Reversing the Door Swing of Your Appliance

Should you desire to reverse the opening direction of the door, please follow the instructions below.
Safely reversing the door swing of your appliance should require at least two people.
1
1
1 2
1 3
1 4
9
10
1 5
PRB24C01AS-OD Use, Care, and Installation Guide
1
2
3
4
6
5
8
7
11
Installation Instructions
1. Take out the 2 screws from the lower door axis
(1), remove the door (2), and the axis plate (1)
from the door.
2. Take out the 3 hinge screws from the top right
hinge (3) and remove it.
3. All located at the bottom of the door, unscrew
2 screws and remove the door magnet (4),
unscrew 1 screw and remove the door stopper
(5), unscrew 2 screws and remove the child
safety lock (6). Then, install the door magnet,
door stopper, and child safety lock at the top
of the door frame. Remove the grey decorative
cover (7) and Zephyr logo (8) at the top of the
door and install it at the bottom of the door
frame.
4. Remove the grey decorative nails (9) from
the top left of the cabinet. Install the grey
decorative nails to the top right of the
cabinet and install the new top hinge (10)
from the hardware package that includes
the installation manual at the top left of the
cabinet with 3 screws.
5. Install the lower door axis (11) and install the
door once correctly aligned.
