INFOSEC UPS SYSTEM E3 PRO RT 3000 VA User Manual page 14

Input/Output & battery information
Load information
UPS status
Mute operation
Battery information
3.3 Audible alarms
Battery mode
Low battery
Overload
Fault
INFOSEC UPS SYSTEM – 15, Rue du Moulin – 44880 Sautron - FRANCE - www.infosec-ups.com
14
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 11 17 AA 59 204 17
Indicates the input/output voltage, input/output frequency or battery
voltage.
V: voltage; Hz: frequency.
Indicates the load level by 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates overload.
Indicates that the load or the UPS output is short circuited.
Indicates the UPS working in line mode.
Indicates the UPS is working in converter mode.
Indicates the UPS is working in bypass mode.
Indicates the UPS powers the output directly from the mains
Indicates the battery charger is working.
Indicates that the UPS alarm is disabled.
Indicates the battery level by 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates low battery.
Indicates a problem with the battery.
Sounding twice every second.
Sounding every 4 seconds.
Sounding every second.
Continuously sounding.
