POWER LSF RECLINING CHAIR WITH POWER HEADREST
NOTE: Do not use power tools for assembly. Power tools increase the risk of over tightening which leads to splitting or cracking
the wood.
COMPONENT LIST (CHAIR)
NO.
A
B
C
HARDWARE LIST
NO.
1
2
3
4
Assembly Instruction
& POWER LUMBAR SUPPORT
ITEM NO.: 9828-LRPWHB
DRAWING
DRAWING
QTY
DESCRIPTION
1 PC
BACK REST
SEAT WITH POWER
HEADREST WIRE &
1 PC
POWER LUMBAR
SUPPORT
1 PC
LSF ARM
QTY
DESCRIPTION
1 PC
ADAPTOR
1 PC
PLUG WITH WIRE
2 PCS
LOCK PIN
1 PC
QP-AI-P022-094-0
WRENCH
