MX60 Installation
A FLEXware 1000 System installation includes up to four MX Charge Controllers which can be
mounted on both the top and side of the FW1000-DC. Newer MXs have rear knockouts allowing
them to be mounted directly to the side of the enclosure without the need for additional
mounting brackets. Mounting brackets are required for top installation of all MX models and for
side installation of less recent models..
Bracket screw locations are
shown below
Figure 12:
MX Charge Controller mounting options
13
Screw locations for directly attaching an
MX Charge Controller are shown below
