- Page 1 Network Camera Quick Guide DC-D3233HRX / DC-D3233WRX DC-D3233RX / DC-D3233X Powered by...
-
Page 2: Safety Precautions
Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. -
Page 3: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements. - Page 4 Some parts may differ depending on the situation. Item Network Camera Open Source Guide Quick Guide DC-D3233HRX / DC-D3233WRX models Allen wrench ( only) Screws (3 ea.) DC-D3233HRX / DC-D3233WRX models Desiccant ( only)
- Page 5 DC-D3233RX / DC-D3233X Dome Cover Screw Hole Dome Cover Removal Groove Safety Wire Dome Cover Screws Dome Cover Assembly Notch Body DC-D3233HRX / DC-D3233WRX Dome Cover Screw Lens Hole SD Memory Card Slot IR LED Cover Side Cable Access Factory Reset Button...
-
Page 6: Camera Installation
Insert a flat-head screwdriver into the groove indicated by the triangle mark on the dome cover, Camera Installation and push down the screwdriver. Removing the Dome Cover DC-D3233HRX / DC-D3233WRX Loosen the screws counterclockwise using the allen wrench. Quick Guide... - Page 7 Inserting a SD Memory Card microSD Logo is a trademark of SD-3C, LLC. DC-D3233HRX / DC-D3233WRX Pull the hook and lift the cover to remove it. Insert a SD memory card into the SD memory card slot with the ‘micro SD’ print facing upward.
- Page 8 The camera may fall off if the wall or ceiling is not strong enough to support its weight. DC-D3233HRX / DC-D3233WRX Pull the hook and lift the cover to remove it. Attach the enclosed desiccant in the SD memory card slot cover to prevent moisture.
- Page 9 DC-D3233RX / DC-D3233X Closing the Dome Cover Use the screws, anchor provided with the camera DC-D3233HRX / DC-D3233WRX to secure the bottom cover on a wall or a ceiling. Attach the dome cover to the bottom cover. Match Use the provided guide pattern to check the dome cover assembly notch to the wall/ceiling the distance between the screws.
- Page 10 DC-D3233RX / DC-D3233X Angle Adjustment Attach the dome cover to the bottom cover. Press the area where the triangular mark meets the dome cover assembly hook to assemble the dome cover. Lens Rotation Horizontal Rotation Vertical Rotation DirectIP NVR makes it easy to use cameras without extra network configurations. •...
- Page 11 Specifications Vandal Resistance Yes ( DC-D3233HRX / DC-D3233WRX only) Out-door Ready DC-D3233HRX / DC-D3233WRX DC-D3233HRX IP66 ( only), Heater ( only) Operating DC-D3233HRX -40°C ~ +50°C (-40°F ~ +122°F) Temperature DC-D3233WRX / DC-D3233RX / -10°C ~ +50°C (+14°F ~ +122°F)
- Page 12 IDIS Co., Ltd. For more information, please visit www.idisglobal.com...
