- Page 1 CHESNEY’S Bio-Ethanol Installation & User Manual model: EFB22 Issue 01...
- Page 2 Thank you for choosing this Chesney’s Bio-Ethanol fire. Please read this information guide carefully to be able to safely install, use and maintain your product.
-
Page 3: Table Of Contents
Contents 1. General Information 2. Installation 3. User Instructions Operating Elements Initial start-up Flame size regulation Device extinguishing Subsequent start-up Information and warning alert Cleaning and maintenance Disposal and recycling... - Page 4 231mm (9 1/8”) 229mm (9”) 2mm (1/16”) 522mm (20 9/16”) 494mm (19 7/16”) 400mm (15 3/4”) 61mm (2 3/8”) 278mm (10 15/16”) 244mm (9 5/8”) Optional log set kit (sold separately)
-
Page 5: General Information
General information • Do not install the device in areas with a cubic capacity of less than / 2.049ft (22m / 240ft with a height of 2.6m / 8.53ft). • Net weight: 11kg. • While installing the device according to the instruction manual local and national guidelines are to be observed. -
Page 6: Installation
INSTALLATION • After opening the packaging box leave the device inside the box for approx. 2 hours until it reaches room temperature. During this time familiarize yourself with the user’s and installation manuals. • The device is specially made to fit Chesney’s 22” Fire Basket. •... - Page 7 Non-flammable materials Non-flammable materials...
-
Page 8: Mm (9
Installation with supports: Make a cavity for the insert. Make sure that the base on which the device is to be placed is level, as later it will not be possible to level the fireplace. The difference in level between the ends of the device must not exceed 2mm. - Page 9 Chesneys 22” fire basket Installing with EFB22 Log Set (optional, sold separately): If installing the unit with the optional log set (sold separately), use the shorter supports (H) supplied as part of the log set kit.
- Page 10 • Locating pins on the metal top plate will ensure that each log sits in the correct position. • Logs must only be handled using the gloves provided. • IMPORTANT: Logs MUST be placed onto the metal top plate in the following order: C - B - A - F - E - G - D, see diagram below: ATTENTION !!! •...
-
Page 11: User Instructions
General information The unit is a decorative appliance with real flames. Due to the innovative technology applied, the device is simple and safe to use. Fuel In order for the device to function correctly use only use fuel that is 86-96% denatured ethanol in accordance with the European Union guidelines (Directive No. - Page 12 vents, etc. • Do not place in areas where there might be a potentially explosive atmosphere of paint vapours, industrial dusts, etc. • Do not use the device at an ambient temperature below 10°C (50° Fahrenheit) or higher than 30°C (86° Fahrenheit). •...
-
Page 13: Operating Elements
• Some elements of the device reach a high temperature. Do not touch the areas of the device adjacent to the flames as it may cause burns. • No items should be placed on the device except those specifically approved by the manufacturer. •... -
Page 14: Initial Start-Up
Control Panel Starts the device from standby mode or Service USB input hidden switches to the standby under a cap Switches to ECO mode The red indicator The green indicator The blue indicator B. Initial start-up of the device On the control panel the blue lightflashes it indicates the lack of fuel in the tank. - Page 15 2.3 Pour the fuel into the funnel following these precautions: • During pouring be careful not to spill fuel out of the filler. If the fuel is spilled and the error message is displayed, an alarm will be triggered and the procedure set out in the table on p.18 of the manual must be followed.
-
Page 16: Flame Size Regulation
C. Flame size regulation The device can operate in two modes: Standard and ECO. The device always starts with a standard flame size. The flame size can be adjusted during operation. In order to reduce the height of the flame, press the ECO button. You will hear two beeps and the ECO button will be highlighted. -
Page 17: Information And Warning Alert
F . Information and warning alert In order to enhance safety, the device is equipped with an electronic system to maintain safe operation. In the case of a dangerous situation, the device will immediately trigger an alarm. - Page 18 LEGEND: Indicator is off Indicator flashes Indicator blinking Information and warning alerts Sound Signals Control Panel Event Procedure Indicators If the fire is not Make sure the device is visible - NO properly connected to the POWER. power supply. If you see a fire Do not leave the device - the device is in unattended by an adult.
- Page 19 Sound Signals Control Panel Event Procedure Indicators The fuel tank is It is not allowed to pour any full. more fuel! Close the Fanola filler bolt. The blue indicator will turn off, the green one will start to flash. There was a fuel Immediately stop pouring spill or the fuel.
- Page 20 Sound Signals Control Panel Event Procedure Indicators Operation error Press the START / STOP button to turn off the sound and hold the ECO button for about 5 seconds. If the message reappears, contact your service provider. The device Press the START / STOP temperature button to turn off the sound.
-
Page 21: Cleaning And Maintenance
V. Cleaning and maintenance Switch off the device before cleaning. Wait until the temperature of the device is close to the ambient temperature. To maintain the device in good condition, please observe the following rules: • The lacquer coating to the surface of the device is not resistant to abrasion. - Page 22 Notes...
