- Page 1 © 2018 Order #XXXXX General Layout 10’ 10’ Plan View SETUP INSTRUCTIONS If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com...
- Page 2 © 2018 Order #XXXXX General Information General Setup Instructions - Read entire setup instruction manual prior to WARNING unpacking parts and pieces. - The setup instructions are created specifically for this configuration. - Setup instructions are laid out sequentially in steps, including exploded views with detailed explanation for assembly.
- Page 3 © 2018 Order #XXXXX Case Packing Top View of Each Level Lights Assembled Header Graphics Setup Hardware (4) Wings Level 1 Level 2 Case 1 of 1...
- Page 4 © 2018 Order #XXXXX Backwall Assembly Item Qty. Description Steps: Base Plate 1) Attach base plates [1] verticals [2A] & [3A], using bolts. 2A/2B 42” Vertical Extrusion 2) Connect verticals [2A] [2B] and [3A] [3B], using connection bars [B]. 3A/3B 42”...
- Page 5 © 2018 Order #XXXXX Backwall Attachments Steps: Item Qty. Description 2) Attach assembled header [7/8/9] to extrusions [5A/5B]. 7/8/9 1/1/1 Header Frame 1) Connect lights to extrusions [5A/5B]. See Light Connection detail. 3) Attach graphic to extrusion [3B]. See Graphic Attachment detail.
