Figure 8: AC and DC Chassis mounted
With each chassis loosely mounted, the AC Conduit Adapter (ACA) and DC Conduit Adapter (DCA)
are installed on the FX.
• Remove the clear plastic AC cover and AC Conduit Plate from each FX.
Clear plastic AC cover
AC Conduit Plate
Figure 9: FX Series Inverter/Charger
DC Wiring
Cover (DCC)
10
