Summary of Contents for LG GR419BBCA
- Page 1 FRIDGE-FREEZER User's Guide Please read this User's Guide carefully before operating and keep it handy for reference at all times.
- Page 2 Electrical Connections Important (In the UK Only) The wires in this mains lead are coloured in accordance with the following code: GREEN AND YELLOW:EARTH BLUE:NEUTRAL BROWN:LIVE This appliance must be earthed Green and Yellow(Earth) Brown(Live) Blue(Neutral) As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:...
-
Page 3: Table Of Contents
Table of Contents Registration Introduction Important Safety Instruction Identification of Parts Installation Installation Starting Operation Temperature Control Vacation Express Frz. Self Test Door Alarm Ice Making Defrosting Suggestion On Storing Food Food storage Care and General Information Maintenance Lamp Replacement To Reverse the Doors Cleaning Trouble Shooting... -
Page 4: Introduction
Introduction Registration Introduction The model and serial number are found on the rear of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 5 Important Safety Instruction w w Warning Precaution • This fridge-freezer must be properly installed and located in accordance with the Installation Instruction before it is used. • Never unplug your fridge-freezer by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.
- Page 6 Introduction Important Safety Instruction • Do not disassemble, repair or alter the appliance. It may cause fire or abnormal operations, which may lead to injury. • Pull the power plug out of the socket before replacing the interior light in the refrigerator. Otherwise, there is a risk of electric shock.
- Page 7 Important Safety Instruction w w Warning w w Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. w w Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
- Page 8 Introduction Important Safety Instruction • If the wall socket is loose, do not insert the power w w Caution plug. It may cause electric shock or fire. • Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull it straight out from the outlet.
-
Page 9: Identification Of Parts
Identification of Parts Display Removable Glass Shelf Multi-air Flow Duct Vegetable Drawer (Optional) Ice Tray Freezer Compartment Removable Plinth Leveling Screw Note If you find some parts missing from your unit, they may be parts only used in other models. Introduction Egg Tray Door Basket... -
Page 10: Installation
Installation Installation Select a good location. Place your fridge-freezer where it is easy to use. Avoid placing the unit near heat sources, direct sunlight or moisture. To ensure proper air circulation around the fridge - freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 11: Operation
Temperature Control • Your fridge-freezer has controls that let you regulate the temperature in the fridge and freezer compartments. These controls are on the top of the fridge-freezer. • Initially set the TEMP(erature) CONTROL at “NORMAL”. Fridge Then adjust the compartment temperature according to your desire. -
Page 12: Vacation
Operation Vacation • This function makes the fridge-freezer work in a power saving mode which is useful when you are away on holiday, by reducing energy consumption as much as possible. Pressing ‘VACATION’ starts operation with lamp ON and pressing it again stops the operation. -
Page 13: Self Test
Self Test This function allows you to check for operational problems. If you think you have a problem with your fridge-freezer, then press the temperature control button: - If the indicate lights move up or down, then there is no problem with your fridge-freezer. -
Page 14: Storing Food
Suggestions on food storage w w Caution Storing Food • Do not store food which goes bad easily at low temperature, such as banana, and melon. • Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills. - Page 15 • Freezer Door Basket, marked compartment, that is suitable for sort term storage of frozen food. • If you want to quick freeze new food, you put it middle drawer of freezer compartment, and then press the EXPRESS FRZ. button. •...
-
Page 16: Care And
Care and Maintenance Power Failure If You Move Anti Condensation Pipe General Information • 1~2 hour power failure does no harm to the foods stores. Try to avoid opening and closing the door too frequently. • Take out foods from the fridge-freezer and firmly fix the loose items with tape. -
Page 17: Lamp Replacement
Lamp Replacement w w Caution Note To Reverse the • Your fridge-freezer is designed with reversible doors, do Doors w w Caution Care and Maintenance Unplug the power cord from the outlet. Remove the room lamp lid by taking down while pulling its back projection. -
Page 18: Cleaning
Care and Maintenance Before Cleaning Exterior Interior After Cleaning Warning Cleaning Be sure to unplug the power. Clean the outside of the fridge-freezer with a soft cloth soaked with hot water or liquid detergent. If you use a detergent, be sure to wipe it with a clean wet cloth. As above. -
Page 19: Trouble Shooting
Before calling for service, check this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Problem Possible Causes • Power plug may be unplugged from the electric Fridge-Freezer outlet. - Page 20 Trouble Shooting Problem Moisture collects inside Fridge has odor Door not closing properly Interior light does not work DISPOSAL OF YOUR OLD APPLIANCE 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2.
- Page 21 MEMO...
- Page 22 MEMO...
- Page 23 LG Twin Tower, 20, Yoido-Dong, Youngdungpo-Gu, Seoul, 150-721, Korea. http://www.lge.co.kr P/No. 3828JD8912B Printed in Korea...
