- Page 1 6X6 AUDIO DISTRIBUTION ACCESSORY VANCO PART NUMBER PA66ACCS Accessory kit for PA66MK2 Audio Distribution Amplifier vanco1.com | 800.626.6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE UNITED STATES TO VERIFY PERFORMANCE PARAMETERS. -
Page 3: Package Contents
Accessory Kit for PA66MK2 Part # PA66ACCS PACKAGE CONTENTS • Remote Control • Keypad Connection Hub and Decora Wall-plate • Keypad Mounting Hardware • Keypad hub • (6) PoE Keypads with built-in IR RX and decora wall plates • Product Manual... - Page 4 KEYPAD 1. Numeric LED Display 2. IR Receiver Target 3. Selection and Status LEDs 4. Power/Status. Press and Hold to Turn Zone ON/OFF. When ON, Press to toggle through settings 5. Increase Volume, Treble or Bass 6. Decrease Volume, Treble or Bass 7.
-
Page 5: Remote Control
REMOTE CONTROL 1. Power: switches power (On/Off) for the certain zone. 2. Mute: allows you to mute a certain zone. 3. BAL: These L & R buttons can adjust the balance of L/R channel in stereo mode. 4. VOL: Volume adjustment 5. - Page 6 The PA66ACCS comes with six POE enabled keypads. This allows for source control from each specific zone as well as IR routing to the appropriate source devices once selected. The PA66ACCS also comes with a hub that allows for all six keypads to be connected to the PA66MK2 amplifier via Cat5e/6.
- Page 7 Connect the other end of the Cat5e/6 to the lone RJ45 port found on the front side of the Keypad Hub. The front is what fits into the provide decora plate. Note that the Cat5e/6 between the unit and the hub should only be between 7-10ft.
- Page 8 TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800- 626-6445. You can also email technical support issues to techsupport@ vanco1.com When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call.
-
Page 9: Limited Warranty
LIMITED WARRANTY With the exceptions noted in the next paragraph, Vanco warrants to the original purchaser that the equipment it manufactures or sells will be free from defects in materials and workmanship for a period of two years from the date of purchase. - Page 10 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 | fax: 630.879.9189 visit: www.vanco1.com...
