CC3000 Shield
Solder Arduino stackable headers or break away headers to the shield.
Header pins soldered onto the CC3000 Shield
Attach the shield to the Arduino.
CC3000 Shield on top of a RedBoard
CC3000 Breakout
Solder break away headers to the 9 header holes on the board.
Header pins soldered onto the CC3000 Breakout Board
Connect the breakout board to the following Arduino pins:
