Black Box LBG1000A Manual

Black Box LBG1000A Manual

Managed express switch
Hide thumbs Also See for LBG1000A:
Table of Contents

Advertisement

Quick Links

Download this manual
Customer Support Information:
To order or for technical support: Call 724-746-5500 or fax 724-746-0746
Technical support and fax orders 24 hours a day, 7 days a week
Phone orders 24 hours, 7 A.M. Monday to midnight Friday; Saturday 8 to 4 (Eastern)
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: http://www.blackbox.com · E-mail:
Managed Express Switch
info@blackbox
.
JANUARY 2002
LBG1000A
LBG1001C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LBG1000A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box LBG1000A

Summary of Contents for Black Box LBG1000A

  • Page 1 Technical support and fax orders 24 hours a day, 7 days a week Phone orders 24 hours, 7 A.M. Monday to midnight Friday; Saturday 8 to 4 (Eastern) Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 info@blackbox...
  • Page 2 FEDERAL COMMUNICATIONS COMMISSION AND CANADIAN DEPARTMENT OF COMMUNICATIONS RADIO FREQUENCY INTERFERENCE STATEMENT Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación. Servicio por personal calificado deberá ser provisto cuando: El cable de poder o el contacto ha sido dañado; u Objectos han caído o líquido ha sido derramado dentro del aparato; o El aparato ha sido expuesto a la lluvia;...

  • Page 4: Preface

    Preface This manual describes how to install and use LBG1000A. This switch introduced here is designed to deliver full scalability with SNMP/RMON web-based management functions by providing 24x10/100BASE-TX fixed ports and optional 2x1000BASE-SX/LX ports. For the two Gigabit ports, it allows options of fiber type and wavelength at user’s discretion.

  • Page 5: Table Of Contents

    Table of Contents 2/25/02 ............................4 REFACE 2/25/02......................5 ABLE OF ONTENTS ..........................7 RODUCT VERVIEW LBG1000A M 24 + 2 G ......................7 ANAGEABLE IGABIT WITCH .................................7 ACKAGE ONTENTS ..............................9 RODUCT IGHLIGHTS Basic Features...................................................9 Management Support................................................9 ..............................11 RONT ANEL ISPLAY ................................13...
  • Page 6 IP Networking..................................................60 Bridging....................................................69 Static Filtering..................................................72 Spanning Tree Functions..............................................75 SNMP Functions................................................80 Other Protocols................................................82 Port Trunking...................................................84 Port Mirroring...................................................86 Sending and Receiving Files............................................88 ..................................92 OGOUT ................................92 ETTINGS ............................92 ESTORE EFAULT ETTINGS ..................................92 EBOOT ....................93 ASED ROWSER ANAGEMENT .............................93 OGGING ON TO THE SWITCH ..........................94 NDERSTANDING THE ROWSER...

  • Page 7: Product Overview

    Product Overview LBG1000A Manageable 24 + 2 Gigabit Switch Front View Package Contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller.

  • Page 9: Product Highlights

    Manageable Gigabit Switch Product Highlights Basic Features High port count: 24x10/100BASE-TX ports with RJ-45 connectors, plus options of 2x1000BASE-SX/LX ports with SC connectors Auto-negotiation for speed and duplexity on all TX ports Full wire-speed forwarding rate Store-and-forward mechanism Back-pressure and IEEE 802.3x compliant flow control Supports 2K MAC addresses Provides 8M bit memory buffer Provides one uplink button for port 24X...
  • Page 10 COS (IEEE802.1p Classification of Service) 4-level transmission priorities: 4 queues per output port Packet transmission scheduled using Weighted Round Robin (WRR) User-defined weights Classification of packet priority can be based on either a VLAN tag on packet or a user-definable port priority INTERNETWORKING PROTOCOLS Bridging: 802.1D Spanning Tree...

  • Page 11: Front Panel Display

    Front Panel Display M an ag eab le 2 4 6 8 10 12 14 16 G ig abit S w itc h LNK/ACT FDX/COL LNK/ACT RESET FDX/COL 1 3 5 7 9 11 13 15  POWER This LED comes on when the switch is properly connected to power and turned on. ...
  • Page 12  Gigabit Port Status LEDs The LEDs are located at the left side of each Gigabit module, displaying status for each respective port. Please refer to the following table for more details. State Indication Transmitting or receiving data. Flashing ACT stands for ACTIVITY. No activity.

  • Page 13: Physical Ports

    Physical Ports The Manageable Gigabit LBG1000A Switch provides 24x10/100TX fixed ports and options of 2x1000SX/LX ports. CONNECTIVITY - SC connectors on Gigabit ports - RJ-45 connectors on TX ports - One MDIX port for uplink <Note> Refer to the table on page 27 for cabling requirements.

  • Page 14: Basic Functions

    Basic Functions In general, the LBG1000Aswitch is responsible for switching both VLAN tagged and untagged frames from a receiving port to one or more transmitting ports. The switch performs multiple steps during the switching process: VLAN CLASSIFICATION LEARNING FILTERING FORWARDING AGING Below is additional information about tasks that the switch performs during unicast and multicast switching.

