CHALLENGE
18V Li-ion Pole Cordless Hedge Trimmer
Original Manual
M0E-9ET-410
Important
- Please read these instructions fully before starting assembly and using.
These instructions contain important information that will help you get the best from your pole
hedge trimmer, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 01904 727503
prior to returning product to store.
Aug 2016 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M0E-9ET-410 and is the answer not in the manual?

Questions and answers

Related Manuals for Challenge M0E-9ET-410

Summary of Contents for Challenge M0E-9ET-410

  • Page 1 CHALLENGE 18V Li-ion Pole Cordless Hedge Trimmer Original Manual M0E-9ET-410 Important - Please read these instructions fully before starting assembly and using. These instructions contain important information that will help you get the best from your pole hedge trimmer, ensuring it is assembled correctly and safely.

  • Page 2: Table Of Contents

    Contents Introduction ..............................3 Safety Information .............................3 Parts list ................................9 Assembly.................................10 Operation.................................14 Maintenance and Storage..........................16 Troubleshooting...............................17 Technical Data..............................18 Recycling and Disposal............................19 Guarantee................................20 Customer Helpline 01904 727503 www.gardenservicecentre.co.uk...

  • Page 3: Introduction

    Thank you for purchasing a CHALLENGE pole hedge trimmer. We hope you are completely satisfied with your new product and hope you will enjoy using this tool for many years. Your M0E-9ET-410 pole Hedge Trimmer has been designed for trimming light foliage and is intend for DIY use only.
  • Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings 9. Do not overreach. Keep proper footing and balance at all times. 10. Stay alert, watch what you are doing. Use common sense when operating the appliance. Do not operate the tool when you are tired.
  • Page 5 Safety Information Additional safety instructions for batteries and chargers Batteries 1. Never attempt to open for any reason. 2. Do not expose to water. 3. Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can explode in a fire.
  • Page 6 Safety Information Chargers 1. The charger’s plug must match the outlet. Never modify the plug in any way. Unmodified plug sand matching outlets will reduce risk of electric shock. 2. Use your charger only to charge batteries of the type supplied with your tool. Other batteries could burst, causing personal injury and damage.
  • Page 7 Safety Information Additional safety instructions for hedge trimmers 12. Always wear ear protection, goggles and a helmet during operating. 13. Always ensure that all guards are fitted when using the tool. Never attempt to use an incomplete tool or a tool with unauthorized modifications. 14.
  • Page 8 Safety Information Residual risks Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: 1.
  • Page 9 Safety Information Warning Symbols Do not expose to rain. WARNING! The device is not protected against electric shocks when it touches high- voltage lines! Maintain a safe distance of 10m from live electrical lines. Guaranteed Sound power level data (96dB) in accordance with Directive 2000/14/EC Warning symbols on the charger Before use, carefully read through the user manual.

  • Page 10: Parts List

    Parts list Parts description Working head Pole tube Blade cove Blade Main switch Battery pack Charger Charging station LED light Safety lock-off button Shoulder strap Connecting knob Customer Helpline 01904 727503 www.gardenservicecentre.co.uk...

  • Page 11: Assembly

    Assembly Preparing to assemble the pole hedge trimmer NOTE: Before assembling the tool, read the instruction book carefully. Charging the battery WARNING! The charger and battery pack are specifically designed to work together so do not attempt to use any other devices. Never insert or allow metallic objects into your charger or battery pack connections because an electrical failure and hazard will occur.
  • Page 12 Assembly Charging procedure Important charging notes Longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 18-24 C. Do not charge the battery pack in a very low or very high air temperature.
  • Page 13 Assembly Install the battery pack Warning! Always release the On/Off switch before insert in or removal of the battery pack. Remove the battery pack. Depress the button (A) on end of the battery pack, and then remove the pack from the tool. Install the battery pack.

  • Page 14: Operation

    Operation Switch ON/OFF WARNING! If any parts are missing, damaged or broken, do not operate your hedge trimmer until all damaged parts have been replaced or repaired. Failure to do so could result in serious personal injury. Switching the trimmer on: 1.
  • Page 15 Operation Function of swivel head Note: The cutter head can be locked in five positions(-45°, -22.5°,0°, 22.5°, 45°, 67.5°). Hold the handle (D) tightly. Push the lock button (E) and then turn the cutter head (F) to the desired position. Release the lock button (E) again and check whether the cutter head is locked in place.

  • Page 16: Maintenance And Storage

    Maintenance and storage Maintenance WARNING! Before any maintenance, always take off the battery pack and wear protection gloves. Lubrication of the blade For easier operation and longer life, lubricate the cutting blades before and after each use. Before lubricating, make sure your hedge trimmer is disconnected from the battery. Apply the oil (any kind of lubrication oil) so that it runs between the two blades.

  • Page 17: Troubleshooting

    Troubleshooting Troubleshooting Although your new cordless hedge trimmer is really easy to operate, if you do experience problems, check the following: If trimmer will not operate Check battery pack assembly; Charge the battery: operation of the hedge trimmer is dependent upon sufficient charge in the battery pack.

  • Page 18: Technical Data

    Technical data Technical Data Table Model M0E-9ET-410 Voltage 18V DC Battery type Lithium-Ion No load speed 1400/min Cutting length/capacity 410mm/14mm Battery pack Model ET-D1806 Battery type Lithium-Ion Battery capacity 1.5Ah Charging time Approx. 4 Hours Charger Model JLH122100400B Rated Voltage...

  • Page 19: Recycling And Disposal

    Technical data Noise and vibration data protection measures are necessary! The declared vibration value has been measured in accordance with a standard test method (according to EN 60745-1) and may be used for comparing one product with another. The declared vibration value may also be used in a preliminary assessment of exposure. This tool may cause hand-arm vibration syndrome if its use is not adequately managed.

  • Page 20: Guarantee

    Guarantee Dear Customer, In the unlikely event that your device develops a fault, please contact our Customer service department on the telephone number shown below. 1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. Claims must be accompanied by Proof of Purchase.
