Whalen WSF48SY26C Assembly Instructions Manual

Whalen WSF48SY26C Assembly Instructions Manual

Shelby 48in fireplace console

Advertisement

Quick Links

Shelby 48in Fireplace Console
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Model # WSF48SY26C
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-06-05
# WSF48SY26M
1-866-942-5362
Rev. 0001-B
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the WSF48SY26C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whalen WSF48SY26C

  • Page 1 LOT NUMBER: DATE PURCHASED: / Shelby 48in Fireplace Console Model # WSF48SY26C # WSF48SY26M ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
  • Page 2: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 3 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. B- Fixed Shelf (Qty. 1) A- Top Panel (Qty. 1) C- Bottom Panel (Qty. 1) D- Left Lower Side Panel (Qty. 1) E- Right Lower Side Panel (Qty.
  • Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. V- Firebox Support W- Upper Side Panel Molding Fireplace Insert Remote Control with Battery (Qty. 1) (Qty. 2) (Qty.
  • Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw the Cam Bolts (2) into the designated small holes on the Fixed Shelf (B), Bottom Panel (C) and Lower Partition Panels (F and G) using a Phillips screwdriver, as shown in the illustration.
  • Page 7 Assembly Instructions 5. Align and attach the Base Rear Stretcher (O) to the Bottom Panel (C) with two Wood Dowels (3) and three Cam Locks (1), as shown. 6. Align and attach the Base Front Molding (L) to the Bottom Panel (C) with two wood dowels (3) and three cam locks (1).
  • Page 8 Assembly Instructions 7. Align and attach the Middle Left Stile (J) to the Left Lower Partition Panel (F) with two Wood Dowels (3) and three Cam Locks (1). 8. Repeat the same procedure to combine the Middle Right Stile (K) and the Right Lower Partition Panel (G) together.
  • Page 9 Assembly Instructions 10. Securely screw the Cam Bolts (2) into the designated small holes on the Left and Right Side Panels (D and E) using a Phillips screwdriver. 11. Glue three Wood Dowels (3) into the inner holes on Left Bottom Molding (M) and fasten it to the Left Lower Side Panel (D) with six 1-1/2”...
  • Page 10 Assembly Instructions 13. Glue six Wood Dowels (3) into the large holes of the assembled base at both ends. 14. Align the large holes on the Left Lower Side Panel (D) with the inserted Wood Dowels (3) on the assembled base. Firmly press them together and fasten it in place by engaging three Cam Locks (1). 15.
  • Page 11 Assembly Instructions 17. Glue eight Wood Dowels (3) into the inner holes on the top edges of the Lower Side Panels and Partition Panels (D, E, F and G). 18. Ask for assistance to position the Fixed Shelf (B) onto the inserted Wood Dowels (3) with the middle crossbar facing forward.
  • Page 12 Assembly Instructions 22. Securely screw six Cam Bolts (2) into the designated small holes on the Fixed Shelf (B) using a Phillips screwdriver. 23. Securely screw two Cam Bolts (2) into the designated small holes on one Upper Side Panel Molding (W) using a Phillips screwdriver.
  • Page 13 Assembly Instructions 26. Glue five Wood Dowels (3) into the large holes on the Fixed Shelf (B). Attach the assembled Upper Side Panels (P) and Partition Panel (H) to the Fixed Shelf (B) by engaging six Cam Locks (1). 27. Securely screw six Cam Bolts (2) into the designated small holes on the Top Panel (A) using a Phillips screwdriver.
  • Page 14 Assembly Instructions 28. Glue 5 Wood Dowels (3) into the top inner holes of the Upper Partition Panel (H) and Side Panels (P). Position the Top Panel (A) onto the inserted Wood Dowels (3) and fasten it in place with 6 Cam Locks (1). 29.
  • Page 15 Assembly Instructions 31. Insert four Shelf Supports (13) into the holes at the desired height inside each compartment. Tilt and rest the Adjustable Shelves (S) onto the Shelf Supports (13). NOTE: The doors are shipped with Wood Door Panel. You can keep the doors as they are or interchange with the Door Glass Insert (R) depending on your configuration.
  • Page 16 Assembly Instructions 33. Extend the Door Hinges (18) and rest the hinge cups onto the cutouts of one Door Panel (Q). Secure the Door Hinges (18) in place by using two 5/8” Zinc Screws (9) in each. 34. Attach one Knob (14) to the front side of the Door (Q) with one Knob Bolt (15). 35.
  • Page 17 Assembly Instructions 39. Plug the Cam Lock Covers (12) onto the visible cams locks to conceal the cams. 40. Stick the Rubber Bumpers (16) on the outer corners of the Doors (Q) where they meet with the partition panels (F and G). 41.
  • Page 18 Assembly Instructions 42. Align and attach the Firebox Support (V) to the Bottom Panel (C) by inserting two 2” Self-tapping Screws (10) through the countersunk holes and screw into place. NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console.
  • Page 19 Assembly Instructions Wooden Stud Wall Short Screw Wall Long Screw Metal Bracket Floor Leveler Tools required (not provided): Phillips screwdriver, stud finder, power drill and 1/8” in drill bit. 45. Ask for assistance to position the assemble fireplace at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Base Front Molding (L) to level the unit.
  • Page 20: Care And Maintenance

    Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...

This manual is also suitable for:

Wsf48sy26m
