LCD Projector
MP-JW351E/MP-JW401E
MP-JX351E
User's Manual (concise)
Thank you for purchasing this product.
This is the basic manual on the product. Visit our website to get the detailed
manuals (Safety Guide, Operating Guide) and the latest information on the
product.
Check them before using the product, for safe use and utilization of the product.
For our website, see the attached sheet.
►Before using this product be sure to read all manuals for this product. After
reading them, store them in a safe place for future reference.
►Heed all the warnings and cautions in the manuals or on the product.
►Follow all the instructions in the manuals or on the product.
NOTE • In this manual, unless any comments are accompanied, "the manuals" means
all the documents provided with this product, and "the product" means this projector and
all the accessories came with the projector.
Contents
First of all ...........................................2
Laser warning ..................................5
recycling systems ..........................6
Contents of package..........................7
Arrangement ......................................9
Turning on the power .......................13
WARNING
Displaying the picture ......................15
Turning off the power .......................16
the air filter .....................................17
Specifications ..................................19
for the product software ................21
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MP-JX351E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hitachi MP-JX351E

Summary of Contents for Hitachi MP-JX351E

  • Page 1: Table Of Contents

    LCD Projector MP-JW351E/MP-JW401E MP-JX351E User's Manual (concise) Thank you for purchasing this product. This is the basic manual on the product. Visit our website to get the detailed manuals (Safety Guide, Operating Guide) and the latest information on the product.

  • Page 2: First Of All

    First of all Graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Know their meanings beforehand and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.
  • Page 3 Important safety instructions (continued) WARNING ►Use only the accessories specified or recommended by the manufacturer. ►Do not modify the projector or accessories. ►Do not let any things or any liquids enter to the inside of the product. ►Do not get the product wet. ►Do not place the projector in the following place where oils or chemicals are used: - near the kitchen which oil smoke comes from...

  • Page 4: Electro-Magnetic Interference

    Electro-magnetic interference In CANADA CAN ICES-3(B) / NMB-3(B). In the US, and other places where the FCC regulations are applicable This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Laser Warning

    Laser warning Product Label: The position of the label is Laser aperture shown in the drawing below. CLASS 1 LASER PRODUCT PRODUIT LASER DE CLASSE 1 LASERPRODUKT DER KLASSE 1 1 類雷射產品 IEC/EN 60825-1:2014 Top view Bottom view As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015 Laser evaluation standard IEC60825-1: 2014, EN60825-1: 2014 Internal Laser Specifications...

  • Page 6: Disposal Of Old Equipment And Batteries Only For European Union And Countries With Recycling Systems

    Disposal of old equipment and batteries only for European Union and countries with recycling systems The above mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries as unsorted municipal waste, but use the return and collection systems available.

  • Page 7: Contents Of Package

    Contents of package Your projector should come with the items shown below. Check that all the items are included. Contact your dealer immediately if any items are missing. Remote control with two AA batteries INPUT MYBUTTON (2) Power cord (x1) ASPECT PbyP AUTO...

  • Page 8: Preparing For The Remote Control

    Preparing for the remote control Insert the batteries into the remote control before using it. Use the appropriate AA carbon-zinc or alkaline batteries (non-rechargeable) in accordance with laws and regulations. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.

  • Page 9: Arrangement

    Arrangement Refer to the table T-1 to T-2 in Supplement (at the end of this manual) to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. The values may be different slightly. This projector will perform in a free tilt angle, as shown in the figures below.

  • Page 10: Connecting With Your Devices

    Arrangement (continued) CAUTION ►Place the projector in a cool place with sufficient ventilation. - Install the projector away from walls or other objects in a well-ventilated place. - Do not stop up, block nor cover the projector’s vent holes. - Do not place the projector on carpet, cushions or bedding. - Do not place the product at places that are exposed to magnetic fields, doing so can cause the cooling fans inside the projector...
  • Page 11 Connecting with your devices (continued) WARNING ►Use only the appropriate accessories. Otherwise it could cause a fire or damage the projector and devices. - Use only the accessories specified or recommended by the projector’s manufacturer. It may be regulated under some standards. - Neither disassemble nor modify the projector and the accessories.