  • Page 15: Unicast Switching

    Multicast Switching For multicast switching, the LBG1000A switch checks whether the received frame is a BPDU. If a BPDU is received, the switch forwards the frame to the CPU for processing by the spanning tree protocol. Otherwise, the switch performs the...
  • Page 16 Manageable Gigabit Switch FORWARDING The LBG1000A switch floods the received multicast frame to all ports that are in forwarding state within the VLAN, excluding the source port. At the same time, the switch ascertains the individual port’s VLAN tagging/untagging configuration and corresponding VLAN ID to render the appropriate frame tagging when the frame is ready to be transmitted.

  • Page 17: Vlan

    VLAN A virtual LAN (VLAN) is a network of computers that behave as if they are connected to the same wire, even though they may actually be physically located on different segments of a LAN. VLANs are analogous to a group of end stations, perhaps on multiple physical LAN segments that are not constrained by their physical location and can communicate as if they were on a common LAN.

  • Page 18: Broadcast Containment

    Broadcast Containment In traditional networks, traffic broadcasts to all network devices, whether they are the intended recipients or not. However, VLANs can be set up to contain only those devices that need to communicate with each other. As a result, VLANs significantly reduce network congestion.

  • Page 19: Vlan Membership

    VLAN membership to all ports that belong to the active topology of the VLAN. VLAN CONFIGURATION The LBG1000A switch provides a Local/Remote Management Console Interface for VLAN configuration and management An SNMP-based VLAN MIB is also provided.

  • Page 20: Class-Of-Service (Cos) Support

    Class-of-Service (CoS) Support The LBG1000A switch provides four transmit queues on each port, with a weighted round-robin scheme. These functions can be used to provide independent priorities for various types of data including real-time video, real-time voice, and best-effort data.

  • Page 21: Igmp Snooping And Ip Multicast Filtering

    IGMP Snooping and IP Multicast Filtering The Internet Group Management Protocol (IGMP) runs between hosts and their immediately neighboring multicast routers. The protocol’s mechanisms allow a host to inform its local router that it wants to receive transmissions addressed to a specific multicast group. Routers periodically query the LAN to determine if known group members are still active.
  • Page 22 The purpose of IP multicast filtering is to optimize a switched network’s performance, so multicast packets will only be forwarded to those ports containing multicast group hosts members and routers instead of flooding to all ports in the subnet (VLAN). Routing switches with IP multicast filtering/switching capability not only passively monitor IGMP Query and Report messages, DVMRP Probe messages, PIM, and MOSPF Hello messages;...

  • Page 23: Switch Management

    Switch Management Administration console via RS-232 serial port The LBG1000A switch provides an onboard serial port, which allows the switch to be configured via a directly connected terminal or a Telnet session. Web-based browser interface The LBG1000A switch also boasts a point-and-click browser-based interface that lets users access full switch configuration and functionality from a Netscape or Internet Explorer browser.

  • Page 24: Installation

    This chapter gives step-by-step instructions about how to install the LBG1000A switch: Selecting a Site for the Switch As with any electric device, you should place the LBG1000A switch where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: The ambient temperature should be between 32 and 104 degrees Fahrenheit (0 to 40 degrees Celsius).

  • Page 25: Connecting To Power

    Connecting to Power Step 1: Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug it into a standard AC outlet with a voltage range from 100 to 260 Vac. Step 2: Disconnect the power cord if you want to shut down the switch. RS232 console port Power Receptacle Rear view...

  • Page 26: Power-On Self Test (Post)

    Power-on Self test (POST) The LBG1000A Switch performs its Power-On Self Test (POST) when the power is switched on. During the POST, the switch CPU will: • perform a series of diagnostic procedures to make sure the basic system is functioning integrity •...

  • Page 27: Connecting To Your Network

    Connecting to Your Network Cable Type & Length It is necessary to follow the cable specifications below when connecting the switch to your network. Use appropriate cables that meet your speed and cabling requirements. Cable Specifications Speed Connecto Port Cable Max.

  • Page 28: Cabling

    Manageable Gigabit Switch Cabling Step 1: First, ensure the power of the switch and end devices is turned off. <Note> Always ensure that the power is off before any installation. Step 2: Prepare cable with corresponding connectors for each type of port in use. <Note>...

  • Page 29: Switch Management

    Manageable Gigabit Switch Switch Management This chapter explains the methods that you can use to configure management access to the switch. It describes the types of management applications and the communication and management protocols that deliver data between your management device (workstation or personal computer) and the system. It also contains information about port connection options.

  • Page 30: Management Access Overview

    Management Access Overview The LBG1000A switch gives you the flexibility to access and manage the switch using any or all of the following methods. The administration console and web browser interface support are embedded in the switch software and are available for immediate use.

  • Page 31: Administration Console

    Administration Console The administration console is an internal, character-oriented, menu-driven user interface for performing system administration such as displaying statistics or changing option settings. Using this method, you can view the administration console from a terminal, personal computer, Apple Macintosh, or workstation connected to the switch’s console port.

  • Page 32: Modem Access

    Modem Access You can access the switch’s administration console from a PC or Macintosh using an external modem attached to the console port. The switch management program provides Console Port screen, accessible from the Basic Management screen, that lets you configure parameters for modem access. When you have configured the external modem from the administration console, the switch transmits characters that you have entered as output on the modem port.

  • Page 33: Web Management

    Web Management The LBG1000A switch provides a browser interface that lets you configure and manage the switch remotely. After you set up your IP address for the switch, you can access the switch’s web interface applications directly in your web browser by entering the IP address of the switch. You can then use your web browser to list and manage switch configuration parameters from one central location, just as if you were directly connected to the switch’s...

