- Page 1 Installation & User Manual Model: Alchemy FB18 with Remote Control Version 001. Oct. 2021...
- Page 2 Thank you for choosing fully remote control Alchemy Bioethanol fireplace. Model: Alchemy FB18 Please read this manual carefully for correct installation, use and maintenance of the fireplace and familiarise yourself with the proper use of the product. Operate the fireplace in accordance with the instructions provided, so you can fully enjoy the product for many years.
-
Page 3: Table Of Contents
Contents 1. Supplied Parts ................4 2. Safety Information ..............7 2.1 Explosion/ Hazard ............7 2.2 Fire Positioning ............. 7 2.3 Ventilation ..............7 2.4 Fuelling the Fire ............8 2.5 Hot Surface Hazard ........... 8 2.6 Using Accessories ............8 3. -
Page 4: Supplied Parts
1. Supplied and Optional Parts 1. Burner 2. Remote Control 3. RC Handset 4 x AAA Batteries 4. AC 220V -240V Mains Power Cable 5. Fuel Filling Funnel... - Page 5 6. Log Plate and Logs Effect (Optional) Complete Log set Log Plate showing pin locations. Individual Logs...
- Page 6 First layer of logs, A, C, F, G. Place second layer of logs, B, E. Last log making up third layer D. Log Effect offer a more traditional finish to your FB Series. We only recommend the use of our approved Log Effects to ensure a safe and inviting fireplace.
-
Page 7: Safety Information
2. Safety Information Thank you for choosing an Alchemy Bioethanol fireplace, fully remote controlled. Please read this manual carefully for correct Installation, use and maintenance of the fireplace and familiarise yourself with the proper use of the product. Operate the fireplace in accordance with the instructions provided, so you can fully enjoy the product for many years. -
Page 8: Fuelling The Fire
2.4 FUELLING THE FIRE I. This fire uses Bioethanol fuel. Bioethanol is a flammable liquid. Store in original container away from heat and sources of ignition. FOLLOW CONTAINER DIRECTIONS ON USE AND SAFETY OF LIQUID FUEL. II. Bioethanol is classified as a flammable liquid class 1B (for flammability) and class 3 PGII (for transportation) and is regulated by various standards around the world. - Page 9 INSTALLATION GENERAL INFORMATION • While installing the device according to the instruction manual local and national guidelines are to be observed. • The device must be placed on a level surface. • Do not obstruct the ventilation slots and/or ventilators. •...
- Page 10 USER INSTRUCTIONS User Cautions: Your health and safety are paramount; therefore, we have taken all necessary consideration for the design, production, assembly and transport to ensure a pleasing and excellent performance for your Bioethanol fire. Please follow these instructions for assembly, use and maintenance as follow: •...
-
Page 11: Installation
3. Installation INSTALLATION PARAMETERS The floor must be level and the Burner positioned on a flat surface; this can be perfected with the adjustable feet. The Burner must only be placed on a non combustible surface and must be installed in accordance with the outlined safety requirements and clearances. The basket/ burner must be open and have free air on the front and sides in accordance with the minimum opening sizes in fig.1 and fig.2. - Page 12 Fig.1 For reasons of safety, under no circumstances can there be any flammable material within a 1m radius from the fireplace. Also, the manufacturer does not recommend positioning any heat sensitive materials or devices above the fireplace as it can significantly limit the materials properties and lifetime.
-
Page 13: Installing & Removing Appliance From Recess
3.2 iNsTAlliNg & remOViNg APPliANCe FrOm reCess To install the appliance into a recess, • Connect the Power cable to the fire on the rear port. DO NOT CONNECT TO MAINS SUPPLY UNTIL AFTER THE APPLIANCE IS SAFELY INSTALLED. • Once inserted, ensure the fire is level. •... -
Page 14: Ventilation
Free air under burner (cm²) Minimum Room Size (m³) Alchemy FB18 To calculate the room size, measure the Height, length and width and multiply all measurements. e.g. (L) 6.6m x (W) 3.8m x (H) 2.4m = 60.192m... -
Page 15: Quick Start
4. Quick start 4.1 OPERATING REMOTE CONTROL AND TURNING ON BURNER Make sure the remote is loaded with batteries. Normally handset is already paired from the factory however; if it requires to be done again follow Pairing Device instructions (see page 25). - Page 16 Burner is priming when the glow plug is heating up and the fuel starts pumping out, as shown in the image. Once the glow plug reaches required temperature and reached by the fuel, the flame will ignite.
