General Information
A
S
R
Q
P
Figure 2-2. 10 kVA and 13 kVA—Components and Control Locations
A Lock with cover
MLCB (generator set
B
disconnect)
C Airbox with air cleaner
D Control panel
Battery compartment
E
(battery not supplied)
8
M
O
N
F Exhaust enclosure
G Status LED indicators
H Oil drain
J Oil fill cap
K Oil filter
B
F
C
D
E
J
L
K
L Composite base
M Data plate location
N Sediment trap
O Fuel regulator
Owner's Manual for Australian 50 Hz Air-Cooled Generators
H
P Fuel inlet
Q Fuel regulator vents (2)
R Wi-Fi module
S Oil dipstick