  • Page 34: Snmp-Based Network Management

    SNMP-Based Network Management You can use an external SNMP-based application to configure and manage the switch. This management method requires the SNMP agent on the switch and the SNMP Network Management Station to use the same community string. This management method, in fact, uses two community strings: the get community string and the set community string.

  • Page 35: Protocols

    Protocols The LBG1000A switch supports the following protocols: VIRTUAL TERMINAL PROTOCOLS, SUCH AS TELNET A virtual terminal protocol is a software program, such as Telnet, that allows you to establish a management session from a Macintosh, a PC, or a UNIX workstation. Because Telnet runs over TCP/IP, you must have at least one IP address configured on the switch before you can establish access to it with a virtual terminal protocol.

  • Page 36: Menu-Driven Console Management

    Menu-Driven Console Management The LBG1000A switch provides a menu-driven console interface for configuration purposes. The switch can be configured either locally through its RS-232 port or remotely via a Telnet session. For the later, you must specify an IP address for the switch first.

  • Page 37: Switch Management Screen

    Switch Management Screen BASIC MANAGEMENT Refer to page 38 for performing basic management activities. ADVANCED MANAGEMENT Refer to page 48 for performing advanced management activities. LOGOUT Highlight this option and press Enter to log out. SAVE SETTINGS Highlight this option and press Enter to save the current settings and remain in the configuration program. RESTORE DEFAULT SETTINGS Highlight this option and press Enter to restore the factory default settings.

  • Page 38: Performing Basic Management Activities

    Performing Basic Management Activities Basic management activities consist of General, LAN Port, and Console Port tasks. Start with Selection Menu Step 1: Highlight [Basic Management] from [Switch Management] screen and press <Enter>. The [Basic Management] screen appears: Step 2: Highlight a desired option and press <Enter>. Or press <Esc> to exit.

  • Page 39: General Management Configurations

    General Management Configurations Step 1: Highlight [General] from [Basic Management] screen and press <Enter>. System Name Step 2: System Name is highlighted. Press <Enter> if you want to change it. Location Step 3: Move to highlight Location and press <Enter> if you want to change it. admin Password Step 4: Move to highlight admin Password and press <Enter>...

  • Page 40: Lan Port Configurations

    Manageable Gigabit Switch LAN Port Configurations Step 1: Highlight [LAN Port] from [Basic Management] screen and press <Enter>. User’s Manual...
  • Page 41 SPEED & FLOW CONTROL Step 2: Speed & Flow Control is highlighted. Press <Enter> if you want to set speed or flow control on port. Step 3: Highlight All (10/100M or 1000M) Ports and press <Enter> to configure at one time. Otherwise, move to highlight each port and press <Enter>...
  • Page 42 Manageable Gigabit Switch <Note> In the Speed Options, Auto denotes auto negotiation on speed and duplex mode, and FD denotes full-duplex. Step 6: Press <Esc> to previous screen. Highlight Flow Control and press <Enter> User’s Manual...
  • Page 43 Flow Control Step 7: For Flow Control, move to highlight a desired setting from the Flow Cntl Options and press <Enter>. Step 8: Press <Esc> to a previous screen as shown in Step 3.
  • Page 44 Admin. Control Step 9: Highlight All Ports and press <Enter> to configure at one time. Otherwise, move to highlight each port and press <Enter> to configure individually. Step 10: For Admin Control, move to highlight Up or Down from admin Status Options.
  • Page 45 Step 11: E.g. Port 4 is set as Admin Down to stop TX/RX transmission. To allow TX/RX transmission on Port 4, move to highlight Up from the options in Step 10. <Note> The other ports are set Admin Up but no link. (Down denotes no link). PHYSICAL PORT ADDRESS Step 12: Press <Esc>...

  • Page 46: Console Port Configurations

    Console Port Configurations Step 1: Move to highlight [Console Port] from [Basic Management] screen. Baud Rate Step 2: Baud Rate is highlighted. Press <Enter> if you want to change the current console baud rate. Flow Control Step 3: Move to highlight Flow Control and press <Enter> if you want to change the current flow control method. Modem Control Step 4: Move to highlight Modem Control and press <Enter>...
  • Page 47 SLIP Step 6: Move to highlight SLIP and press <Enter> if you want to change it, Disabled or Enabled. <Note> If you enable SLIP, a message tells you that the console port becomes accessible only through the SLIP protocol after you logout from the current console screen.

  • Page 48: Performing Advanced Management Activities

    Performing Advanced Management Activities Advanced management activities consist of L2 Switching DataBase / IP Networking / Bridging / Static Filtering / Spanning Tree / SNMP / Other Protocols / Port Trunking / Port Mirroring / File Transfer. Start with Selection Menu Step 1: Highlight [Advanced Management] from [Switch Management] screen and press <Enter>.
  • Page 49 L2 SWITCHING DATABASE View and change VLAN, MAC address, IP multicast group, and port perspectives. IP NETWORKING View and change IP settings, ARP and routing table parameters, DHCP gateway settings, and ping settings. BRIDGING View and change the aging period for a MAC address and the flood limit for all ports. STATIC FILTERING View / add / delete / search all source or destination MAC addresses to be filtered.

