- Page 1 A Twin-Star International Br and MODEL: 23IRM7490-W500 INSERT MODEL: 23II033FGL www.tsicustomerservice.com 1-866-661-1218 Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China www.tsicustomerservice.com MP#MG 23IRM7490REV.0...
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. DANGER – High temperatures may be generated under certain abnormal conditions. Do not partially or fully cover or obstruct the front of this heater. - Page 3 HARDWARE/QUINCAILLERIE/ACCESORIOS [x1] REPLACEMENT PARTS 23IRM7490 PIECES DE REMPLACEMENT 23IRM7490 PARTES DE REPUESTO 23IRM7490 PH-BKTZNC001 PH-CSTBLK001 PH-CSTBLK002 MP#MG 23IRM7490REV.0 www.tsicustomerservice.com...
-
Page 4: Getting Started
GETTING STARTED 1. Remove the product identification sticker from the front of the insert. Product Identification Sticker 2. Attach the Product Identification Sticker to the Manual below for future reference. This information is used for product registration and also is necessary for customer service. Attach Product Identification Sticker Here 3. - Page 5 OPERATION INSTRUCTIONS Control Panel Display The heater can be operated by either the remote control or the control panel. 23IRM7490REV.0 www.tsicustomerservice.com MP#MG...
- Page 6 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION The power button supplies power to all of the functions POWER of the fireplace. The power button will put the insert in a standby mode. This will turn off all functions at once but will hold the settings in the memory. By pressing the Power button again the unit will turn on at the same settings.
-
Page 7: Troubleshooting
TROUBLESHOOTING Problem Root Cause Corrective Action Unplug the fireplace, remove the back panel of the fireplace and check that The thermostat sensor is Display shows “ ” the thermostat is plugged into the main circuit board. If this does not solve broken or disconnected. -
Page 8: Exploded View
EXPLODED VIEW Part Part Name Part Number Emberbed Circuit Board Y15-S146-P44E Flame Generator Drive Motor P10-6-Q Flame Circuit Board Y15-C70-P40 Flame Generator/ Spinner Y15-S146-P11 Main Circuit Board Y15-S146-P15 Heater/Blower Assembly Y15-S146-P01 Control Panel Circuit Board Y15-S146-P32 Control Panel Buttons Y15-S146-P85 Emberbed with Log Y15-S146-P02 Log Circuit Board... -
Page 9: Fcc/Ic Information
FCC/IC INFORMATION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 10: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. 1. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. - Page 11 A Twin-Star International Br and www.tsicustomerservice.com MP#MG 23IRM7490REV.0 www.tsicustomerservice.com...
