LCD Projector
MP-AW4001/MP-AW3001/MP-AX3001
User's Manual (concise)
Thank you for purchasing this product.
This is the basic manual on the product.
Visit our website to get the detailed manuals and the latest information on the
product. Check them before using the product, for safe use and utilization of the
product.
Our website: See the attached sheet.
WARNING
product. After reading them, store them in a safe place for future reference.
NOTE • In this manual, unless any comments are accompanied, "the
manuals" means all the documents provided with this product, and "the product"
means this projector and all the accessories came with the projector.
Contents
............................................ 2
Important safety instruction ..............................2
Regulatory notices .............................. 3
recycling systems .............................................5
Contents of package........................... 5
Arrangement ....................................... 6
Turning on the power ........................ 11
Operation .......................................... 12
Turning off the power ........................ 14
3
the internal clock battery ............... 16
................................... 18
.. 15
1

Advertisement

Table of Contents
loading

Related Manuals for Hitachi MP-AW4001

Summary of Contents for Hitachi MP-AW4001

  • Page 1: Table Of Contents

    LCD Projector MP-AW4001/MP-AW3001/MP-AX3001 User's Manual (concise) Thank you for purchasing this product. This is the basic manual on the product. Visit our website to get the detailed manuals and the latest information on the product. Check them before using the product, for safe use and utilization of the product.

  • Page 2: Entries And Graphical Symbols Explanation

    First of all Entries and graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.

  • Page 3: Regulatory Notices

    Regulatory notices About Electro-Magnetic Interference In CANADA In the US, and other places where the FCC regulations are applicable Declaration of Conformity: See the attached sheet. to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015. Laser evaluation standard: IEC60825-1: 2007, IEC60825-1: 2014, EN60825-1: 2014 MP-AW4001: Max. Output: 95W Wave Length: 449 - 461nm Laser Aperture Max. Output: 71W Wave Length: 449 - 461nm IEC60825-1:2014 and JIS C 6802:2014, and as a class 2 laser product that of the following.

  • Page 5: Only For European Union And Countries With Recycling Systems

    Regulatory notices (continued) Disposal of Old Equipment and Batteries Only for European Union and countries with recycling systems The above mark is in compliance with the Waste Electrical and Electronic requirement NOT to dispose the equipment including any spent or discarded batteries as unsorted municipal waste, but use the return and collection systems available.

  • Page 6: Arrangement

    Arrangement Refer to tables T-1 and T-2 an F-1 and F-2 at the end of this manual to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. Screen size (diagonal) Projection distance (±8%) Screen height (±8%) b1 , b2...

  • Page 7: Connecting With Your Devices

    Arrangement (continued) Connecting with your devices Make sure that all the devices are suitable to be connected with this product, and F-3 to F-5 at the back of this manual. website. ( • When AUTO is selected for the COMPUTER IN1 or COMPUTER IN2 port in COMPUTER IN of the INPUT menu, that port will accept component video signals.
  • Page 8 Connecting with your devices (continued) NOTICE ports of the projector are recessed. Ferrite core for MHL cable cable tie. Cable tie - small Projector Fastening the adapter cover Use the supplied adapter cover to prevent the off easily and prevention from burn injury. Loosen the screw (marked with triangle) on the bottom left of the USB TYPE A port.

  • Page 9: Connecting To A Power Supply

    Connecting to a power supply Put the connector of the power cord into the AC (AC inlet) of the projector. outlet. In a couple of seconds after the power supply connection, the POWER/STATUS1 indicator will light up in steady orange. Please remember that when the DIRECT POWER ON function is activated, the connection of the power supply makes the projector turn on.

  • Page 10: Preparing For The Remote Control

    Preparing for the remote control Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.

  • Page 11: Turning On The Power

    Turning on the power POWER/STATUS1 indicator STANDBY/ON button and correctly connected to the projector and the outlet. Make sure that the POWER/STATUS1 indicator is steady orange. Press the STANDBY/ON button on the MYBUTTON INPUT projector or the remote control. ASPECT PbyP AUTO FREEZE...

  • Page 12: Adjusting The Projector's Elevator

    Adjusting the projector's elevator The projector has 2 Rear feet for adjusting the horizontal position and inclination. You can use the projector as it is with attached Spacers of Rear feet. You can make more precise adjustments by detaching the spacers and turning the Rear feet. -1~1°...
  • Page 13 Focusing ASPECT button Use the FOCUS + and FOCUS - buttons on FOCUS +/- button MYBUTTON INPUT the projector or remote control to adjust the ASPECT PbyP AUTO FREEZE screen focus. ZOOM +/- button MAGNIFY FOCUS ZOOM VOLUME Selecting an aspect ratio PAGE VOLUME +/- button GEOMETRY...

  • Page 14: Turning Off The Power

    NOTE • The ASPECT button does not work when no proper signal is input. an operation is made. This is not a malfunction. Turning off the power POWER/STATUS1 indicator STANDBY/ON button Press the STANDBY/ON button on the projector or the remote control. The message “Power off?”...
  • Page 15 type number from your dealer when purchasing a new one. Type number : UX43251 ilter set) Turn the projector off, and unplug the power cord. Allow Press up slightly the bottom side knobs to unlock the Use a vacuum cleaner for the inner side of each are damaged or heavily soiled, replace them with the new ones.

  • Page 16: Installing Or Replacing The Internal Clock Battery

    Installing or replacing the internal clock battery This product has an internal clock. When you use the function that requires the internal clock ( "Event Scheduling" in the Network Guide), install a new battery. If the internal clock starts to malfunction, try to replace the battery. Use the following type of battery, and follow the steps below.

  • Page 17: Caring For The Projection Window

    Caring for the projection window of display quality. Please take care of the projection window, being cautious of handling. Turn the projector off and unplug the power cord from the power outlet. And cool the projector down by leaving it for a while. Use an air blower to blow away dust on the projection window before wiping.
  • Page 18 35 ~ 40°C (The brightness of the light source is reduced automatically.) Size F-6 at the back of this manual. approx. 7.4 kg Weight (mass) MP-AW4001: approx. 7.6 kg Computer input port Audio input/output port COMPUTER IN1 AUDIO IN1 ....Stereo mini x1 .......

  • Page 19: Troubleshooting - Warranty And After-Service

    Troubleshooting - Warranty and after-service If an abnormal operation (such as smoke, strange odor or excessive sound) should occur, stop using the projector immediately. “Operating Guide” and “Network Guide”, and run through the suggested checks. If this does not resolve the problem, please consult your dealer or service company.
  • Page 20 End User License Agreement for the Product Software Software in the product consists of the plural number of independent software of such software modules. The product also uses software modules that we property for each of such software and related items including but not limited to the software related documents.
