- Page 1 March Networks 8704 S Hybrid NVR (Gen 2) Installation Guide...
- Page 2 Copyright © 2021. March Networks Corporation. All rights reserved. Information in this document is subject to change without notice. MARCH NETWORKS, March Networks Command, March Networks Searchlight, March Networks RideSafe, and the MARCH NETWORKS logo are trademarks of March Networks Corporation. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Power Ratings ........................12 Video Inputs ......................... 13 Video Capture Rates......................14 Analog Camera Video Inputs ................... 14 FPS Values for Analog Camera Inputs ................. 14 IP Camera Video Inputs ....................14 8704 S Hybrid NVR (Gen 2) Installation Guide... - Page 4 Hard Drive Details......................23 NiCd Battery Pack and Lithium Battery................24 NiCd Battery Pack ......................24 Lithium Battery ........................24 Chapter 3: Unit Setup..............25 Mounting the Recorder ......................25 Wall-Mounting........................26 Desk-Mounting ........................28 Installing Hard Drives ......................29 Installation Requirements....................29 8704 S Hybrid NVR (Gen 2) Installation Guide...
-
Page 5: Chapter 1: Mandatory Regulations
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Europe This equipment complies with the following EU directives: 2014/30/EU, 2014/35/EU, and 2011/65/EU. A Declaration of Conformity is available upon request. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 6: Environmental Directive Compliance
Battery Notices CAUTION: There is risk of explosion if any battery is replaced with another battery of the incorrect type. Ensure that you only use the NiCd battery pack and lithium battery provided by March Networks. NiCd Battery Pack Notice The unit contains an internal NiCd battery pack that is used during power shortages. -
Page 7: Avis Sur La Batterie Lithium
L’unité a un chargeur de batterie intégré. N’utiliser pas un autre chargeur pour charger le bloc de batterie. • Remplacer seulement avec les blocs de batterie de marque March Networks. • Ne pas modifier le bloc de batterie NiCd. •... -
Page 8: Ground Connection
Shipment of the unit and components may expose the unit to temperature extremes. We recommend you allow the unit to return to room temperature prior to operation. Model Definition Information The HNVR LS is the regulatory model for the 8704 S Hybrid NVR. Certification Regulatory Model Includes the following NVR... -
Page 9: Chapter 2: Feature Overview
This NVR offers outstanding video compression and storage, and can be managed using either the March Networks Command or the Visual Intelligence video management platforms. Note: You should familiarize yourself with the differences between the platforms prior to deploying the recorders. -
Page 10: Key Features
• Internal back-up battery for power brown-out protection. • Advanced networking features for unlimited scalability and dependable remote access. • Advanced health management features for centralized support and maximum up-time. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 11: Packaging/Shipment Contents
• Data and power cables for the hard drives • Software DVD — The software can also be downloaded from the March Networks Partner Portal. • Technical publications — Included on the software DVD, or you can also download hardware and software technical publications from the March Networks Partner Portal. -
Page 12: Specifications
The recorder has an external power supply. • Power input: 100-240 volts AC input (auto-sensing) • Current rating: 1.7 A • Frequency range: 50-60 Hz • Power consumption: 15 W typical, 20 W maximum 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 13: Video Inputs
Video Termination Video termination for the 8704 S is controlled through the Visual Intelligence software. You can use the March Networks Administrator Console application to view and modify the analog video termination. For more information, see the Administrator Console User Manual or online Help. -
Page 14: Video Capture Rates
The 8704 S provides a capture rate of up to 3 mbps and 30 FPS per attached IP camera for 4 cameras (a total of 12 mbps of inbound traffic from 4 IP cameras). • 4 channels at 3 mbps = 12 mbps 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 15: Front Panel Leds
For more information, see the Command Enterprise User Guide or the Administrator Console User Manual, available from the March Networks Partner Portal website. 8704 S Hybrid NVR (Gen 2) Installation Guide... - Page 16 Command or Visual Intelligence). For more information, see the Command Enterprise User Guide or the Administrator Console User Manual, available from the March Networks Partner Portal. 8704 S Hybrid NVR (Gen 2) Installation Guide...