  • Page 50: L2 Switching Database

    L2 Switching DataBase Highlight [L2 Switching DataBase] from [Advanced Management] screen and press <Enter>. VLAN PERSPECTIVE Step 1: The VLAN Perspective is highlighted. Press <Enter> to view VLAN info of the default VLAN or if you want to obtain a VLAN perspective instead of the default VLAN. <Note>...
  • Page 51 Manageable Gigabit Switch Enter a new VLAN ID as either a 12-bit decimal or hexadecimal value. <Note> “Remote” is appended to the VLAN ID automatically if the VLAN is learned from a remote switch. User’s Manual...
  • Page 52 Add New Switch Ports Step 3: Press <Esc> and appears the following screen. Press [+] to add new switch ports to the newly created VLAN. [ ] to add switch ports: press [+] on keypad [ ] to delete switch ports: press [-] on keypad * No precautionary message appears before you delete a switch port.
  • Page 53 Step 5: From Select Untagged Ports, press <Enter> to select All Ports or move to highlight each port individually and press <Enter>. Similar procedure when you select Tagged Ports and Forbidden Ports in Step 4. <Note> If you added untagged ports and want to now add tagged ports or forbidden ports, or vice versa, repeat Step 4 and Step 5. Step 6: Press <Esc>...
  • Page 54 Delete VLAN Step 7: Delete VLAN: highlight a VLAN ID and press [-] to delete it. Note that you cannot delete the default VLAN. * No precautionary message appears before you delete a VLAN. * Be sure you do not need the VLAN before doing so. Step 8: Press <Esc>...
  • Page 55 VLAN Info Step 9: Highlight an existing VLAN and press <Enter> to view VLAN information. Step 10: Move to highlight VLAN Activities and press <Enter> to view or search activity information. Step 11: Return to Step 9. Move to highlight VLAN Settings and press <Enter>. The screen appears as shown in Step 3 for adding or deleting switch ports.
  • Page 56 PORT PERSPECTIVE Step 1: Move to highlight [Port Perspective] from [L2 Switching DataBase] screen on page 50, and press <Enter>. You can view VLAN activities and RMON statistics here. Per Port VLAN Activities Step 2: Per Port VLAN Activities is highlighted. Press <Enter>.
  • Page 57 Step 3: Move to highlight a port and press <Enter>. E.g. select Port A to view corresponding VLAN Activities. Step 4: View or search by MAC address individually. Step 5: Press <Esc> to return to a previous screen as shown in Step 1.
  • Page 58 Per Port Statistics Step 6: Move to highlight Per Port Statistics and press <Enter>. <Enter> to view by port <R> to reset counters for all Step 7: Move to highlight a port and press <Enter>. E.g. select Port 1 to view corresponding VLAN Activities. Press <R>...
  • Page 59 Per Port Priority Step 8: Move to highlight Per Port Priority and press <Enter>. Step 9: Move to highlight a port and press <Enter>. E.g. select Port A to view corresponding priority level.

  • Page 60: Ip Networking

    IP Networking Move to highlight [IP Networking] from [Advanced Management] screen and press <Enter>. IP & RIP SETTINGS Step 1: Highlight [IP & RIP Settings] from [IP Networking] and press <Enter>.
  • Page 61 Step 2: The screen shows a list of VLAN IDs, IP addresses, subnet masks, proxy ARPs, and RIPs currently defined. Before you can define a VLAN’s IP settings, you must first create a VLAN as described in previous Step 3: Move to highlight the row that contains the parameters you want to change, and then press <Enter>. Step 4: Move to highlight a parameter you want to change, and then press <Enter>...
  • Page 62 Manageable Gigabit Switch User’s Manual...
  • Page 63 Add/Delete Static ARP Table Entries Step 2: Press [+] on keypad to add an entry into the ARP Table. Enter Internet/Physical Addresses then. Step 3: Press [-] on keypad if you want to delete a static entry from the ARP Table. * No precautionary message appears before you delete an entry from the ARP table.
  • Page 64 Search for ARP Table Entries Step 4: Press <S> to search a static entry. You can search by Internet address or physical address. ROUTING TABLE Step 1: Move to highlight [Routing Table] from [IP Networking] and press <Enter>. The screen shows the Routing Table allows you to view, add, delete or search a particular routing path.
  • Page 65 Routing Table Columns Column Description Network The IP subnetwork address to which the switch can route packets. Mask The related IP subnetwork mask to which the switch can route packets. Gateway The IP address of the router at the next hop. Metric The number of hops needed between the switch and the destination network.
  • Page 66 Add/Delete Routing Table Entries Step 2: Press [+] on keypad to enter Route Options as shown below. Step 3: Press [-] to delete an entry in the routing table. * No precautionary message appears before you delete an entry from the routing table.
  • Page 67 DHCP GATEWAY SETTINGS Step 1: Move to highlight [DHCP Gateway Settings] from [IP Networking] and press <Enter>. Step 2: Move to highlight a row you want to change the DHCP Gateway Settings, and press <Enter>...
  • Page 68 Add/Delete Relay IP Step 3: Press [+] on keypad to add a relay IP. Choose a suitable interface or All Interfaces from Select Outbound Relay Interfaces. Otherwise, you may press [-] on keypad to delete a relay IP. * No precautionary message appears before you delete a relay IP. * Be sure you want to delete it before doing so.

