Functions

4.1

Master unit

3
4
5
6
7
8
9
1 OPEN button
2 SD/MS/MMC card slot
3 Master power switch
4 Headphone jack
5 AV OUT connection
6 COAXIAL output
7 USB slot
2 1
10 11 12 13
8 DC OUT 9-12 V connection
9 DC IN 9-12 V connection
10 ENTER button
11 Arrow buttons
12 SOURCE button
13 LCD display
ACVDS736
