- Page 1 ® FUSION USER’S GUIDE PORTABLE, PRACTICAL, FUEL-FREE HYBRID COOKER Manual del usuario en Español / Manuel d'utilisation en Français / Bedienungsanleitung auf Deutsch / 用 手册中文 / 日本語ユーザーズマニュアル https://www.gosun.co/pages/product-manuals...
-
Page 2: Table Of Contents
Table of Contents Important Safety Info General Safety Information Parts List Available Accessories Operating Instructions Open Stove Orient to Sun The GoSun Dial 10-11 Insert Food Power On Cook Food Cook Times Cooking Tips Cleanup Storage Additional Product Info Tube Removal... - Page 3 DANGER AVOID THERMAL SHOCK • Do Not Preheat Stove. • Do Not Place Cold Food or Water Inside Hot Tube. CONTENTS HOT • Handle Stove Contents With Extreme Care. AVOID OVERHEATING • Do Not Leave Empty Stove Open and in the Sun...
-
Page 4: General Safety Information
• ELECTRICAL SPECIFICATIONS • Intended for use with power supplies of 12V, 15A (180W) • Do not put plastic, paper, or non-edible items inside the GoSun Stove. • This device is not intended for use near or by young children or cognitively impaired persons without supervision. -
Page 5: Parts List
Part List Reflectors Open: Reflector Arm (4) GoSun Dial Solar Evacuated Cooking Tube Power Cord Closed: Rubber Latches (2) Handle (2) Cook Tray Power Port Collar (2) Leg (2) -
Page 6: Available Accessories
• Lithium-ion Polymer Battery • Smart, Wireless Thermometer • Includes AC Adapter for Charging GoSun Solar Panel: GoSun Fusion Carrying Case • Fold-able + Durable • Ultra portable with handles and • 12V DC Output shoulder strap Go to www.gosun.co to learn more... -
Page 7: Open Stove
1. The stainless steel cooking tray can easily be cleaned by 1. First Use: Remove from packaging. 2. Slightly lift one end of the Fusion and hinge the hand; it can also be cleaned by unscrewing the wooden handle and placing the tray in the dishwasher. -
Page 8: Orient To Sun
COOKING WITH SOLAR ORIENT TO SUN 1. Firmly grab the Fusion by the Handles on both ends. 2. Rotate the Fusion until the GoSun Dial’s shadow and solar glare are directly in the center ring of target below. GoSun Dial Grab by Handles, NOT by Reflectors... -
Page 9: The Gosun Dial
THE GOSUN DIAL When properly aligned, both the dome’s glare and the dot’s shadow will be in the center of the target. OFF-ANGLE: Glare Shadow ALIGNED: For more information, go to the Accessories page on www.gosun.co. -
Page 10: Insert Food
INSERT FOOD 1. Fill up the Cooking Tray with food. 2. Do not allow the cooker to preheat in the Sun or with electricity before placing food inside to avoid thermal shock. 3. Insert cooking tray until Tray Handle seals with the mouth of the Tube. -
Page 12: Power On
COOKING WITH ELECTRIC POWER ON 1. Locate the Power Cord. 2. Plug the Power Plug into the port on the Cook Tray. 3. Plug the opposite end into any 12V (15 AMP) power source, such as the PowerBank. 4. Activate the switch on the power source end, so that the indicator light turns on. -
Page 13: Cook Food
• Use Caution when handling the device and imple- ments. The GoSun Fusion can reach temperatures of up to 550°F, and will begin heating up as soon as it is exposed to Sunlight or the electric heating element is switched on. -
Page 14: Cook Times
(generally overcast or “thick” air) can significantly impact cooking times due to light scattering. In humid climates the GoSun Fusion will be most e cient in the Spring and Fall. It will not work in the shade without electricity. -
Page 15: Cooking Tips
• The GoSun Fusion tends to trap a large amount of moisture from cooking food and can be used to easily steam vegetables. For a crispier meal, allow more steam to escape by keeping the Tray slightly open. -
Page 16: Storage
4. Close the Reflector with the Rubber Latches on top of the first. 5. Pull Rubber Latches over Hooks to secure Reflectors. 6. Slightly lift one end of the Fusion and hinge the corresponding Leg closed until it seats into place. 7. Repeat Step 6 on the opposite Leg. - Page 17 4. Keep surfaces of Tube and Reflectors clean with glass cleaner or mild soap. 5. If the GoSun Cooking Tray becomes deformed after extensive use and becomes noticeably harder to insert into the tube, it can be remedied by squeezing the tray by hand.
-
Page 18: Tube Removal
Tube Removal For repairing purposes or to do a deep clean of the GoSun Fusion, the tube can be removed from the rest of the device with the following procedures: If cleaning, ensure tube is at room temperature. 1. Remove the Cooking Tray. - Page 19 End Cap Silicone Cushion...
-
Page 20: How It Works
How It Works OUTER SPACE IN A TUBE At the heart of the GoSun is the evacuated glass Tube. It’s not only a superior absorber of light, but also a fantastic insulator. EXTERNAL COATINGS ALUMINUM NITRIDE Catching and Absorbing Light... - Page 21 Specifications Cooking Capacity: • 101 oz (3 L) of liquid Dry Weight: • 14.5 lbs (6.6 kg) Unit Size: • Length: 24.2” (61.5 cm), Height: 8.5” (21.6 cm), Width: 8.2” (20.8 cm) • Estimated Cooking Power: [Sun] 200+ Watts in full sunlight, [Electric] 144W nominal @12Vdc.
-
Page 22: Liability Release
Liability Release By using the GoSun Fusion, the Purchaser and User acknowledges that cooking is an activity that puts you at some amount of risk. The Purchaser and User also acknowledge that it is critical to have read and understood the entire contents of the User’s Manual. -
Page 23: Warranty
To activate your warranty, register at www.gosun.co/register The GoSun Fusion’s evacuated tube is made of glass — It uses the same tough borosilicate glass as Pyrex, but it can break. All purchases are backed with a One-Year Limited Tube Warranty on the evacuated tube. - Page 24 “Authorized Dealer” means any distributor, reseller or retailer that was duly authorized by GoSun at the time of the sale to sell authentic GoSun products in the jurisdiction where it sold the Product, and that sold the Product in new, unused condition in its original packaging.
- Page 25 • In the case of Fraud or Misrepresentation, GoSun reserves the right to deny all warranty coverage or claims. • Risk of Loss- GoSun is not responsible for any Product that is lost in shipping and not actually received by GoSun. To avoid unnecessary delays and minimize the possibility of a lost Product, we strongly suggest that you use the return label provided to you by GoSun’s online warranty system to send your Product to GoSun.
-
Page 26: Contact Us
Contact Us Please ‘Like’ us on Facebook and post your recipes or visit our website www.GoSun.co to learn more. Activate your warranty now at www.gosun.co/register Direct any questions or issues to: support@gosunstove.com Or call us at: 1-888-868-6154 Visit us on Facebook: https://www.facebook.com/gosunstove/... - Page 27 ® FUSION Patent Pending in USA and other countries. Copyright © 2019 GoSun Inc. All rights reserved.
- Page 28 5. Use a standard glass cleaner to clean the Reflectors and the outside of the Tube. 6. If doing a deep clean of the Fusion, see “Tube Removal” section of the manual. Note: Cleaning is recommended every 3-4 uses (or after a spill) to prevent build-up of grease or food matter, which can a ect the flavor of food.