  • Page 69: Bridging

    PING SETTINGS Step 1: Move to highlight [Ping] from [IP Networking] and press <Enter>. Host Step 2 Move to highlight Host and press <Enter>. Step 3 Enter 4 decimal bytes (dot separated) as the IP address to ping. Count Step 4 Move to highlight Count and press <Enter>.
  • Page 70 Manageable Gigabit Switch AGING TIME Step 1: Move to highlight Aging Time and press <Enter>. User’s Manual...
  • Page 71 Aging Options Step 2: Set Aging Time is highlighted. Press <Enter>. Enter a decimal number as bridge aging period in seconds. Step 3: Otherwise, you may move to highlight No Aging, and press <Enter>.

  • Page 72: Static Filtering

    FLOOD LIMIT FOR ALL PORTS Step 1: Move to highlight [Flood Limit for All ports] and press <Enter>. Flooding Options Step 2: Set Flood Limit is highlighted. Press <Enter>. Enter a decimal number as flood limit in packets per second. Step 3: Otherwise, you may move to highlight Unlimited, and press <Enter>.
  • Page 73 Manageable Gigabit Switch User’s Manual...
  • Page 74 SOURCE/DESTINATION MAC ADDRESS OUT-FILTERS Step 1: Move to highlight source MAC addresses or destination MAC addresses for static filtering, and press <Enter>. If you select source MAC addresses, the SRC MAC Out-Filter appears. Add/Delete/Search Step 2: Press [+] on keypad to add a specific MAC address to be filtered. Press [-] to delete a specific MAC address from being filtered.

  • Page 75: Spanning Tree Functions

    Spanning Tree Functions Move to highlight [Spanning Tree] from [Advanced Management] screen, and press <Enter>.
  • Page 76 SPANNING TREE CONFIGURATIONS Step 1: Move to highlight [Spanning Tree Configurations] if you want to change Spanning Tree Protocol Configurations. Read-only values Move down User configurable more Spanning Tree Protocol Step 2: Press <Enter> to enter Spanning Tree Options. Decide to have it Disabled or Enabled. Bridge Priority Step 3: Move to highlight Bridge Priority and press <Enter>.
  • Page 77 SPANNING TREE PORT STATES Step 1: Move to highlight [Spanning Tree Port States] if you want to change per port administration status, and press <Enter>. Step 2: Move to highlight a port if you want to change its administration status, and press <Enter>. ‘Disabled (Link Down)’...
  • Page 78 SPANNING TREE PATH COSTS Step 1: To change the path cost, move to highlight [Spanning Tree Path Costs] and press <Enter>. Step 2: Move to highlight All Ports or each port individually, and press <Enter>. For new path cost, type a decimal number and press <Enter>.
  • Page 79 SPANNING TREE PORT PRIORITIES Step 1: To change the priority level per port, move to highlight [Spanning Tree Port Priorities] and press <Enter>. Step 2: Move to highlight All Ports or each port individually, and press <Enter>. For new priority value, type a decimal number from 0-255, and press <Enter>.

  • Page 80: Snmp Functions

    SNMP Functions Move to highlight [SNMP] from [Advanced Management] screen, and press <Enter>. Factory-default values Move down more SNMP Options Step 1: Move to highlight SNMP and press <Enter>. Decide to have it Disabled or Enabled. Get Community Name Step 2: Move to highlight Get Community Name and press <Enter>. Enter text and press <Enter>.
  • Page 81 Trap Host IP Address Step 4: Move to highlight Trap Host 1 IP Address and press <Enter>. Type an IP address for trap host 1 and press <Enter> Repeat to specify up to three more trap host IP addresses Cold Start Trap Step 5: Move to highlight Cold Start Trap and press <Enter>.

  • Page 82: Other Protocols

    Other Protocols Move to highlight [Other Protocols] from [Advanced Management] screen, and press <Enter>. GVRP Step 1: Move to highlight GVRP and press <Enter>. Step 2: Decide to have it Disabled or Enabled.
  • Page 83 IGMP Step 1: Move to highlight IGMP and press <Enter>. Step 2: Decide to have it Disabled or set in either Passive or Active mode.

  • Page 84: Port Trunking

    Port Trunking Move to highlight [Port Trunking] from [Advanced Management] screen, and press <Enter>. Note that Gigabit ports, Port A or Port B, cannot be used for trunking. Select Range Step 1: Move to highlight a trunk group to which you want to assign ports, and press <Enter> to enter Select Range.
  • Page 85 Manageable Gigabit Switch Step 4: Press <Esc> when completed with selecting ports User’s Manual...

  • Page 86: Port Mirroring

    Port Mirroring Move to highlight [Port Mirroring] from [Advanced Management] screen, and press <Enter>. You can mirror one port from port range 2-12 to Port 1. one port from port range 14-24 to Port 13. Step 1: Move to highlight Port 1 or Port 13. E.g.
  • Page 87 Mirror From Step 2: Press <Enter> to enter Mirror From Options, listing the ports that can be mirrored from. Step 3: Move to highlight the port you want to mirror from and press <Enter>. Mirror Mode Step 4: Move to select Mirror Mode. From Mode Options, decide whether the port to be mirrored from will be receiving or transmitting.

