IAdea XDS-1078-A9 Quick Start Manual

Content Management
Please consult the Solution Store documentation for information
specific to your content management solution.
QR: https://support.iadea.com/hc/en-us/articles/360041795652
Troubleshooting
How do I interrupt playback and enter setup menu?
Use USB mouse to click and hold one corner of the screen for 10 seconds to exit
playback and enter setup menu.
How do I provide a DEBUG log for a misbehaving signboard to the support team?
Please follow the instructions below to collect the player's DEBUG log:
1 Prepare a blank USB stick in FAT-32 format.
2 Create a folder named "DEBUG" (case insensitive) in the root of USB stick.
3 Make sure the player is operating (see welcome screen or playing content).
4 Insert the USB stick into player and wait for
5 Within the "DEBUG" folder, is a folder with a string of number as its name. If
the string of numbers are all zero's, the debug log has not been collected
properly. Repeat step 1-4 again and make sure to wait
6 Zip the"DEBUG" folder and send to IAdea Support Team.
Reseting smart signboard to factory default
Factory reseting the smart signboard will result in the removal of all saved con-
to complete the smart signboard factory reseting process:
1 Use a pen to press and hold the reset button - do not release until Step 4.
2 Insert the power cord.
3 Wait 30 seconds for the system reboot indicating your data is erased.
4 Release the reset button and your smart signboard will initialize in factory
default state.
IAD_DGS_X7S_60EP
XDS-1078-A9
Quick Start Guide
This is a quick walkthrough of the set up process. For complete documentations
and quick start guides, please visit http://support.IAdea.com.
Box Content
Mounting and Installation
Mounting option 1: VESA mount
- VESA standard: VESA MIS-D75 (75 mm x 75 mm)
- Screw: M4 x 4 mm (excluding the mounting plate thickness)
Mounting option 2: using back cover
- Power / SD card brackets MUST NOT be connected when mounting cover
- plate
.
Mounting option 3: glass mount
- 3M VHB™ Industrial Heavy Duty Mounting Tape (90 mm x 70 mm)
Mounting back cover
1) Release the cover
plate screw to
release cover plate
Smart
signboard
2) Install cover plate 3) Run power and network
(thread head height cable from the bottom
not to exceed 3 mm) and connect to signboard
before mounting
Power and micro
SD card brackets
