ASSEMBLY INSTRUCTIONS
INSTRUCTION D'ASSEMBLAGE
Sofa w/ Pillows / Sofa avec Oreiller
It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing
furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet.
PARTS LIST
NO.
DRAWING
A
B
C
D
E
F
G
HARDWARE LIST
NO.
SKETCH
1
2
3
4
ITEM NO: 9899GY/SN-3
QTY
1
3
1
1
3
1
2
QTY
4
4
4
2
Page: 1/3
DESCRIPTION
BACK REST
BACK CUSHION
LSF/RSF/MIDDLE
LSF ARM
RSF ARM
SEAT CUSHION
LSF/RSF/MIDDLE
SEAT FRAME
PILLOW
DESCRIPTION
BOLT
PLASTIC WASHER
BUN FOOT
SUPPORT LEG
Advertisement
Table of Contents
Related Manuals for Homelegance 9899GY/SN-3
Summary of Contents for Homelegance 9899GY/SN-3
- Page 1 ASSEMBLY INSTRUCTIONS INSTRUCTION D'ASSEMBLAGE ITEM NO: 9899GY/SN-3 Sofa w/ Pillows / Sofa avec Oreiller It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet.
- Page 2 BEFORE ASSEMBLY/ LISTE DE PIECES ***Please take out all parts from seat frame for assembly*** SOFA ASSEMBLY INSTRUCTION Note: Place/lay flat Seat Frame on carton or object . STEP 1: Pull up arm sleeve, align and attach both Arms to the Seat Frame, insert bolts and rotate 3 to 5 times to engage it . DO NOT FULLY TIGHTEN IT.
- Page 3 STEP 2 : Assemble Bun Foot onto Seat Frame. STEP 3 : Align and insert metal brackets on Back Rest to assembled Seat Frame, push to the end and make sure it is secure in positon. Pull down Back Rest cover and attach Velcro to the bottom of Seat Frame, make sure it's all fixed properly. CARE INTRUCTION FOR FABRIC FURNITURE In order to maintain the original appearance of your funiture, please follow below care procedures.