  • Page 88: Sending And Receiving Files

    Sending and Receiving Files Move to highlight [File Transfer] from [Advanced Management] screen, and press <Enter>. If you access the administration console by connecting an RS232 cable directly to the console port at the back of the switch, you will see a different [File Transfer] screen, as shown below.
  • Page 89 RECEIVE FILE VIA TFTP Step 1: Move to highlight Receive File Via TFTP and press <Enter>. Step 2: Type the name of the file you intend to receive and press <Enter>. Step 3: Move to highlight IP Address and press <Enter>. Type the IP address from where the file will be obtained.
  • Page 90 SEND FILE VIA TFTP Step 1: In [File Transfer] screen, move to highlight Send File Via TFTP and press <Enter>. Step 2: If the default File Type is not the one you intend to send, press <Enter>. Select the file type you intend to send and press <Enter>.
  • Page 91 RECEIVE FILE VIA KERMIT Step 1: In [File Transfer] screen obtained via console port, move to highlight Receive File Via Kermit and press <Enter>. Step 2: A dialog box appears to ask if you want to transfer file now. Move to highlight [Yes] and press <Enter> to start file transfer. Otherwise, highlight [No] and press <Enter>...

  • Page 92: Logout

    Logout To log out, highlight [Logout] from [Switch Management] screen and press <Enter>. Please remember to save settings you have changed before you log out. Save Settings To save the current settings and remain in the configuration program, highlight [Save Settings] from [Switch Management] and press <Enter>.

  • Page 93: Web-Based Browser Management

    Web-Based Browser Management The switch provides a web-based browser interface for configuring and managing the switch. This interface allows you to access the switch using a preferred web browser. This chapter describes how to configure the switch using its web-based browser interface. Logging on to the switch SWITCH IP ADDRESS In your web browser, specify the IP address of the switch.

  • Page 94: Understanding The Browser Interface

    Understanding the Browser Interface The web browser interface provides three point-and-click buttons at the upper field of the screen for configuring and managing the switch. In addition, you can click any port on the switch image to view the switch’s current speed, duplex, and activity status.

  • Page 95: Performing File Activities

    Performing File Activities Start with Selection Menu Click the [File] button at the upper field of the main display, the menu options appear. SAVING SETTING Step 1: Click Saving Setting to save your configuration settings. Step 2: When you click it, a message asks ”Are you sure you want to save setting? ”, click OK to save it or Cancel to abort it.
  • Page 96 RECEIVE FILE VIA TFTP Step 1: Click Receive File Via TFTP on the [File] display <Note> The TFTP protocol is used to download upgraded software to the switch. A VLAN with the proper IP address and routing path to the TFTP server must be configured for the switch to access the specified TFTP server.

  • Page 97: Performing Basic Setup Activities

    Performing Basic Setup Activities Start with Selection Menu Click the [Basic Setup] button at the upper field of the main display, the menu options appear.
  • Page 98 GENERAL MANAGEMENT CONFIGURATION Step 1: Click General and the screen shows the Basic Setup/General parameters. The screen here is the same as shown on page 94 when you first access the switch browser interface. Read-only information System Name Step 2: Click in System Name text box on the field of Basic Setup/General. Step 3: Type a system name if it is blank, or replace the current system name with a new one.

  • Page 99: Lan Port Configuration

    LAN Port Configuration To access the LAN configuration parameters, click Basic Setup button first and then point to LAN Port and click a suitable option. For your convenience, click any port on the image of the switch and view its current speed, duplex, and link activity from the LED Panel window.
  • Page 100 Manageable Gigabit Switch Step 2: In the Port column, click the port you want to configure. E.g. click Port 1. Admin Setting Step 3: Click the drop-down menu under Admin Setting, decide to disable or enable it. <Note> Disable: places the port in DOWN state. In this state, packets cannot be switches to and from the port Enable: places the port in UP state.

  • Page 101: Console Port Configuration

    Console Port Configuration To access the console port configuration parameters, click Basic Setup button first and then click Console Port. Baud Rate Step 1: Click an appropriate speed from Baud Rate drop-down menu on the field of Basic Setup/Console Port Configuration.
  • Page 102 Modem Setup String Step 5: If you select Custom_Setup_String, enter the string in the Modem setup String text box. <Note> The default modem setup string configures the modem to auto answer. It works for all Hayes-compatible modems. SLIP Step 6: Click an appropriate option from SLIP drop-down menu to disable or enable SLIP. SLIP Address Step 7: If you enable SLIP, type a SLIP address in SLIP Address text box.

  • Page 103: Performing Advanced Setup Activities

    Performing Advanced Setup Activities Start with Selection Menu Click the [Advanced Setup] button at the upper field of the main display, the menu options appear.

  • Page 104: Mac Address Management

    MAC Address Management From the Advanced Setup menu, point to MAC Address Management to view VLANs and their associated MAC addresses.
  • Page 105 PER VLAN VIEW Step 1: Click Per VLAN View first, and click on the VLAN ID that you want to view. Step 2: Click to close the VLAN Activities window when finished viewing.
  • Page 106 PER PORT VIEW Step 1: Click Advanced Setup  MAC Address Management  Per Port View first, and click on the port that you want to view. If there is a list of MAC addresses here, you may click any one to view information by individual MAC address.
  • Page 107 INDIVIDUAL MAC VIEW Step 1: Click Advanced Setup  MAC Address Management  Individual MAC View. Step 2: Click in the Enter MAC Address text box and type the MAC address that you want to view. Step 3: Then click on the Get Information button. Step 4: Click to close the Individual MAC View window when finished viewing.

