USER'S GUIDE

EASY, DELICIOUS, FUEL-FREE

SOLAR COOKER

Table of Contents

Need help?

Do you have a question about the GOSUN GRILL and is the answer not in the manual?

Questions and answers

Summary of Contents for GOSUN GOSUN GRILL

Page 1 USER’S GUIDE EASY, DELICIOUS, FUEL-FREE SOLAR COOKER...
Page 2: Table Of Contents
GoSun Dial.................. Insert Food................. Cook Food................14-15 Steam and Drip Trays............. Temperature Gauge..............Cooking Times..............18-19 Cooking Tips............... 20-21 Maintaining Your Grill............. 22-23 How It Works................Liability Release..............Warranty................26-30 Customer Support..............Copyright © 2018 GoSun Inc., all rights reserved...
Page 3 Body and Contents May Be Hot • Do Not Move Cooking Tray Rapidly or Forcefully, Cooking Pans May Spill FRAGILE • Do Not Transport Grill With Cooking Pans Stored Inside • Mount Grill Securely Before Use. Do Not Drop Or Expose To Impact www.gosun.co...
Page 4: Parts List
PARTS LIST Drip Tray Steam Tray Parabolic Reflectors Cooking Pans Reflector Arm Brackets Carrying Handles Tube Inserts GoSun Dial Sliding Tray Temperature Gauge Frame Evacuated Tube Oven Rotating Collars Copyright © 2018 GoSun Inc., all rights reserved...
Page 5: General Safety
• Keep surfaces of Tube and Reflectors clean with glass cleaner or mild soap. • Do not put plastic paper or non-edible items inside the GoSun Grill. • This device is not intended for use near or by young children or cognitively impaired persons without supervision.
Page 6 • When using with liquids, be very careful not to splash or spill the fluid from the Cooking Pan. • Only Use GoSun Grill Implements with your Grill. • Device not intended for commercial use. Copyright © 2018 GoSun Inc., all rights reserved...
Page 7 Cooking Pan Dim: 3” (76mm) x 4.5” (114mm) x 9.8” (248mm) Cooking Pan Volume: 7.5 Cups (1.77 L) Estimated Power Output: 250 Watts Mounting Capability: Mountable with Vesa 200 x 400 Universal Adapter Plate ACCESSORIES Additional Cooking Pans and Trays are also available at www.gosun.co. www.gosun.co...
Page 8: Operating Instructions Place Grill
3. The optimal location is open to lots of sunlight. Keep in mind the Sun will travel east to west, so you’ll want to ensure open access to the Sun as it moves throughout cooking. Copyright © 2018 GoSun Inc., all rights reserved...
Page 9: Open Grill
2. Open Grill by gently pushing Reflectors so they sweep through the Frame. 3. Be sure to push Reflectors evenly so that they don’t contact the sides of the Frame. 4. Make sure the Reflectors clear the bottom of the Grill when opening. www.gosun.co...
Page 10: Open Reflectors
OPEN REFLECTORS 1. Open Reflectors until they stop against their latches. 2. First time: Remove plastic film from the surface of the Reflectors. Copyright © 2018 GoSun Inc., all rights reserved...
Page 11: Orient To Sun
1. Rotate the Grill and Reflectors until the GoSun Dial’s shadow and solar glare are directly in the center ring. 2. Secure the Reflectors in place by rotating the GoSun Dial once clockwise. 3. Rotate the GoSun Dial to tighten or loosen the Reflectors as necessary.
Page 12: Gosun Dial
GOSUN DIAL When properly aligned, both the dome’s glare and the dot’s shadow will be in the center of the target. Unaligned Aligned Copyright © 2018 GoSun Inc., all rights reserved...
Page 13: Insert Food
1. Place food into one or both Cooking Pans. 2. Optionally, use the Steam and/or Drip Trays 3. To speed up cook times, preheat GoSun Grill to #6 before inserting food. Do not preheat past #6. 4. Place Cooking Pan(s) onto the Sliding Tray.
Page 14: Cook Food
4. Close Reflectors or move out of sunlight to prevent overheating when empty. 5. Remember, cooked food can be left in the GoSun Grill to be kept hot and juicy for when you’re ready to eat. 6. Always use a hot pad when removing contents of the Grill.
