Reversing The Door Swing Of Your Appliance - Zephyr PRB24C01AS-ADA Use, Care And Installation Manual

Installation Instructions

Reversing the Door Swing of Your Appliance

Should you desire to reverse the opening direction of the door, please follow the instructions below.
Safely reversing the door swing of your appliance should require at least two people.
1
1
1 2
1 3
1 4
9
10
1 5
18
1
2
3
8
7
5
4
6
11
PRB24C01AS-ADA Use, Care, and Installation Guide
1. Take out the 2 screws from the lower door axis
(1), remove the door (2), and the axis plate (1)
from the door.
2. Take out the 3 hinge screws from the top right
hinge (3) and remove it.
3. All located at the bottom of the door, unscrew
2 screws and remove the door magnet (4),
unscrew 2 screws and remove the door stopper
(5), unscrew 2 screws and remove the child
safety lock (6), and remove and discard the
Zephyr logo (7). Then, install the door magnet,
child safety lock, and new door stopper (8) on
the opposite side of the door frame. Rotate the
door 180 degrees and install the new Zephyr
logo at the top of the door by following the
steps on the next page.
4. Remove the 3 black decorative nails (9)
from the top left of the cabinet. Install the
black decorative nails to the top right of the
cabinet and install the new top hinge (10)
from the hardware package that includes
the installation manual at the top left of the
cabinet with 3 screws.
5. Install the lower door axis (11) and install the
door once correctly aligned.
