- Page 1 SERVICE MANUAL Undercounter Refrigerator Drawer Units Models VURD140 DURD140 DFRD140 VIKING Preferred Service 1803 Hwy 82 West, Greenwood, Mississippi (MS) 38930 USA 662-455-1200...
- Page 2 “WARNING” or “CAUTION”. These words mean: CAUTION DANGER VIKING will not be responsible for any injury or property damage from improper service procedures. IMMEDIATE HAZARDS WHICH WILL RESULT IN If performing service on your own product, you SEVERE PERSONAL INJURY OR DEATH.
-
Page 3: Starting Out
S TA RT I N G O U T Remove Packaging Your drawer refrigerator has been packed for ship- ment with all parts that could be damaged by movement securely fastened. Before installing the drawer refrigerator, be sure all packing materials and tape have been removed. - Page 4 I N S TA L L AT I O N Select Location The proper location will ensure peak perform- ance of your drawer refrigerator. Choose a loca- tion away from heat and out of direct sunlight. Best performance will be maintained when installed within the following parameters: Electrical Connection Ideal Ambient Temperature Range...
- Page 5 F E AT U R E S Control Panel The temperature of your drawer unit ranges from 32°F to 47°F (0°C to 8°C. The temperature can be TEMPERATURE CONTROL adjusted using the control panel located on the inside of the top drawer. To change the tempera- ture setting, press the warmer or cooler pads until the display shows the desired temperature.
- Page 6 C A R E A N D C L E A N I N G O F Y O U R D R AW E R R E F R I G E R ATO R Condenser The condenser tubing inside the cabinet does not require frequent cleaning;...
-
Page 7: Full Overlay Panel Installation Instructions
FULL OVERLAY PANEL INSTALLATION INSTRUCTIONS Step 1: Wood Screws Required 1. A #8 pan head wood screw should be used to properly secure the overlay panel. A total of 8 screws will be needed. 2. Use only pan head screws. 5/16 PHILLIPS HEAD SCREWS HOLDING DRAWER FRONT 3. - Page 8 FULL OVERLAY PANEL INSTALLATION INSTRUCTIONS Step 3: Sizing the Overlay Panel 23.63 14.63 15.19 7.59 11.81 23.06 Step 6: Step 4: Reinstall the Drawer Attaching the Overlay Panel to the Door 1. Fully extend drawer slides and place drawer on 1.
-
Page 9: Troubleshooting
T R O U B L E S H O O T I N G PROBLEM POSSIBLE CAUSE CORRECTION Odor in cabinet • Clean inside of unit. See “Care and Cleaning” pg. 7. • Unit interior needs cleaned. Noisy operation •... -
Page 10: Obtaining Service
O B TA I N I N G S E RV I C E Before Calling for Service 3. In all correspondence regarding service, be Before calling for service, check the following sure to give the model number, serial num- items: ber and proof of purchase. - Page 11 Mode Selection Instructions Electronic Contro Adjustment of LED set points to specific model (Mode Selection) The same electronic control is used for the model 140. The control contains two different temperature set-point look up tables, one for the 140. The below procedures are used to verify that the correct table is being used for the specific model and to change the look-up table if the incorrect table is in use.
