REORDER NO. ZZAN602
ANALOG TENS UNIT
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZZAN602 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BodyMed ZZAN602

Summary of Contents for BodyMed ZZAN602

  • Page 1 REORDER NO. ZZAN602 ANALOG TENS UNIT Instruction Manual...

  • Page 2: Table Of Contents

    17. Adjusting the Controls ............15 18. Battery Information .............. 18 19. Maintenance, Transportation and Storage of TENS Device ..............19 20. Safety Control ................ 19 21. Malfunctions ................20 22. Conformity to Safety Standards ..........20 23. Warranty ................20 Manufactured for BodyMed ®...

  • Page 3: Introduction

    CHAPTER 1 : INTRODUCTION EXPLANATION OF PAIN Pain is a warning system and the body’s method of telling us that something is wrong. Pain is important; without it abnormal conditions may go undetected, causing damage or injury to vital parts of our bodies. Even though pain is a necessary warning signal of trauma or malfunction in the body, nature may have gone too far in its design.

  • Page 4: Cautions

    CHAPTER 2 : CAUTIONS 1. Precautions: Isolated cases of skin irritation may occur at the site of electrode placement following long-term application. Effectiveness is highly dependent upon patient selection by a person qualified in the management of pain patients. 2. Contradictions: TENS devices can affect the operation of demand type cardiac pacemakers.

  • Page 5: Warnings

    CHAPTER 3 : WARNINGS 1. Caution should be used in applying TENS to patients suspected of having heart disease. Further clinical data is needed to show there are no adverse results. 2. The safety of TENS devices for use during pregnancy or birth has not been established.

  • Page 6: General Description

    CHAPTER 4 : GENERAL DESCRIPTION The ZZAN602 is a battery operated pulse generator that sends electrical impulses electrodes to the body and reach the nerves causing pain. The device is provided with two controllable output channels, each independent of each other. An electrode pair can be connected to each output channel.

  • Page 7: Technical Specifications

    CHAPTER 6 : TECHNICAL SPECIFICATIONS The technical specification details of ZZAN602 are as follows. MECHANISM TECHNICAL DESCRIPTION Channel Dual, isolated between channels Pulse Amplitude Adjustable, 0-80 mA peak into 500 ohm load each channel Pulse Rate Adjustable, from 2 to 150 Hz...

  • Page 8: Replaceable Parts

    MAIN PCB INTENSITY KNOB B-N-M SWITCH PULSE WIDTH KNOB PULSE RATE KNOB CHAPTER 8 : ACCESSORIES Each set ZZAN602 are completed with standard accessories and standard label as given below Ref. NO. DESCRIPTION Q’TY 40 X 4 0 mm Adhesive Electrodes 4 pcs.

  • Page 9: Graphic Symbols

    CHAPTER 9 : GRAPHIC SYMBOLS Note Operating Instructions Degree of Electrical Protection BF Do not insert the plug into AC power supply socket. Direct Current (DC power source) CHAPTER 10 : PARAMETER CONTROLS PULSE DURATION Wider pulse duration settings will deliver stronger stimulation for any given intensity setting.
  • Page 10 CHAPTER 10 : PARAMETER CONTROLS stimulating directly through the area of pain or localized enervation), a quick pulse rate (setting greater than 80Hz on the Pulse Rate Control) is desired. The patient should not perceive individual pulses but rather have the sensation of steady continuous stimulation.

  • Page 11: Attachment Of Electrodes Lead Wires

    CHAPTER 11 : ATTACHMENT OF ELECTRODE LEAD WIRES The wires provided with the system insert into the jack sockets located on top of the device. Holding the insulated portion of the connector, push the plug end of the wire into one of the jacks (see drawing); one or two sets of wires may be used.

  • Page 12: Electrode Options

    CHAPTER 13 : ELECTRODE OPTIONS The electrodes are disposable and should be routinely replaced when they start to lose their adhesive nature. If you are unsure of your electrode adhesive properties, order replacement electrodes. Replacement electrodes should be re-ordered through or on the advice of your physician to ensure proper quality.

  • Page 13: Tips For Skin Care

    CHAPTER 15 : TIPS FOR SKIN CARE To avoid skin irritation, especially if you have sensitive skin, follow these suggestions: Wash the area of skin where you will be placing the electrodes, using mild soap and water before applying electrodes, and after taking them off.

  • Page 14: Application Of Re-Usable Self Adhesive Electrodes

    CHAPTER 16 APPLICATION OF RE-USABLE SELF ADHESIVE ELECTRODES Application 1. Clean and dry the skin at the prescribed area thoroughly with soap and water prior to application of electrodes. 2. Insert the lead wire into the pin connector on the pre-wired electrodes. 3.

  • Page 15: Adjusting The Controls

    CHAPTER 17 : ADJUSTING THE CONTROLS 1. Slide Cover: A slide-on panel cover covers the controls for Pulse Width, Pulse Rate,Mode Selector and Modulation Selector. Your medical professional may wish to set these controls for you and request that you leave the cover in place.
  • Page 16 CHAPTER 17 : ADJUSTING THE CONTROLS 5. Mode Control Expose the controls by sliding front cover down from top of unit. This switch has 3 positions: B for Burst stimulation, N for Constant stimulation, and M for modulation stimulation. Push the Mode Selector until engaged in position desired.
  • Page 17 CHAPTER 17 : ADJUSTING THE CONTROLS 8. Timer Control Treatment time of TENS can be preset with Timer Control. This switch has 3 positions, 15, 30 and C(Continue). . Push the Timer Control until engaged in position desired. 9. Check/Replace the Battery: Over time, in order to ensure the functional safety of TENS, changing the battery is necessary.

  • Page 18: Battery Information

    CHAPTER 18 : BATTERY INFORMATION ZZAN602 can be used with a rechargeable battery when necessary. If you use rechargeable batteries, please follow the instructions. RECHARGEABLE BATTERIES (NOT INCLUDED) Prior to the use of a new unit, the rechargeable battery should be charged according to the battery manufacturer’s instructions.

  • Page 19: Maintenance, Transportation And Storage Of Tens Device

    -20˚ ~ +60˚, relative humidity 20% ~ 95% , atmosphere pressure 500 hPa ~ 1060 hPa. CHAPTER 20: SAFETY-TECHNICALCONTROLS For safety reasons, check your ZZAN602 each week based on the following checklist. 1. Check the device for external damage.

  • Page 20: Malfunctions

    60601-1:1990+A1:1993+A2:1995+A13: 1996 safety standards. CHAPTER 23 : WARRANTY All ZZAN602 models carry a warranty of one year from the date of delivery. The warranty applies to the stimulator only and covers both parts and labor relating thereto. The warranty does not apply to damage resulting from failure to follow the operating instructions, accidents, abuse, alteration or disassembly by unauthorized personnel.
