Sonatest Microgage III Series Quick Start Manual

The new portable precision thickness gauge range from
Sonatest Ltd, the Microgage III series, is available with
choice between monochrome and colour displays, with or
without A-Scan capability. All instruments across the range
a field upgradeable, allowing the operator to opt for further
features further down the line, without returning the instru-
ment to the factory.
The variety of features offered by the Microgage III series
allows the user to select a quality tool that will exceed their
application needs. The Echo-to-Echo capability allows the
measurement of the thickness of materials without removing
paint or coatings.
Designed with the user in mind, the Microgage III utilises
state-of-the–art digital technology to produce fast and ac-
curate readings. Available in 7 models including basic (B),
datalogging (DL), with and without waveform(W) with mono-
chrome or colour (C) displays.
Features include:
•
0.0001 resolution.
•
30 MHz bandwidth.
•
Sunlight readable.
•
Zoom auto tracking.
•
Live A-scan (colour optional).
•
Storage and recall of set ups.
•
Datalogger 100,000 readings.
•
Vibration and colour change with alarm.
•
Multiple Modes for challenging applications.
•
Real-Time adjustment of initial gain, slope,
range, rectification, zoom and blankings.
•
Languages include: English, German, French,
Uses colours based on alarm system. Red= below minimum Yellow = caution Green = good
All software options are field upgradeable, no need to return to factory.
Microgage III Series
Monochrome or Colour Displays
Applications include:
Fibreglass Thickness (boats), Coil Steel,
Titanium (golf club heads), Rubber Tyres,
Thin Walled Components,
Aerospace applications,
Plastics Manufacturing.
B-Scan Feature
Included with DL version.
Cross sectional view of test piece.
Enter Maximum Thickness.
Saves B-Scan in DL.
Easy to review.
Shows all readings in review mode.
Interfaces with Data XLS software.