-
Page 17: Rs-232 Interface
The RS-232 interface allows you to provide text capture, with the following pins: Input Ground Output Definition You can also use this to control a PTZ camera with an RS-232 to RS-485 converter. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 18: Alarm And Switch Terminals
Depending on the switch’s default state, connect the normally-open or normally-closed wire to the normally-open (NO) or normally-closed (NC) terminal, respectively. After you connect the alarm and/or switch devices, you can turn on the unit. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 19: Audio Terminals
(whether intercom or speaker) includes a built-in amplifier. Audio Out pin 1 is the signal for audio output channel 1. Connect the return to the “G” beside the audio output. Output specification: unbalanced, 600 Ω, 1Vp-p (line level) 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 20: Ethernet Ports And Usb Ports
Command Enterprise Console, you must ensure that the primary network address is listed first in the Published Addresses list (at the top of the list). For more information, see the Command Enterprise Installation Guide, available from the March Networks Partner Portal website. Ethernet port LEDs Each Ethernet port has colored LEDs that indicate the connection status. -
Page 21: Power Connection
For the unit’s power ratings, see “Specifications” on page 12. Power Supply The unit is powered by an external 12 volt DC power supply. • Brand: XP Power • Model: VEC65US12-XD0632A 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 22: Ground Connection
NVR and must ensure that anti-static precautions are taken. Connecting the ground wire to the NVR ground stud Ground wire from earth ground source (18 gauge) Keps nut NVR ground stud 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 23: Hard Drives
One or two internal hard drives can be installed in each recorder. For information about installing hard drives, see “Installing Hard Drives” on page 29. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 24: Nicd Battery Pack And Lithium Battery
ATTENTION : Avant de remplacer les piles, lisez les « Avis pour les batteries » à la page 6. Utilisez uniquement des piles approuvées dans l'appareil. Avant de remplacer les piles, éteignez l'unité. Assurez- vous que les voyants LED à l'avant de l'unité s'éteignent avant de retirer le couvercle. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 25: Chapter 3: Unit Setup
Then, specify basic device configurations using the March Networks Administrator Console. The Administrator Console application is included on the provided software DVD. For more information, see the Administrator Console User Manual, available for download from the March Networks Partner Portal. -
Page 26: Wall-Mounting
Left Right Top view of unit bracket bracket Left bracket screws circled Right bracket screws circled Left side view of unit Right side view of unit 8704 S Hybrid NVR (Gen 2) Installation Guide... - Page 27 Remove the recorder from the mounting screw and put it aside. Install the left mounting screw at the marked location. • If the left mounting location is in a wall stud, thread the screw directly into the wall stud. 8704 S Hybrid NVR (Gen 2) Installation Guide...
-
Page 28: Desk-Mounting
ATTENTION : Pour garantir que l'unité respecte la température de fonctionnement recommandée, l'unité doit être montée sur un bureau dans un endroit qui garantit qu'elle est dégagée de tous les côtés. 8704 S Hybrid NVR (Gen 2) Installation Guide... -
Page 29: Installing Hard Drives
The cover screws are located on the sides of the unit at the bottom (see illustration below). Note: Set these screws aside - you will use them to re-attach the cover. cover Screw (right side) 8704 S Hybrid NVR (Gen 2) Installation Guide... - Page 30 Note: Set the screws aside - you will use them to re-attach the bracket. Screws to secure the hard drive in the bracket 2 screws visible for hard drive bracket 8704 S Hybrid NVR (Gen 2) Installation Guide...
- Page 31 When all the hard drives that you require are installed, close the cover of the recorder unit and secure it with the two (2) screws. Use 4.3 in-lbs (inch pounds) of torque. 8704 S Hybrid NVR (Gen 2) Installation Guide...
- Page 32 The SATA standard is based on serial signaling technology. SMART Self-Monitoring Analysis and Reporting Technology. An interface between the recorder and the hard drive. Universal serial bus. An interface between the recorder and add-on devices. 8704 S Hybrid NVR (Gen 2) Installation Guide...
- Page 33 Companies worldwide use our software solutions to improve efficiency and compliance, reduce losses and risk, enhance customer service and compete more successfully. With deep roots in video security and networking, March Networks is also recognized as the leader in scalable, enterprise-class video management and hosted services.
