Test report no. 19011679
Page 1 of 24
EUT: ID PM-ECCO+
FCC ID: PJMECCOPLUS
FCC Title 47 CFR Part 15
Date of issue: 2019-02-26
Annex acc. to FCC Title 47 CFR Part 15
relating to
FEIG Electronic GmbH
ID PM-ECCO+
Annex no. 5
User Manual
Functional Description
Title 47 - Telecommunication
Part 15 - Radio Frequency Devices
Subpart C – Intentional Radiators
ANSI C63.4-2014
ANSI C63.10-2013
Date: 2018-06-06
Created: P4
Reviewed: P9
Released: P1
Vers. No. 1.18
TÜV NORD Hochfrequenztechnik GmbH & Co. KG
Tel: +49 2207 9689-0
Rottland 5a, 51429 Bergisch Gladbach, Germany
Fax +49 2207 9689-20
Advertisement
Table of Contents
Related Manuals for Feig Electronic ID PM ECCO+
Summary of Contents for Feig Electronic ID PM ECCO+
- Page 1 FCC ID: PJMECCOPLUS FCC Title 47 CFR Part 15 Date of issue: 2019-02-26 Annex acc. to FCC Title 47 CFR Part 15 relating to FEIG Electronic GmbH ID PM-ECCO+ Annex no. 5 User Manual Functional Description Title 47 - Telecommunication Part 15 - Radio Frequency Devices Subpart C –...
- Page 2 IDENTIFICATION os: 2 /ID P/D ec kblatt_M anual @ 0\mod_1526622727845_10021.doc x @ 13771 @ @ 1 === Ende der Liste für T extmar ke Dec kbl att === MANUAL ID PM ECCO+ Compact and Robust RFID-/Barcode Scanner...
- Page 3 Composition of the information in this document has been done to the best of our knowledge. FEIG ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since, despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.
- Page 4 IDENTIFICATION Contents Pos : 6 /IDP/IVZ /TOC @ 0\mod_1524560731432_10021.doc x @ 10175 @ @ 1 Contents Introduction Reset Configuration Mode Charging the Battery Scanning Barcode 1D Laser ..........................9 1D/2D Imager ........................10 Scanning RFID Bluetooth Connection Numeric Barcodes for Bluetooth Pairing ............... 13 Wi-Fi Connection Transmitting Barcode and/or RFID Data to a Host Technical specification...
-
Page 5: Table Of Contents
IDENTIFICATION Contents 13.6 Safety on the Road ......................20 13.7 Warnings for Use of Wireless Devices ................20 13.8 Potentially Hazaedous Atmospheres – Vehicle Use ............. 21 13.9 Safety in Aircrafts ......................21 13.10 Safety in Hospitals ......................21 13.11 Pacemakers ........................21 13.12 Other Medical Devices .................... - Page 6 Introduction IDENTIFICATION Pos : 8 /IDP/M anuals/Ü berschriften/1/Intr oduc tion @ 0\mod_1526993216125_10021.doc x @ 15697 @ 1 @ 1 1 Introduction Introduction Pos : 9 /IDP/M anuals/Introduc tion/Intr oduc tion ECCO+ @ 3\mod_1542013202968_10021.doc x @ 55611 @ @ 1 The ID PM ECCO+ captures and stores barcodes and RFID data for a variety of uses and transmits those to a host via USB connection, Bluetooth or WiFi.
- Page 7 Introduction IDENTIFICATION programming interface) Key 3 (custom) (This function can be configured by using Master Setup or with the programming interface) Key 4 (custom) (This function can be configured by using Master Setup or with the programming interface) Power key to turn the unit ON. Pressing this key for 3 sec. turns the unit Power ON/OFF button OFF.
- Page 8 Reset IDENTIFICATION Pos : 11 /ID P/M anuals/Ü bersc hriften/1/Reset @ 3\mod_1542030229425_10021.doc x @ 56199 @ 1 @ 1 2 Reset Reset Pos : 12 /ID P/M anuals/PANMOBIL/R es et @ 3\mod_1542016708957_10021.doc x @ 55649 @ @ 1 To reset the ID PM ECCO+ press and hold the keys 1, 2, 3 and 4 for 5 seconds. ...
- Page 9 Charging the Battery IDENTIFICATION Pos : 16 /ID P/M anuals/Ü bersc hriften/1/Charging the Batter y @ 3\mod_1542017653651_10021.doc x @ 55667 @ 1 @ 1 4 Charging the Battery Charging the Battery Pos : 17 /ID P/M anuals/PANMOBIL/C harging the Batter y @ 3\mod_1542018436163_10021.doc x @ 55907 @ @ 1 Before the first operation, the main battery should be fully charged by using the included power adapter or through the USB interface of a computer.
- Page 10 Scanning Barcode IDENTIFICATION Pos : 19 /ID P/M anuals/Ü bersc hriften/1/Sc anni ng Barc ode @ 3\mod_1542017701577_10021.doc x @ 55677 @ 1 @ 1 5 Scanning Barcode Scanning Barcode Pos : 20 /ID P/M anuals/Ü bersc hriften/2/1D Las er @ 3\mod_1542017806783_10021.doc x @ 55697 @ 2 @ 1 5.1 1D Laser Pos : 21 /ID P/M anuals/PANMOBIL/Sc anning Barcode (1D Las er) @ 3\mod_1542018707813_10021.doc x @ 55916 @ @ 1 To scan a barcode follow the steps below:...