  • Page 108: Ip Networking

    IP Networking To access the IP networking parameters, click the Advanced Setup button, and Point to IP Networking from the selection menu.
  • Page 109 IP & RIP SETTINGS Step 1: Click IP & RIP Settings to access IP and RIP settings. A list of VLAN IDs appears, along with their corresponding IP address and subnet mask. Step 2: In the VLAN ID column, click a VLAN ID whose settings you want to view and/or change. IP Address Step 3: Click in the text box and type a new address.
  • Page 110 Manageable Gigabit Switch BOOTP Step 6: Click a value from the drop-down list. Proxy ARP Step 7: Click a value from the drop-down list. RIP Setting Step 8: Click a value from the drop-down list. Use Broadcast/Multicast Step 9: Specify whether you want to broadcast, multicast, or neither from the drop-down list. Advertise Routes Step 10: Specify whether you want to advertise routes.
  • Page 111 Manageable Gigabit Switch Accept Default Route Updates Step 13: Specify whether you want to accept default route updates. User’s Manual...
  • Page 112 Use Split Horizon Step 14: Specify whether split horizon is to be used. Use Poisoned Reverse Step 15: Specify whether poisoned reverse is to be used. Send Triggered Responses Step 16: Specify whether the switch is to send triggered responses. Step 17: When you finished with these selections, click Update Setting.
  • Page 113 DEFAULT GATEWAY Step 1: Click Advanced Setup  IP Networking  Default Gateway to access gateway settings. Default Gateway Step 2: For Default Gateway, click in the text box and type the IP address of the router at the next hop. Metric Step 3: For Metric, click in the text box and type the number of hops needed between the switch and the destination network.
  • Page 114 ARP TABLE Step 1: Click Advanced Setup  IP Networking  ARP Table to view ARP table settings. The information here is read-only.
  • Page 115 DHCP GATEWAY SETTINGS Step 1: Click Advanced Setup  IP Networking  DHCP Gateway Settings to view and/or change settings. Step 2: In the VLAN ID column, click on a VLAN ID that you want to view or change its DHCP gateway settings.
  • Page 116 DHCP Gateway Step 3: Click the drop-down list and decide to have it Disabled or Enabled. Maximum Hops Step 4: Click in the text box and type a decimal number to configure the maximum number of hops. Delay Step 5: Click in the text box and type a decimal number to configure the delay in seconds. Preferred Server Step 6: Click in the text box and type an IP address for it.

  • Page 117: Per Port Statistics

    Per Port Statistics Step 1: To access per port statistics, click the Advanced Setup button, and then click Per Port Statistics from the selection menu. Step 2: Click a port to view statistic data.

  • Page 118: Port Priority

    Port Priority Step 1: To access port priority, click the Advanced Setup button, and then click Port Priority from the selection menu. Step 2: Click a port to change the priority level. Step 3: Click the drop-down list for setting a proper priority level. Step 4: Click Update Setting when completed.

  • Page 119: Bridging

    Bridging To access bridging parameters, click the Advanced Setup button, and then click Bridging from the selection menu. Aging Options Step 1: Click the drop-down list for Disabled (No Aging) or Set Aging Time. Aging Time Step 2: When Set Aging Time is selected, click in this text box and type a decimal number as bridge aging period in seconds.

  • Page 120: Static Mac Filter

    Static MAC Filter To access the static MAC filter parameters, click the Advanced Setup button, and point to Static MAC Filter in the selection menu.
  • Page 121 SOURCE MAC ADDRESS Step 1: Click Source MAC Address. Add Source MAC Address Step 2: Click Add MAC Addr button to add a source MAC address for static filtering. Step 3: The Static Source MAC Filter window appears. Click in the Source MAC Address Filter text box and type a unique MAC source address you want to add.
  • Page 122 Delete Source MAC Address Step 6: If you no longer need a source MAC address, click Delete MAC Addr button to delete it in Step 2. Step 7: The Delete Source MAC Address window appears. Click the Select a MAC Address drop-down list and select the source MAC address you want to delete.

  • Page 123: Ip Multicast Group

    DESTINATION MAC ADDRESS Step 1: Click the Advanced Setup button, and point to Static MAC Filter in the selection menu. Click Destination MAC Address. Step 2: Click Add MAC Addr button to add a destination MAC address for static filtering. Refer to Step 2~5 in Source MAC Address section for similar procedure.

  • Page 124: Vlan Perspective

    VLAN Perspective To view the VLAN configuration information, click the Advanced Setup button, and point to VLAN Perspective in the selection menu. VLAN CONFIGURATION Step 1: Click VLAN Configuration. Step 2: Click on a VLAN ID whose VLAN configuration you want to change. E.g.
  • Page 125 Step 3: The VLAN Information window appears. Click to assign switch ports to VLAN ID 1. For each switch, the port options include Tagged Ports, Untagged Ports, or Forbidden Ports. Step 4: Click to close the VLAN Information window.
  • Page 126 Add a VLAN Entry Step 5: Click on the Add VLAN button to create a new VLAN. Step 6: The Add a VLAN Entry window appears. Step 7: Click in the VLAN ID textbox and specify a new VLAN ID number from 2~4094. Step 8: Click in the VLAN Name textbox and type a name for this newly created VLAN.
  • Page 127 Delete a VLAN Entry Step 11: Click on the Delete VLAN button to delete a VLAN. VLAN ID 1 is the default VLAN and cannot be deleted. Step 12: The Delete a VLAN Entry window appears. Step 13: Click the drop-down menu to select a VLAN ID, which you want to delete. Step 14: Click the Delete button.

