Page 1
Photoelectric Smoke Detector
F11-Y1-xx
Operation Instruction Manual
Thank you for purchasing this product.
In this manual, we have shown the important notice in order for you
to use the device just and the method of handling this system.
In addition to you read this manual well before the utilization,
understanding well, and use.
After you read, in the place where it is seen with anytime, please be
sure to keep.
ES1103 K0
Advertisement
Table of Contents
Related Manuals for Fenwal F11-Y1 Series
Summary of Contents for Fenwal F11-Y1 Series
- Page 1 Page 1 Photoelectric Smoke Detector F11-Y1-xx Operation Instruction Manual Thank you for purchasing this product. In this manual, we have shown the important notice in order for you to use the device just and the method of handling this system. In addition to you read this manual well before the utilization, understanding well, and use.
-
Page 2: Table Of Contents
頁 Table of contents 1. Safety Instructions........................3 2. Name and Function of each section ....................4 2-1. Detector（Type：F11-Y1） ....................... 4 2-2. Mounting Base（Type：FBR-Y）....................5 2-3. Outline Dimensions........................6 3. Install ............................7 3-1. Installation place ..........................7 3-2. Method of installation........................8 4. -
Page 3: Safety Instructions
頁 1. Safety Instructions ･Before the using, read this chapter and use correctly. ･The contents which it occurs when you handle erroneously are divided in two of “warning” and “caution”. This division states clearly the size and impendence of the harm and the damage. The Warning symbol is used to indicate situations and conditions that can ！... -
Page 4: Name And Function Of Each Section
頁 ④Error in regard to use of the consumer, breakdown and the loss with repairing, remodeling other than our company and error connecting. Furthermore, the guarantee referred to here being something which means the guarantee of the payment item single unit, pardons the damage which is induced by the breakdown of the payment item. 2. -
Page 5: Mounting Base（Type：fbr-Y
頁 2-2. Mounting Base（Type：FBR-Y） Conformity wire 18-26AWG (Incase of Pin terminal, under φ2mm) Strip length 4～5mm ①Wiring Terminal (4 places) These holes are Wiring Terminals for communication and power supply. L and C terminals each have two terminals. Two of each terminalｓ are internally connected. Please wire to another Base. -
Page 6: Outline Dimensions
頁 2-3. Outline Dimensions ＜Detector＞ ＜Mounting Base＞ ES1103 730110 K0... -
Page 7: Install
頁 3. Install ･Do not disassemble and repair and remodel a detector. It causes trouble ･Do not remove a detector, Fire can not be detected. ･Do not use a detector which has impacted. And also do not paint or cover a ！... -
Page 8: Method Of Installation
頁 3-2. Method of installation (1) Installation of Mounting Base Conformity wire 18-26AWG (Incase of Pin terminal, under φ2mm) Strip length 4～5mm Please install a Mounting Base to “install holes” with two screws M3 which is more than 15mm length. (See above) ･Incorrect loading of the equipments can cause a malfunction, failure or drop. - Page 9 頁 (3) Put a Detector into Mounting Base Please put both insert guides together, and insert Terminal and Attachment of Detector into Mounting Base. And Turn a Detector Clockwise until make a sound with "a snick". （See above) ･Put Insert guides, Detector Terminal and Attachment together correctly. It causes trouble.
-
Page 10: Specifications
頁 4. Specifications 4-1. Part Number 4-1-1. Detector (1) Name of item: Photoelectric smoke detector (2) Type: F11-Y1-xx (“xx” means Address. It is on Address seal.) 4-1-2. Mounting Base (1) Name of item: Mounting Base (2) Type: FBR-Y 4-2. Electric specifications (1) Rating: DC24V 0.5mA（Be supplied by the control unit. -
Page 11: Environmental Specifications
頁 4-4. Environmental specifications (1) Working temperature range: 0℃～50℃ -20℃～70℃ (2) Storage temperature range: (3) Working humidity range: 30～85%R.H, Non condensing (4) Resistance to corrosion : No tolerance to acid and alkaline. Use the detector in an environment that meets the general specifications ！... -
Page 12: Self Check Function
頁 5. Self check Function The Detector revise own sensitivity changes automatically once a day. Use of Environment and Dirty and Degradation of Optics parts cause of sensitivity changes. Limit the amount of sensitivity revision come and failure. And State Indication LED lights in trouble. Also the detector notifies the control unit of own trouble status. -
Page 13: Disposal
This product is as general industrial waste disposal. Disposal methods are specific criteria depending on each municipality. 8. Support Please inquire about this product to Fenwal Controls of Japan Co., Ltd. Tokyo headquarters. Fenwal Controls of Japan Co., Ltd. 1-5-10 Iidabashi Chiyoda Tokyo, 102-0072 Japan...