-
Page 17: Out Of Fuel Notification And Refuelling
4.3 OUT OF FUEL NOTIFICATION AND REFUELLING When the tank is empty or does not have sufficient amount of bioethanol, a beep and message will appear on the display screen. You will not be able to fill up the Fuel Tank while flame is on, because removing top cover will trigger the safety switch and will extinguish the flames. -
Page 18: Safety Systems
5. Safety Systems The Alchemy Bioethanol range incorporates several safety systems to ensure a complete peace of mind. 5.1 LEAK DETECTION SENSOR The Bio Fires have a leak detection sensor located underneath the burner on the lowest part of the sump as per image showing the sensor location. -
Page 19: Servicing
6. servicing Turn the appliance OFF and isolate the mains supply. Ensure the appliance is fully cold before attempting to start servicing the appliance. No liability can be accepted by Alchemy Ltd for injury caused by burning or scolding by a hot appliance. A suggested procedure for servicing is listed below. -
Page 20: Troubleshooting
8. Troubleshooting 8.1 There is smoke or a foreign smell coming from the Burner when burning a. There may be waste burning that should not be in the Burner. b. You are using the wrong fuel (it is essential that you ONLY use Bioethanol). c. - Page 21 8.5 rC Handset error Codes The software installed will give an error/ stop coded if the bioethanol fire stopped or did not start from any reason. If the bio-fire stops a code is generated, and can be read on the RC handset. The code number will help to see at which stage in the ignition process or operating the fault has happened.
- Page 22 6 High level sensor not reached, pump timed out Reason: The fuel has not reached the high level sensor in the burner during operation due to fuel running out, blockage in the fuel lines or faulty pump. Solution: Check for leaks, around fuel tank. Check fuel, refuel if no fuel. If leak found or still doesn’t turn on after refuelling, call engineer/dealer to check fuel lines and pump.
-
Page 23: Appendix 1 - Remote Control (Optional Features)
Appendix 1 - remote Control (Optional Features) The appliance is in Standby mode when the power is switched on. You must have the power supply ON (—) before using the handset. The remote control works by radio signal which is configured at the factory with a unique signal code. - Page 24 1. remote Control Functions Press both Menu buttons until a menu appears at top of screen. Three screen options will appear. To select options rotate dial until highlighted in RED and press select. • SET CLOCK • DEVICE • ADVANCED 1.1 SET CLOCK I.
- Page 25 1.2.1 DELETING DEVICE I. Scroll to DEVICE menu and press select. II. This gives details of the appliance and also gives the option to delete the appliance from the remote handset. Press and hold the delete option to remove appliance. III.
- Page 26 1.3 ADVANCED 1.3.1 SCREEN DIMMER I. Scroll to ADVANCE menu and press select. II. This function dims the screen of the remote. To switch dimmer on or off press SET option to toggle between ON and OFF.
-
Page 27: Appendix 2 - Pump Top Change Over
Appendix 2 - Pump Top Change Over To remove the Pump Top, the tabs on the side need to be pushed in as shown on images to release the top from the body. Image above is pump inside the fire enclosure, view from top. - Page 28 Image shows Pump Top removed once the side tabs have released it from the pump body. The insulation sleeves need to be carefully pulled back to reveal the flexi hose connectors (highlighted in red). Cables ties need to be cut off (highlighted in yellow) and the Pump Top flexi hoses can be pulled off the connectors.
-
Page 29: Appendix 3 - Dimensions And Spare Parts
Appendix 3 - Dimensions and spare Parts 3.1 DIMENSIONS... - Page 30 3.2 SPARE PARTS ITEM PART REVISION DESCRIPTION QTY. NUMBER FB18-001 BURNER THERMOCOUPLE FB18-002 BURNER ASSEMBLY FB18-003 SAFETY SWITCH FB18-004 ENCLOSURE BOX ASSEMBLY FB18-005 POWER LEAD FB18-006 IEC POWER SOCKET FB18-007 TOP PLATE – FRONT FB18-008 TOP PLATE – REAR FB18-009 POWER CONTROL ASSEMBLY FB18-010 FUEL PUMP TOP...
- Page 31 NOTES ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
