Makita 9564PC Instruction Manual

Hide thumbs Also See for 9564PC:


Quick Links

Angle Grinder
Read before use.


Table of Contents

Summary of Contents for Makita 9564PC

  • Page 1 INSTRUCTION MANUAL Angle Grinder 9564PC 9564PCV 9565PC 9565PCV 9566PC 9566PCV DOUBLE INSULATION Read before use.
  • Page 2: Specifications

    Overall length 307 mm 307 mm 307 mm 307 mm Net weight 2.4 kg (9564PC) 2.5 kg 2.4 kg 2.7 kg 2.6 kg (9565PC) Safety class • Due to our continuing program of research and development, the specifications herein are subject to change with- out notice.
  • Page 3: Ec Declaration Of Conformity

    13. Prevent unintentional starting. Ensure the EC Declaration of Conformity switch is in the off-position before connecting to power source and/or battery pack, picking For European countries only up or carrying the tool. Carrying power tools with The EC declaration of conformity is included as Annex A your finger on the switch or energising power tools to this instruction manual.
  • Page 4 10. Hold the power tool by insulated gripping sur- GRINDER SAFETY WARNINGS faces only, when performing an operation where the cutting accessory may contact hidden wiring Safety Warnings Common for Grinding, Sanding, or its own cord. Cutting accessory contacting a "live" Wire Brushing, or Abrasive Cutting-Off Operations: wire may make exposed metal parts of the power tool This power tool is intended to function as a...
  • Page 5 Safety Warnings Specific for Grinding and Abrasive Safety Warnings Specific for Sanding Operations: Cutting-Off Operations: a) Do not use excessively oversized sanding a) Use only wheel types that are recommended disc paper. Follow manufacturers recommen- for your power tool and the specific guard dations, when selecting sanding paper.
  • Page 6: Functional Description

    WARNING: DO NOT let comfort or famil- CAUTION: iarity with product (gained from repeated • Before plugging in the tool, always check to use) replace strict adherence to safety see that the switch lever actuates properly and returns to the "OFF" position when released. rules for the subject product.
  • Page 7: Electronic Function

    Electronic function Installing or removing wheel guard (For depressed center wheel, Constant speed control multi disc / abrasive cut-off wheel, diamond wheel) • Possible to get fine finish, because the rotating speed is kept constantly even under the loaded condition. WARNING: •...
  • Page 8: Operation

    ► 1. Screw ► 1. Lock nut wrench 2. Shaft lock Pull the lever in the direction of the arrow after loosen- Installing or removing abrasive disc ing the screw. Mount the wheel guard with the protru- (optional accessory) sion on the wheel guard band aligned with the notch on the bearing box.
  • Page 9 Operation with abrasive cut-off / CAUTION: diamond wheel • After operation, always switch off the tool and wait until the wheel has come to a complete stop Optional accessory before putting the tool down. WARNING: When using an abrasive cut-off Grinding and sanding operation / diamond wheel, be sure to use only the special wheel guard designed for use with cut-off wheels.
  • Page 10: Optional Accessories

    CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for ►...
  • Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 884754G221 20180822...