  • Page 128: Spanning Tree Perspective

    Spanning Tree Perspective To view the spanning tree perspective parameters, click the Advanced Setup button, and point to Spanning Tree Perspective in the selection menu. CONFIGURATIONS Step 1: To view and/or change the Spanning Tree configurations, click Configurations from the above screen. Read-only values User...
  • Page 129 Spanning Tree Protocol Step 2: Specify whether you want to have it Disabled or Enabled by clicking the drop-down list. Bridge Priority Step 3: Click in the text box and type a decimal number between 0 and 65535. Hello Time Step 4: Click in the text box and type a decimal number between 0 and 10.
  • Page 130 Step 2: In the Port column, click the port whose Spanning Tree information you want to view. E.g. click Port 6. Port Priority Step 3: Click in the text box and type a decimal number between 0 and 255. A low value gives the port a greater likelihood of becoming a Root port.

  • Page 131: Snmp

    SNMP To view and/or change all SNMP-related information, click the Advanced Setup button, and click SNMP in the selection menu. The SNMP Configurations window appears. As shown below, the factory-default SNMP value is Enabled and the factory- default Community Name value is public. SNMP Step 1: Specify whether it is Disabled or Enabled by clicking the drop-down list.
  • Page 132 Manageable Gigabit Switch Step 14: Click Update Setting when completed. A confirmation window appears. Click to close the confirmation window. User’s Manual...

  • Page 133: Other Protocols

    Other Protocols To enable or disable the GVRP and/or IGMP protocols, click the Advanced Setup button, and click Other Protocols in the selection menu. GVRP Step 1: Specify whether it is Disabled or Enabled by clicking the drop-down list. IGMP Step 2: Specify whether it is Disabled or Passive or Active by clicking the drop-down list.

  • Page 134: Port Trunking

    Port Trunking To use the switch’s trunking capability to gain more bandwidth, click the Advanced Setup button, and click Port Trunking in the selection menu. Step 1: The Port Trunking Overview window appears. E.g. Click Trunk Group 1 in the Trunk Group column. Step 2: The Trunk Group 1 Setup window appears.

  • Page 135: Port Mirroring

    Port Mirroring To use the switch’s mirroring capability to mirror one port to Port 1 or Port 13, click the Advanced Setup button, and click Port Mirroring in the selection menu. Step 1: E.g. Click Port 1 in the Mirror To column. Step 2: The Port Mirroring Setting window appears.

  • Page 136: Snmp & Rmon Management

    SNMP & RMON Management This chapter describes the switch’s Simple Network Management Protocol (SNMP) and Remote Monitoring (RMON) capabilities. Overview RMON is an abbreviation for the Remote Monitoring MIB (Management Information Base). RMON is a system defined by the Internet Engineering Task Force (IETF) document RFC 1757, which defines how networks can be monitored remotely.

  • Page 137: Snmp Agent And Mib-2 (Rfc 1213)

    SNMP Agent and MIB-2 (RFC 1213) The SNMP Agent running on the switch manager CPU is responsible for: - Retrieving MIB counters from various layers of software modules according to the SNMP GET/GET NEXT frame messages. - Setting MIB variables according to the SNMP SET frame message. - Generating an SNMP TRAP frame message to the Network Management Station if the threshold of a certain MIB counter is reached or if other trap conditions (such as the following) are met: WARM START...

  • Page 138: Rmon Mib (Rfc 1757) And Bridge Mib (Rfc 1493)

    RMON MIB (RFC 1757) and Bridge MIB (RFC 1493) The switch provides hardware-based RMON counters in the switch chipset. The switch manager CPU polls these counters periodically to collect the statistics in a format that complies with the RMON MIB definition. RMON Groups Supported The switch supports the following RMON MIB groups defined in RFC 1757: - RMON Statistics Group –...

  • Page 139: Bridge Groups Supported

    Bridge Groups Supported The switch supports the following four groups of Bridge MIB (RFC 1493): - The dot1dBase Group – a mandatory group that contains the objects applicable to all types of bridges. - The dot1dStp Group – contains objects that denote the bridge’s state with respect to the Spanning Tree Protocol. If a node does not implement the Spanning Tree Protocol, this group will not be implemented.

  • Page 140: Specifications

    Manageable Gigabit Switch Specifications Manageable 24 + 2 1) Two 1000BASE-SX/LX ports with Gigabit Switch SC connectors (*modules optional) 2) Twenty-four 10/100BASE-T/TX auto-negotiating ports with RJ-45 connectors Applicable Standards IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3z 1000BASE-SX/LX Switching Method Store-and-Forward Forwarding Rate 10BASE-T:...
  • Page 141 Manageable Gigabit Switch Emissions FCC part 15 Class A, CE Mark Class A, VCCI Class A User’s Manual...

  • Page 142: Appendixa - Connector Pinouts

    Manageable Gigabit Switch Appendix A – Connector Pinouts Pin arrangement of RJ-45 connectors: RJ-45 Connector and Cable Pins The following table lists the pinout of 10/100BASE-T/TX ports. Regular Ports Uplink port Input Receive Data + Output Transmit Data + Input Receive Data - Output Transmit Data - Output Transmit Data + Input Receive Data +...

This manual is also suitable for:

Lbg1001c

Table of Contents
