Start Your Installation

Please follow these instructions so that you can hook up the cables to associated connectors.
1. Lay the LCD fl at on an even surface and take off cable cover as seen in the step 1 diagram.
2. Connect the cables to the appropriate connectors as seen in the step 2 diagram.
3. Take screw from the accessory box, and put all cables under the cover lip, then use a
Philips Head screw driver, insert the screw (CBM M3x6) into cable cover and monitor as
seen in the step 3-1 or step 3-2 diagram either.
Step 3-1
Step 1
Step 2
Power
DVI
VGA
Audio-In
7
USB
COM-Out
COM-In
Audio-Out
Step 3-2
