Hanging Straps
Figure 4: Two mounting plates installed
Note: Check that both FW-MPs are level as per the FLEXware Mounting Plate Installation Manual. If
space is restricted, the FW-MPs can be installed vertically.
With the Mounting Plate and the hanging screws (for the FX Series Inverter/Chargers) installed,
install the FXs.
• Start with the top FX.
• Hang the FX on the hanging screws, but continue to hold onto it.
• Loosely install four M6 X 20 mm screws, included with the FW-MP, one in each corner; tighten
them when all four are installed and the FX is aligned.
• Install the remaining FXs in the same manner.
6
