PIXEL TOUCH PCB
USER MANUAL
PRODUCTION DESCRIPTION
CAT WALK PANEL is a wonderful LED display screen integral with 25 three-in-one RGB LEDs, featuring auto
DMX addressing and inductive touch control.
FEATURES
- Automatic DMX addressing
- Innovative control by inductive touching
- Easy & one-for-all setting
- Dazzling LED display suitable for various occasions
- Remarkable interactive lighting-up to walking or dancing
SPECIFICATIONS
OPERATING VOLTAGE
CURRENT CONSUMPTION
MAX CURRENT INPUT
LIGHT SOURCE
PIXEL DISTANCE
INDUCTIVE DISTANCE
INDUCTIVE TIME
DIMENSIONS
WEIGHT
INSTALLATION & OPERATION GUIDE
1 Field Connection
Connect the first unit to the 24VDC power supply (and a DMX controller, if necessary). Then link other units
to it in a line by using the power/data cables. Up to 24 units can be linked together by DMX1000K and 6 units
by DMX512.
NOTE:
i) The nominal wattage of the power supply in use must be above the loading of the whole line of units,
otherwise extra power supplies will have to be used, so as to avoid risk of over-loading.
Ii) The maximum permissible current of the power/data cable is 6A. Always keep input current below 6A.
2 Inductive Control
When the units are duly connected and powered, and an object eg finger, foot, etc comes within the
inductive range of the LEDs of a unit, the LEDs will automatically change from background color (manually
preset or DMX controlled) to touch-color, and turn back to background color when the object goes out of the
inductive range,.
3 Auto DMX Addressing
W
h
e
n
C
A
T
W
A
L
K
P
A
automatically addressed in numeric order (D1 ~ D25), starting from red, green and then blue section of the
first LED (position designator - D1) of the first unit. This means a single unit shall takes 75 DMX channels of
which each three channels are assigned to one LED (1st channel for red, 2nd for green and 3rd for blue).
24VDC
450mA
6A
Full color 5050 SMD LEDs (25pcs)
40mm
20mm Max
60ms Min
200(L)x200(W)x10(H)mm
225g
N
E
L
u
i n
s t
a
e r
l
n i
k
e
d
o t
g
e
h t
r e
a
n
d
c
o
n
r t
l o
e l
d
b
y
a
D
M
X
p
o r
o t
c
o
, l
D
M
X
c
h
a
n
n
e
s l
w
l l i
b
e
24-004-2896-00
Rev1.1