Page 15 • Use Caution when handling the device and implements. The GoSun Grill can reach temperatures of up to 700°F, and will begin heating up as soon as it is exposed to sunlight. Because of the vacuum insulator, you cannot be burned by touching the exterior of the tube.
Page 16: Steam And Drip Trays
Cooking Pan and place food on top of it. 4. Make sure not to pile food too high on the Steam Tray that it touches the inside top of the Tube. Drip Tray Steam Tray Copyright © 2018 GoSun Inc., all rights reserved...
Page 17 3. When placing food inside, the temperature reading will initially drop, then plateau and finally climb again. 4. Avoid opening the GoSun Grill excessively, or keeping it open for long periods of time, as that allows heat to escape and can slow cooking times.
Page 18: Temperature Gauge
4. Temperature rises steadily and then tends to plateau once food is placed inside. 5. For fastest cooking times, avoid opening the Grill excessively to check progress. Usually the “smell test” will tell whether the food is cooked yet. Copyright © 2018 GoSun Inc., all rights reserved...
Page 19 (generally overcast or “thick” air) can significantly impact cooking times due to light scattering. In humid climates, the GoSun Grill will be most efficient in the spring and fall. It will not work in the shade.
Page 20: Cooking Tips
• Cooked food can be left in the GoSun Grill to be kept hot and juicy for when you’re ready to eat. • Anticipate the movement of the sun (East to West and Height) as it relates to the intended cook time and serving time.
Page 21 • The next round of food will typically cook quicker than the first round since the Tube is preheated. OTHER RESOURCES: - www.gosun.co/blogs/recipes - wLog on and join other GoSun enthusiasts to learn and share recipes and cooking tips. www.gosun.co...
Page 23: How It Works
HOW IT WORKS www.gosun.co...
Page 24: Liability Release
User’s Manual. GoSun Inc. is not liable for damage or injury caused by misuse, abuse, or results from failure to implement the proper safety precautions.
Page 25: Warranty
To activate your warranty, register at www.gosun.co/register The GoSun Grill evacuated tube is made of glass — It uses the same tough borosilicate glass as Pyrex, but it can break. All purchases are backed with a One-Year Limited Tube Warranty on the evacuated tube.
Page 26 DEFINITIONS “Authorized Dealer” means any distributor, reseller or retailer that was duly authorized by GoSun Inc. at the time of the sale to sell authentic GoSun products in the jurisdiction where it sold the Product, and that sold the Product in new, unused condition in its original packaging.
Page 27 One-Time Tube Credit is then applied to a replacement tube to be sent directly to the purchaser’s address of choice. This Credit for may not be used toward any other GoSun products such as GoSun Apparel and accessories. Note that GoSun Inc.
Page 28 • In the case of Fraud or Misrepresentation, GoSun Inc. reserves the right to deny all warranty coverage or claims. • Risk of Loss- GoSun is not responsible for any Product that is lost in shipping and not actually received by GoSun Inc. To...
Page 29 In case of any inconsistency between the English and other versions of this Limited Warranty, the English version shall prevail. REFUNDS AND EXCHANGES All refunds and exchanges are handled through your retailer or distributor. 1-YEAR WARRANTY www.gosun.co...
Page 30 At GoSun, we nourish the good things in life and help others do the same. We also believe that we should do what we can, when we can.
Page 31 CONTACT US Please ‘Like’ us on Facebook and post your recipes or visit our website www.GoSun.co to learn more. Activate your warranty now at www.gosun.co/pages/register Direct any questions or issues to: support@gosunstove.com Or call us at: 1-888-868-6154 Visit us on Facebook: https://www.facebook.com/gosunstove/...
