Summary of Contents for CDA HC3621FR
- Page 1 Ceramic Hob Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 (EMC) 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 • Do not place hot lids flat on the hob top. A “suction” effect could cause damage to the hob. • Do not drag cookware across the hob top: in the long term, this could cause damage to the hob. •...
-
Page 5: Using Your Hob
Using your hob Zones: 1. Front 1.2kW Ø 145mm 2. Rear 1.8kW Ø 180mm fig. 1 fig. 2 Control panel: 1. On/off sensor 5. Cooking zone indicators 2. Timer plus setting selector 6. Zone minus setting selectors 3. Timer minus setting selector 7. - Page 6 Using Your Hob To switch the hob on • To switch the power on, touch and hold the "On/off sensor" (1) approximately one second. The hob will beep and both cooking zone indicators (5) will show “0”. Please note: When switching the hob on after the appliance has been switched off at the mains, the front zone's display may show, in series, 4 0 3 and then the safety key lock will activate.
- Page 7 • To switch off the hob immediately, touch and hold the "On/off sensor" (1) for approximately one second. Please note: Any zones that are still hot to the touch will display an " " provided the mains power supply is not interrupted. Operating time limiter Each zone has an operating time limiter to increase overall efficiency and to prevent the hob from being left on indefinitely.
- Page 8 Auto-heat Function Both zones are equipped with an auto-heat function, which reduces the warming up time for the zone. To activate the auto-heat function on a zone • Switch the hob on, if not already so, and touch the zone's minus setting selector (6).
- Page 9 Timer The hob is equipped with a timer that allows a finish time to be set for the end of cooking on any zone, between a minimum of 1 minute and a maximum of 99 minutes. The timer can only be used on one zone at a time.
-
Page 10: Safety Key Lock
the countdown. Simply touch the timer plus or minus setting selectors and re-adjust to the desired number of minutes. To cancel the timer • SImply touch the timer plus setting selector (2) and the timer minus setting selector (3) simultaneously. The timer display will revert to displaying ‘00’... -
Page 11: Residual Heat Indicators
To deactivate the safety key lock Simply touch and hold the safety key lock sensor (7) for approximately 2 seconds. The hob will beep and the safety key lock LED should extinguish. Residual Heat Indicators The hob is equipped with residual heat indicators to warn when any of the zones are still hot to the touch after use. -
Page 12: Efficient Use Of Your Hob
Efficient Use of Your Hob The hob is equipped with zones designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 13: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. - Page 14 2. Check that the mains supply has not been switched off. 3. Check that the fuse in the spur has not blown. In the event of a fault with the hob please advise CDA Customer Care. Contact CDA Customer Care...
-
Page 15: Troubleshooting
The hob is not working and the The electronics touched too briefly (less again and for longer display shows a non-standard are not functioning Call CDA Customer Care than a second) graphic correctly Sensor fields do not The hob is not working and the... - Page 16 Should any error code show on the zone displays, or the above steps not resolve an issue, please contact CDA Customer Care for assistance. Contact details are on page 14. IMPORTANT - PLEASE NOTE: In the event of any breakage, crack or cracking –...
-
Page 17: Fitting The Hob
Fitting the Hob Unpacking the hob: Installation above a cupboard unit Take care not to lose, drop or mishandle any parts. 20mm Fitting position of the hob: 35mm This appliance must be installed a minimum of 50mm from any back 500 x 10mm wall and a minimum of 55mm away from any adjacent vertical surfaces,... - Page 18 If fitting a cooker hood above the hob: If a cooker hood is to be installed above the hob, the height of the hood above the hob must be at least 600mm (650mm is recommended) (Fig.6). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, Fig.6...
-
Page 19: How To Install The Hob
How to Install the Hob Overall dimensions of the hob: Width: 300 mm Depth: 520 mm Worktop cut-out dimensions: Width: 285 mm Depth: 490 mm 1 - Worktop 1. Make the required hole in the worktop. 2 - Hob seal 3 - Ceramic hob Fig.7 Before doing this, you must check the... - Page 20 If fitting the hob into a 28-40mm worktop: The four fixing clips supplied should be used. If fitting the hob into a thin worktop (i.e. 28mm), then we recommend using four 15x15x50mm wooden batons in addition to the brackets (as per figs. 9 and 10). Position the fixing brackets perpendicularly to the hob’s edge and tighten firmly.
-
Page 21: Mains Electricity Connection
Mains Electricity Connection Warning! This appliance must be earthed. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. Live L: BN - brown Neutral N: BU - blue Earth PE: GNYE -green/yellow This appliance is intended to be... - Page 22 • This appliance is intended to be connected to the mains supply with a cable of cross sectional area 1.5mm 2 . • The current rating of the fuse or circuit breaker protecting this appliance should be marked on the socket outlet. •...
- Page 23 Energy E ciency Information Attribute Symbol Value Units CDA model HC3621FR Type of hob Built in Number of cooking zones and/or areas Heating technology (induction cooking Radiant zones and cooking areas, radiant cooking zones cooking zones, solid plates) For circular cooking zones or area: Ø...
- Page 24 Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