- Page 11 Scanning Barcode IDENTIFICATION Pos : 23 /ID P/M anuals/PANMOBIL/Sc anning Barcode (1D/2D Imag er) @ 3\mod_1542020027013_10021.doc x @ 55934 @ @ 1 5.2 1D/2D Imager Pos : 21 /ID P/M anuals/PANMOBIL/Sc anning Barcode (1D Las er) @ 3\mod_1542018707813_10021.doc x @ 55916 @ @ 1 To scan a barcode follow the steps below: 1.
- Page 12 Scanning RFID IDENTIFICATION Pos : 26 /ID P/M anuals/Ü bersc hriften/1/Sc anni ng RFID @ 3\mod_1542017848900_10021.doc x @ 55717 @ 1 @ 1 6 Scanning RFID Scanning RFID Pos : 27 /ID P/M anuals/PANMOBIL/Sc anning RF ID @ 3\mod_1542020944563_10021.doc x @ 55962 @ @ 1 To scan an RFID tag follow the steps below: 1.
- Page 13 Bluetooth Connection IDENTIFICATION Pos : 29 /ID P/M anuals/Ü bersc hriften/1/Bl uetooth C onnecti on @ 3\mod_1542017875297_10021.doc x @ 55727 @ 1 @ 1 7 Bluetooth Connection Bluetooth Connection Pos : 30 /ID P/M anuals/PANMOBIL/Bluetooth Connection @ 3\mod_1542021084856_10021.doc x @ 55971 @ @ 1 To pair the Bluetooth enabled devices to a Bluetooth enabled host.
- Page 14 Bluetooth Connection IDENTIFICATION Pos : 32 /ID P/M anuals/Ü bersc hriften/2/Numeric Barc ods for Bluetooth Pairing @ 3\mod_1542017912662_10021.doc x @ 55737 @ 2 @ 1 7.1 Numeric Barcodes for Bluetooth Pairing Pos : 33 /ID P/M anuals/PANMOBIL/N umeric Barcodes for Bluetooth Pairing @ 3\mod_1542021725822_10021.doc x @ 55989 @ @ 1 Pos : 34 /Steuermodul e/------------ Seitenumbruc h ------------ @ 0\mod_1452083281983_0.doc x @ 10032 @ Page 13 of 13...
- Page 15 WiFi Connection IDENTIFICATION Pos : 35 /ID P/M anuals/Ü bersc hriften/1/Wi-Fi Connec tion @ 3\mod_1542017944279_10021.doc x @ 55747 @ 1 @ 1 8 Wi-Fi Connection WiFi Connection Pos : 36 /ID P/M anuals/PANMOBIL/Wi-Fi C onnecti on @ 3\mod_1542021824140_10021.doc x @ 55998 @ @ 1 To connect Wi-Fi enabled devices to a host.
- Page 16 Transmitting Data to a Host IDENTIFICATION Pos : 38 /ID P/M anuals/Ü bersc hriften/1/Trans mitti ng Barc ode and/or RF ID D ata to a H ost @ 3\mod_1542021992638_10021.doc x @ 56007 @ 1 @ 1 9 Transmitting Barcode and/or RFID Data to a Host Transmitting Data to a Host Pos : 39 /ID P/M anuals/PANMOBIL/Tr ans mitti ng Barcode and/or RFID Data to a Hos t @ 3\mod_1542022060134_10021.doc x @ 56017 @ @ 1 Batch mode...
- Page 17 Transmitting Data to a Host IDENTIFICATION 10 Technical specification Mechanical Data Housing Double-walled Inside: robust ABS Outside: protective rubber coating Dimension (W x H x D) 87 mm x 48 mm x 26 mm (3.42“ x 1.89“ x 1.02“) Weight 98 g (3.46 oz) Protection Class IP 64...
- Page 18 Troubleshooting IDENTIFICATION 11 Troubleshooting Troubleshooting Pos : 42 /ID P/M anuals/PANMOBIL/Tr oubl eshooting @ 3\mod_1542024639030_10021.doc x @ 56026 @ @ 1 Problem Possible Solution Device does not turn on. Make sure the battery is charged. • Laser comes on but device does not Ensure the device is configured to read the type of code being scanned.
- Page 19 NOTE: Changes or modifications made to this equipment not expressly approved by FEIG ELECTRONIC GmbH may void the FCC authorization to operate this equipment. Pos : 49 /Steuermodul e/------------ Seitenumbruc h ------------ @ 0\mod_1452083281983_0.doc x @ 10032 @ @ 1...
- Page 20 Approvals IDENTIFICATION Pos : 50 /ID P/M anuals/Ü bersc hriften/2/Europe (CE) @ 3\mod_1542018076382_10021.doc x @ 55787 @ 2 @ 1 13.2 Europe (CE) Pos : 51 /ID P/M anuals/PANMOBIL/Appr ovals /Europa (CE) @ 3\mod_1542026510111_10021.doc x @ 56063 @ @ 1 This equipment is intended to be commercialized in all the countries of the European Union and there is no commercialization or operational restrictions in any of the countries.
-
