Little Tikes Fire Rescue Cozy Truck Assembly Instructions Manual

Little Tikes Fire Rescue Cozy Truck Assembly Instructions Manual

Advertisement

Quick Links

1
-5
1
/
2
years
Fire Rescue Cozy Truck
ASSEMBLY INSTRUCTIONS
#654015MX1
Adult assembly required. Approx. assembly time: 50 min.
Look for video of assembly at
littletikes.com/videoinstructions
XIM654015-R1 - 8/21
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fire Rescue Cozy Truck and is the answer not in the manual?

Questions and answers

Summary of Contents for Little Tikes Fire Rescue Cozy Truck

  • Page 1 Fire Rescue Cozy Truck ™ ASSEMBLY INSTRUCTIONS #654015MX1 Adult assembly required. Approx. assembly time: 50 min. Look for video of assembly at littletikes.com/videoinstructions XIM654015-R1 - 8/21...
  • Page 2 • You will need a Phillips head screwdriver (power driver, recommended, not included) hammer and safety glasses (not included) to assemble the Fire Rescue Cozy Truck™. - When installing screws, be sure screws are tightened snugly, but do NOT OVERTIGHTEN.
  • Page 3: Battery Safety Information

    • Install batteries with the correct polarity (+ • Do not attempt to modify or repair this product. For and -). help contact Little Tikes Consumer Service. • Never fill with anything except clean tap water. Use • To avoid battery leakage: of other liquids may be harmful or damage the unit.
  • Page 4: Care And Storage

