maintenance
V 1.0 | Version 10/2021 Page 30 of 36 4.11 Maintenance This menu item contains the maintenance functions of the BMT-RTR device. Figure 28 Menu item Maintenance METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 31: Device Management
When you press the "Device Locator" button, all the LED indicators of the device flash at a frequency of 5 Hz for 5 seconds. This function helps you determine the location of the device among other equipment. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433... -
Page 32: Device Settings
If you choose to restore the factory default settings, you can see confirmation window with a list of the parameter values that will be set. Figure 32 Confirmation METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com... -
Page 33: Firmware Update
V 1.0 | Version 10/2021 Page 33 of 36 4.11.3 Firmware Update To update the software of the BMT-RTR, a firmware update can be carried out. The latest firmware is available on the METZ CONNECT homepage at www.metz-connect.com/bacnet-router Figure 33 Firmware Update... -
Page 34: Configuration Using The "Mc-Search Utility
The utility allows you to fast find and configure the device parameters even if its network parameters are incorrectly configured. This can be useful if you don't know the current device network settings. For the access to the web interface of BMT-RTR, the network settings must be configured via the MC- Search Utility tool: 1. - Page 35 V 1.0 | Version 10/2021 Page 35 of 36 The “Network” tab is used to display and configure the network settings of the BMT-RTR router. Figure 35 MC-Search Utility – Network tab If you have changed the network settings of the device, then you need to click the "Update" button.
- Page 36 For a description of the parameter assignment, see the section configuration descriptions via the WEB interface. After changing the BACnet parameters, do not forget to click the "Update" button. METZ CONNECT GmbH | Im Tal 2 | 78176 Blumberg | Germany Tel. +49 7702 533-0 | Fax +49 7702 533-433 more Documentation: www.metz-connect.com...
