Dimensions
TV INTERFACE
7.87 in
200mm
MIN
MAX
15.75 in
400mm
100mm
MAX
23.6 in
600mm
WALL PLATE
16.00 in
406.4mm
10.36 in
263.1mm
F
U
L
L
Y
A
S
S
E
M
B
L
E
D
27.00 in
685.8mm
16.73 in
425mm
BEFORE YOU BEGIN
Remove the stand
from your TV — if attached.
MIN
3.94 in
24 in
1.77 in
42 deg
609.6mm
45mm
M
O
U
N
T
Install any accessories
you may have purchased, if they
require TV removal prior to assembly.
The TV is removable for future
accessory purchases.
TOP VIEW - EXTENDED
WALL IS ON TOP
SIMULATED 75"
FLAT SCREEN TV
T
O
P
V
E I
W
-
R
E
T
R
A
C
T
E
D
WALL IS ON TOP
3-D
SIDE VIEW - EXTENDED
15°
DOWN
42 deg
S
D I
E
V
E I
W
Protect the face
of your TV when laying it
down for installation.
Soft clean surface
5°
UP
R
E
T
R
A
C
T
E
D
2.26 in
57.5mm
3