    The Little Tikes Company makes fun, high quality toys. We warrant to the original purchaser that this product is free of defects in materials or workmanship for one year * from the date of purchase (dated sales receipt is required...
  • Page 5 Some packages of hardware may have extras pieces. Questions? We’re here to help. Little Tikes customer service team at 1-800- 321-0183. Tools required (not included) Included in hardware pack (2). Discard after use.
  • Page 6 Door (1) Door latch (1) Roof Pillars - REAR Roof Pillars - FRONT Body (1) Roof pillars - Roof pillars - Roof pillars - Roof pillars - Roof (1) front right (1) front left (1) rear right (1) rear left (1) Rear axle (1) Grill (1) Logo (1)
  • Page 7 Front Wheel Axles Left Right Steering O-ring (1) Gas cap (1) Steering clip (1) Steering Wheel (1) NOTE: Distance Horn (1) from end to the notch on the “Left” axle is less than the notch on the “Right” axle. Floorboard buttons (2) Floorboard (1) Hose (1) Tray (1)
  • Page 8 Start with the steering decals! Before installing steering wheel, apply decals 11 & 12 to dashboard. Let’s get the horn working WARNING: Remove battery cover before pulling tab. Remove battery cover on horn (part U) Pull clear tab from horn unit to Snap horn (part U) into center of activate.
  • Page 9 Steering in a CLICK! Squeeze steering clip (part T) Steering clip should snap into MIDDLE into steering wheel (part S). hole on each side of the steering column. Insert steering wheel through hole in dashboard AND through the steering O-ring (part P). Make sure the steering clip snaps past the O-ring.
  • Page 10 Cap it! Insert gas cap (part Q). Floorboard needs buttons! Insert (2) floorboard buttons (part V).
  • Page 11 Ready...let’s get started! First, install door latch (part C) into door (part B) Attach using (1) " (1.27 cm) screw. " (1.27 cm) TO PERMANENTLY LOCK THE DOOR DOOR LOCKS AND Add (1) additional 1/2” (1.27 cm) screw UNLOCKS Next, insert door (part B) into body (part A).
  • Page 12 Roof and pillars match-up! BEFORE YOU START: match roof supports marked “L & R” to the correct side of roof also marked “L & R”. Roof Pillars - FRONT Roof Pillars - REAR...
  • Page 13 FRONT pillars...insert, pull back, turn! PUSH DOWN Line up the “R” on the front roof pillar (part E1) to the “R” on the roof (part D). Hook the rounded end in and push down. TURN PULL Turn the FRONT pillar around. Pull the FRONT pillar toward you to The side view mirror should be fully insert the pillar into the roof.
  • Page 14 REAR pillars...insert, pull back, turn! PUSH DOWN Line up the “R1” on the rear pillar (part F1) to the “R1” on the roof (part D). Hook the rounded end in and push down. Pull the REAR pillar, toward you to fully insert the pillar into the roof.
  • Page 15 Roof and pillars-cont. FRONT pillars...lock the door in place! Insert the front roof pillars and roof Insert the front roof pillars and roof on the body (part A). on the body (part A). Make sure LEFT pillar fits over door pin. To ease the assembly, it helps to place a drop or two of liquid dish soap onto the surface area...
  • Page 16 Rear pillars-get attached " (4.44 cm) Person 1: Hold down roof assembly. Person 2: Secure using (2) 1 " (4.44 cm) screws.
  • Page 17 Grill on the front...tailgate in the back First, turn the truck over and rest it on the roof. Logo plate MUST BE Attach grill (part G) to the body (part A). installed ONLY AFTER screws have been installed 1" (2.54 cm) Secure using (3) 1"...
  • Page 18 Grill & Tailgate...cont. " (4.44 cm) Secure using (2) 13/4" (4.44 cm) screws. FLIP TRUCK UPRIGHT THEN, snap Little Tikes logo (part I) into the grill.
  • Page 19 REAR wheels - give it a good hit! Do not hammer on surfaces or items you don’t want to top hat break, mar or dent. Top hat tool Place top hat (part AA) into top hat tool. Really give it a good hit! Insert the rear axle (part H) into the top hat.
  • Page 20 REAR wheels...get into the groove rear axle washer hubcap wheel bushing Slide onto rear axle (1) hubcap (M), (1) wheel (K), (1) rear axle bushing (DD) and (1) washer (BB). rear axle bushing washer Slide assembled axle through rear axle guides. Slide (1) washer (BB) then (1) rear axle bushing (DD) Slide wheel (K), then hubcap (M) onto axle.
  • Page 21 REAR wheels...last step. Flip the truck on its side. Place a top hat (AA) and the top hat tool over the OPEN end of the axle. Hammer the top hat onto axle. Top hat tool Do not hammer on Top hat surfaces or items you don’t want to break, mar or dent.
  • Page 22 FRONT wheels - check your axles Axles are NOT IDENTICAL. washer Left Right Slide onto LEFT front axle (L) (1) washer (BB), (1) wheel and (1) hubcap. NOTE: Distance from end to the notch on the “Left” axle is less than the notch on the “Right”...
  • Page 23 FRONT wheels...rolling along First, slide washer (BB), then bushing (CC) onto assembled right axle. REPEAT on left side. Then, insert FRONT wheels and axles. bushing washer Insert axle “R” Insert axle “L” (for right) into body. (for left) into body. Insert bushing (CC) onto each axle and push in place...
  • Page 24 IMPORTANT! Check axle positions - roll the Cozy Truck forward - HUBCAPS SHOULD BE STOP FACING OUTWARD. CORRECT WRONG...
  • Page 25 FRONT wheels...almost there Hammer (1) top hat (AA) onto each end of exposed RIGHT and LEFT axles. top hat Top hat tool Top hat corner -right (1) Match right “R” (part O1) top hat corners Insert and press into place. Secure using (1) 3/4"...
  • Page 26 Water tank & pump 1" (2.54 cm) Secure the tray (part X2) to the rear of TO AVOID INJURY: Fill tank the truck using (4) 1" (2.54 cm) screws. with clean tap water only. 1 gallon (3.78 L)
  • Page 27 Water pump operation Operation of Water Pump 5-10x 1. Check pump and hose collars: hand-tighten by turning clockwise. 2. Pump 5-10 times to pressurize tank. 3. Caution: to avoid injury, never aim water nozzle at face or eyes. 4. Press nozzle button to spray: release button to stop spray.
  • Page 28 LAST STEP...let’s finish with the decals! Decals must be applied to a clean, dry surface. Wipe clean with a dry rag before application. Remove air from under decals by applying pressure to the decals starting from the center, and work Decals are located in the bottom of the cardboard box.
