Viking Use/Installation Guide
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information
call 1-888-VIKNG1 (845-4641)
or visit the Viking Web Site at
vikingrange.com
Undercounter/Freestanding Refrigerated
Beverage Centers
F20725A EN
(071610)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VUAR143TRSS and is the answer not in the manual?

Questions and answers

Related Manuals for Viking VUAR143TRSS

Summary of Contents for Viking VUAR143TRSS

  • Page 1 All manuals and user guides at all-guides.com Viking Use/Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information call 1-888-VIKNG1 (845-4641) or visit the Viking Web Site at vikingrange.com Undercounter/Freestanding Refrigerated Beverage Centers F20725A EN (071610)

  • Page 2: Important - Please Read And Follow

    MUST BE INSTALLED IN AN AREA PROTECTED FROM THE ELEMENTS, SUCH AS WIND, RAIN, WATER (SPRAY OR • Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which DRIP). are not installed properly or do not meet the requirements below.
  • Page 3 All manuals and user guides at all-guides.com SPECIFICATIONS/DIMENSIONS Front View SPECIFICATIONS/DIMENSIONS Front View PROFESSIONAL - 15” W. Models DESIGNER - 15” W. Models B B a a s s i i c c E E l l e e c c t t r r i i c c D D a a t t a a B B a a s s i i c c E E l l e e c c t t r r i i c c D D a a t t a a •115 VAC/60 Hz •115 VAC/60 Hz...

  • Page 4: Front View

    All manuals and user guides at all-guides.com SPECIFICATIONS/DIMENSIONS Front View SPECIFICATIONS/DIMENSIONS Front View PROFESSIONAL - 24” W. Models DESIGNER - 24” W. Models B B a a s s i i c c E E l l e e c c t t r r i i c c D D a a t t a a B B a a s s i i c c E E l l e e c c t t r r i i c c D D a a t t a a •115 VAC/60 Hz •115 VAC/60 Hz...

  • Page 5: Material Type

    All manuals and user guides at all-guides.com Custom Wood Frame Installation Instructions (DFUR Model) Custom Wood Frame Installation Instructions (DFUR Model) (cont.) Note: Weight of wood panel must not exceed 20 lbs. Step 1: Verify door alignment The door should be parallel to the sides and top of the refrigerator. If alignment is necessary the door may be adjusted by loosening the 2 screws which secure the hinge adapter brackets to the door and adjusting the door side to side.
  • Page 6 All manuals and user guides at all-guides.com Custom Wood Frame Installation Instructions (DFUR Model) Custom Wood Frame Installation Instructions (DFUR Model) (cont.) (cont.) Step 7: Secure overlay panel to the door With the #8 wood screws provided, fasten the overlay panel to the door. (See Figure 3). Step 8: Install door gasket Press the door gasket into the door channel.

  • Page 7: Leg Leveler Installation

    WARNING Failure to follow these instructions could result in fire or electrical shock. WARNING NOTE Please contact your Viking Range Light Do not lay unit on top, side, back, or front. If unit is accidentally laid in Green Corporation parts distributor or dealer to order...

  • Page 8: Setting The Controls

    All manuals and user guides at all-guides.com SETTING THE CONTROLS The temperature of the refrigerated beverage center ranges from 40ºF to 65°F (4ºC to 18ºC). TruProtect ™ “Basic” Function “Quick” Reference Solid Door Models: Glass Door Models: TruProtect System TruProtect System ˚...

  • Page 9: Cleaning And Maintenance

    All manuals and user guides at all-guides.com SETTING THE CONTROLS (cont’d) Stainless Steel Parts All stainless steel parts should be wiped regularly with hot soapy water. Use a liquid cleaner designed for stainless steel when soapy water will not do the job. Do not use steel wool, abrasive cloths, cleansers, or powders. Do not permit FOR OUTDOOR UNITS - it is recommended that in temperatures above 110ºF (43.3ºC) and below 40ºF (4.4ºC) the unit citrus or tomato juice to remain on stainless steel surfaces, as citric acid will permanently discolor stainless steel.

  • Page 10: Service Diagnostics

    All manuals and user guides at all-guides.com SERVICE DIAGNOSTICS TruProtect ™ “Advanced” Function “Quick” Reference Solid Door Models: Glass Door Models: TruProtect System TruProtect System ˚ WARMER ˚ ˚̊ WARMER F /C POWER FAILURE - Flashing Amber POWER FAILURE - Flashing Amber HIGH/LOW TEMP - Red HIGH/LOW TEMP - Red COLDER...

  • Page 11: Service Information

    For the name of your nearest authorized Viking Range Corporation service agency, call the dealer from whom the product was purchased or Viking Range Corporation. I I M M P P O O R R T T A A N N T T : : Retain proof of original purchase to establish warranty period.
  • Page 12 For the name of your nearest authorized Viking Range Corporation service agency, call the dealer from whom the product was purchased or Viking Range Corporation. I I M M P P O O R R T T A A N N T T : : Retain proof of original purchase to establish warranty period.
