Attaching the seal
1. Clean the worktop around the cut out
area.
2. Attach the supplied seal stripe to the
lower edge of the hob along the outer
edge of the glass ceramic. Do not
extend it. Make sure that the ends of
Assembly
min.
500mm
3. Add some mm when you cut the seal
4. Push the two ends of seal stripe
min.
50mm
min.
28 mm
the seal stripe are located in the middle
of one side of the hob.
stripe to the length.
together.
R 5mm
0
490 mm
+1
270
55 mm
min.
20 mm
0
mm
+1
min.
12 mm