  • Page 12: Connecting To A Power Supply

    Connecting to a power supply Put the connector of the power cord into the POWER/STATUS1 AC (AC inlet) of the product. indicator Firmly plug the power cord’s plug into the outlet. In a couple of seconds after the power supply connection, the POWER/STATUS1 indicator lights up in steady orange.

  • Page 13: Turning On The Power

    Turning on the power POWER/STATUS1 indicator Make sure that the power cord is firmly and STANDBY/ON button correctly connected to the projector and the outlet. Make sure that the POWER/STATUS1 indicator is steady orange. Then remove the lens cover. Press the STANDBY/ON button on the projector or the remote control.

  • Page 14: Adjusting The Projector's Elevator

    Adjusting the projector's elevator Lengthening or shortening the each elevator foot shifts the projection position and the projection angle. Turn the elevator foot to adjust its length. Front foot WARNING max. ►Do not lengthen the elevator foot exceeding 22 mm. The foot lengthened exceeding the limit may come off and drop the projector down, and result in an injury or damaging the projector.

  • Page 15: Displaying The Picture

    Displaying the picture Activate your signal source. Turn the FOCUS ring signal source on, and make it send the signal to the projector. ZOOM ring Use the VOLUME + / VOLUME - INPUT button buttons to adjust the volume. To turn off the sound, press the MUTE button on the remote control.

  • Page 16: Turning Off The Power

    Turning off the power Press the STANDBY/ON button on the POWER/STATUS1 indicator projector or the remote control. STANDBY/ON button The message “Power off?” appears on the screen for about 5 seconds. Press the STANDBY/ON button again while the message appears. The light source will go off, and the POWER/ STATUS1 indicator will begin blinking in orange.

  • Page 17: Cleaning And Replacing The Air Filter

    Cleaning and replacing the air filter Check and clean the air filter periodically. When the indicators or a message prompts you to clean the air filter, comply with it as soon as possible. The filter unit is attached to inner side of the filter cover. If a filter of the filter unit is damaged or heavily soiled, replace the whole unit with a new one.
  • Page 18 Cleaning and replacing the air filter (continued) WARNING ►Before taking care of the air filter, make sure the power cord is not plugged in, then allow the projector to cool sufficiently. ►Use only the air filter of the specified type. Do not use the projector without the air filter or the filter cover.

  • Page 19: Specifications

    786,432 pixels (1024 horizontal x 768 vertical) Light source Laser diode Speaker 1 W mono MP-JW401E: 2.6A (AC 100V-120V), 1.3A (AC 220V-240V) Power supply/ MP-JW351E/MP-JX351E: 2.3A (AC 100V-120V), Rated current 1.2A (AC 220V-240V) MP-JW401E: 250W (AC 100V-120V), 240W (AC 220V-240V) Power MP-JW351E/MP-JX351E: 230W (AC 100V-120V), consumption 220W (AC 220V-240V) 0 ~ 40 °C...
  • Page 20 Specifications (continued) Item Specification COMPUTER IN ......D-sub 15 pin mini jack x1 HDMI ............HDMI connector x1 AUDIO IN ......... 3.5 mm (stereo) mini jack x1 AUDIO OUT ......3.5 mm (stereo) mini jack x1 Ports CONTROL ..........D-sub 9 pin plug x1 DC5V 2A ...............

  • Page 21: End User License Agreement For The Product Software

    End user license agreement for the product software Software in the product consists of the plural number of independent software modules and there exist our copyright and/or third party copyrights for each of such software modules. The product also uses software modules that we have developed and/or produced.

  • Page 22: Troubleshooting - Warranty And After-Service

    Troubleshooting - Warranty and after-service If an abnormal operation (such as smoke, strange odor or excessive sound) should occur, stop using the projector immediately. Otherwise if a problem occurs with the projector, first refer to “Troubleshooting” of the Operating Guide, and follow the suggested checks.
