CHALLENGE
250W Grass Trimmer
Original Manual
N1F-GT-220/250-C
Important
- Please read these instructions fully before starting assembly and using.
These instructions contain important information that will help you get the best from your grass
trimmer, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 01904 727503
prior to returning product to store.
Aug 2016 Rev A
