Installing The Stainless Steel Handle; Operating Your Appliance; Control Panel - Summit Professional SPR628BCSS Instruction Manual

5. Screw the alternative left top hinge (6), included in the fittings,
3)
6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left
designated position and tighten it after the door is leveled.
7. Remove the handle from the left side of the door and install it on the right side. (See next section.)

INSTALLING THE STAINLESS STEEL HANDLE

This appliance includes a stainless steel handle that is not required
to operate the unit. To install the handle, follow the instructions
below:
1. Remove the door gasket (2) on the side you wish to install the
handle - you can see two designated holes for handle installation.
2. Install the handle (4) tightly as shown above with two screws (1)
and flat washers (3) provided.
3. Replace the door gasket.
It is recommended that you install the appliance in a place where the ambient temperature is between 72º
and 78ºF (23º to26ºC). If the ambient temperature is above or below the recommended temperatures, the
performance of the unit may be affected. For example, placing your unit in extremely cold or hot conditions
may cause interior temperatures to fluctuate. The operating temperature range may not be reached.

CONTROL PANEL

ON/OFF Power
To turn the appliance off, press and hold the
off. To turn the appliance on, press and hold the
lights up.
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.
LIGHT
To control the inner light.
UP
Used to increase (warm) the set temperature by 1°C/1ºF.
DOWN
Used to decrease (cool) the set temperature by 1°C/1ºF.
ºF/ºCSelector
Select the temperature display in Fahrenheit or Celsius degrees. To change the temperature from

OPERATING YOUR APPLIANCE

on the left hand side of the cabinet. (Fig.
key for 5 seconds until the temperature display goes
key for 1 second until the temperature display
