Classic Exhibits SEGUE DESIGN Sunrise VK-1903 Setup Instructions

© 2018
Order #XXXXX
Steps:
Item Description
1) Connect horizontals [1-2] [3-4] [5-6] and [7-8] together. See
1 45" Vertical Extrusion
2) Connect assemblies together on floor. See
2 45" Vertical Extrusion
3) Attach foot to verticals [1] and [3]. See
3 45" Vertical Extrusion
4) Attach SEG graphic to front of assembled frame. See
4 45" Vertical Extrusion
5 45" Horizontal Extrusion
6 45" Horizontal Extrusion
7 45" Horizontal Extrusion
8 45" Horizontal Extrusion
SEG Graphic Attachment
Corner A Corner B
Corner D
Corner C
It is important to first insert Step 1 Step 2
graphic into each alternate Insert corner A. Turn edge of Repeat Step 1 for opposite
corner, then to the sides of
graphic so silicon welt is corner C, then insert corner
the frame. If this is not done, perpendicular to face of B, followed by corner D, to
graphic will not fit into the graphic. Insert narrow side complete the installation of
frame correctly.
of welt with fabric to outside the corners.
into the channel. Repeat for
other side of this corner.
Graphic Removal
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
To remove the graphic
the frame, locate the fabric
pull tab. Gently pull up on the
tab to remove the fabric.
VK-1903 Sunrise
Corner detail.
Foot Attachment detail.
7
Corner
2
Connect ends
together, then
Tighten knob
to secure.
1
*
from 5
Straight detail.
SEG Graphic Installation detail.
8
Straight
Connector
Slide connector into
horizontals, then tighten
knobs to secure.
6
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com
Completed Assembly
4
*
3
Foot Attachment
Attach Foot with Bolt.
*
Foot
Bolt
