  • Page 1 2 2 0 0 1 1 1 1 P P L L A A N N N N I I N N G G G G U U I I D D E E...
  • Page 3 T A B L E O F C O N T E N T S Outdoor SS Appliance Cabinet ID..........4-6 Outdoor SS Non-Appliance Cabinet ID..........6 Outdoor SS Cabinet Accessory ID..........7-8 Common Installations..............9-14 Typical Kitchen Layout Packages..........15-25 Countertop Sizing Guidelines..........26-27...
  • Page 4 ”W. x 29 ¼ ”D. x 34 ”H. grill base with warming drawer ) 171 (77.6) For use with any Viking 30”W. outdoor T-Series or E-Series grill and 30”W. outdoor warming drawer access VQWO4120 ( 41 ¼ ”W. x 29 ¼...
  • Page 5 ¼ ”D. x 34 ¼ ”H. side burner base ) - For use with Viking outdoor double & infrared side burners 30”D. WOK, REFRESHMENT STATION & 24”W. TRUSEAR INFRARED GRILLER BASE* • commercial-type construction, design and styling • all cabinets are constructed completely of heavy-duty stainless steel •...
  • Page 6 • commercial-type construction, design and styling • all cabinets are constructed completely of heavy-duty stainless steel • fully concealed door hinges • Professional-style handles match Viking outdoor appliances • heavy-duty adjustable legs • optional toe kick included • two-year limited warranty - door hinges •...
  • Page 7 F I L L E R S T R I P S • attach between cabinets to separate cabinets and create turns • sides are to be mounted flush with doors and not the cabinet face • optional toe kick included VFLR4 Model Approx.
  • Page 8 V I K I N G B A C K PA N E L S F O R U S E I N C U S T O M I S L A N D A P P L I C AT I O N S • heavy-duty stainless steel • for use in custom island installations • individual back panels for each Viking outdoor cabinet • ¼...
  • Page 9: Common Installations

    In General The cabinets have been designed to be easily installed by contractor or consumer. The cabinets are designed completely of stainless steel and provide a rich, contemporary look that complements Viking outdoor appliances. The cabinets are 34 ” high where the toe kick area is 4 ”.
  • Page 10 If the refrigeration falls in the end of a run a, 30”W. side panel (VSP30) should be used. If used in conjunction with a Viking outdoor grill, a VBPFLR4 should be used along with the VSP30 to insure meeting grill specifications (see page 9 exam- ple).
  • Page 11 All the cabinets will be lined up flush at the face, or a 3-sided half-wall could be built to eliminate the side panels. Alternatively, islands can be finished with Viking produced back panels. There are individual panels made to fit each indi- vidual cabinet offered by Viking. The result is a smooth, custom fit finish.
  • Page 12 2) Use a 4”W. back panel whenever a Viking outdoor grill is used in a layout against a non-combustible surface (such as a brick wall). The general specifications for the grill require 3” of space between the back of the grill and any non-combustible surface.
  • Page 13 P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N When to Use Inside and Outside Filler Strips Together (see sample drawing below) In situations where the back of your cabinet layout is exposed, such as in an island setting, inside and outside filler strips will need to be used.
  • Page 14: Common Installations

    VCF135 The installation examples shown in this guide represent basic installations that may be encountered in common installations. Please contact Viking, your Viking Dealer or your Viking Distributor with any questions you might have regarding these or any other installations.
  • Page 15: Typical Kitchen Layout Packages

    T Y P I C A L K I T C H E N L AY O U T PA C K A G E S A series of small, medium & large typical outdoor kitchen layouts, using the Viking stainless steel outdoor cabinetry product line.
  • Page 16 PA C K A G E 5 - 3 ( T H R E E C A B I N E T S ) Elevation View ” thick countertop pieces ” supplied by local source ” Wall Installation NON-COMBUSTIBLE VBPFLR4 VBPFLR4 (stainless facing out) (stainless facing out)
  • Page 17 PA C K A G E 5 - 4 ( F O U R C A B I N E T S ) Elevation View ” thick countertop ” pieces supplied by local source ” Wall Installation VBPFLR4 VBPFLR4 NON-COMBUSTIBLE SURFACE (stainless facing out) (stainless facing out) 1 VQWO4120...
  • Page 18 PA C K A G E 5 - 5 ( F I V E C A B I N E T S ) Elevation View ” ” thick countertop pieces ” supplied by local source Wall Installation VBPFLR4 VBPFLR4 (stainless facing out) NON-COMBUSTIBLE SURFACE (stainless facing out) 1 VQWO5311...
  • Page 19 PA C K A G E 5 - 6 ( S I X C A B I N E T S ) Elevation View ” ” thick countertop pieces ” supplied by local source Wall Installation VBPFLR4 VBPFLR4 (stainless facing out) NON-COMBUSTIBLE SURFACE (stainless facing out) 1 VQWO5311...
  • Page 20 PA C K A G E 5 - 7 ( S E V E N C A B I N E T S ) Elevation View ” ” thick countertop pieces supplied by ” local source Wall Installation 1 VURO3200 1 VSBO2402 VBPFLR4 VBPFLR4...
  • Page 21 PA C K A G E L - 8 ( E I G H T C A B I N E T S ) Elevation View ” thick countertop pieces supplied by local source ” ” Installation 3/4“ VOCF90 Back Panel VBP32 VBP24 VBP24...
  • Page 22 PA C K A G E L - 9 ( N I N E C A B I N E T S ) Elevation View ” thick countertop pieces supplied by local source Installation 3/4“ VTBP32 VBP18 VBP36 VBP18 VOCF90 Back Panel 1 VGRO3200 1 VTPO1810 1 VSBO3602...
  • Page 23 P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N 41” 53” 30” 30” 30” 30” VQWO3010 VQWO4120 VQWO5311 53”...
  • Page 24 P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N 16” 24” 32” 26” 30” 30” 30” 30” VBBO1601 VBBO2602 VURO2400...
  • Page 25 P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N Plan and Elevations Graphic Symbols ¼ ” = 1’-0’...
  • Page 26: Countertop Sizing Guidelines

    P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N C O U N T E RTO P S I Z I N G G U I D E L I N E S F O R WA L L I N STA L L AT I O N S While it is always recommended that field templates be used to exactly determine countertop sizes on outdoor cabinet layouts, the dimensions above, and following rules will be helpful in planning and costing countertop installations: 1.
  • Page 27: Countertop Sizing Guidelines

    P L A N N I N G Y O U R V I K I N G O U T D O O R K I T C H E N C O U N T E RTO P S I Z I N G G U I D E L I N E S F O R I S L A N D I N STA L L AT I O N S While it is always recommended that field templates be used to exactly determine countertop sizes on outdoor cabinet layouts, the dimensions above, and following rules will be helpful in planning and costing countertop installations: 1.
  • Page 28 0310...
