FROST-FREE REFRIGERATOR
Model Nos.
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial Number (on lower left corner of
inside cabinet) here:
_______________________
Serial No.:
INSTRUCTION MANUAL
SPR628BCSS / SPR629WCSS
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit Professional SPR628BCSS
Summary of Contents for Summit Professional SPR628BCSS
- Page 1 FROST-FREE REFRIGERATOR INSTRUCTION MANUAL SPR628BCSS / SPR629WCSS Model Nos. BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial Number (on lower left corner of An ISO 9001:2015 registered company inside cabinet) here:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handle Operating Your Appliance 8-10 Control Panel Sabbath Mode Temperature Memory Function... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 - Avoid open flames and anything that creates a spark, - Disconnect from the power supply, - Air the room in which the appliance is located for several minutes and - Contact the Service Department for advice. The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up.
-
Page 5: Location Of Parts
LOCATION OF PARTS Digital Control Panel Stainless Steel Door LED Light Shelves (3) Door Racks (2) Security Lock Kick-plate Adjustable Legs... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE Remove the exterior and interior packing. Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. Clean the interior surface with lukewarm water using a soft cloth. -
Page 7: Extension Cord
overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end. -
Page 8: Installing The Stainless Steel Handle
5. Screw the alternative left top hinge (6), included in the fittings, on the left hand side of the cabinet. (Fig. 6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left designated position and tighten it after the door is leveled. 7. -
Page 9: Sabbath Mode
Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Setting the Temperature Control You can set the temperature by touching the UP and DOWN symbols. When you push either of the two buttons for the first time, the LED readout will show the original temperature set previously. (The temperature preset at the factory is 38°F, or 3°C.) The temperature you are setting will increase by one degree each time you touch the UP symbol, and will decrease by one degree each time you touch the DOWN symbol. -
Page 10: Defrosting
tray by the compressor where it evaporates. However, frost may accumulate on the evaporator if the unit is repeatedly opened in a high heat or high humidity location. If this frost pattern does not clear within 24 hours, your unit will require manual defrosting. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR APPLIANCE Turn off the power, unplug the appliance, and remove all items, including shelves. Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). Wash the shelves with a mild detergent solution. -
Page 12: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power Connect the appliance. - Page 13 “E0”indicates a communication error for Call for service. 3-zone models. Display “E0”, “E1” or “E2” indicates that the air “E1”. “E2”, temperature sensor has failed. “E3”, “E4”, “E3” or “E4”indicates that the defrost “E5” or “E7”. sensor in the evaporator has failed. “E5”...
- Page 14 NOTES...
- Page 15 NOTES...
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
